VIEWRAIL Quick Slide Handrail LED Installation Manual

Table of Contents

Read over the provided material prior to the start of your installation
Power Supply Installation & Setup ........................................................................... 3
Testing & Wall Remote Setup ................................................................................... 5
Finishing Up .............................................................................................................. 7
Warnings ................................................................................................................... 8
Troubleshooting ......................................................................................................... 9
Tools & Supplies Needed for this Installation
• Drill
• / " or / " Metal Drill Bit
1 5
4 16
• Wire Cutters
• Wire Strippers
Before you begin, you will need to procure leader wiring
that goes from the LEDs to the LED controller. This is not
provided by Viewrail, as the length and gauge of the wiring
is dependent on your specific installation. There is a table
at the bottom of page 4 that will help you calculate what
gauge you need.
Please take the following precautions:
1. This equipment, like all electrical equipment, should be installed by a qualified person.
2. Do not expose these LEDs, dimmers or power supplies to intense electro-magnetic fields,
including lightning.
3. The controllers and power supplies are not waterproof. Keep them dry.
4. Always observe proper polarity.
© 2024 VIEWRAIL All Rights Reserved ∙ (866) 261-8013 ∙ viewrail.com ∙ For Helpful Tutorials go to www.youtube.com/viewrail
Quick Slide Handrail - LED
Installation Guide
• Silicone
• Wire Fishing Sticks
• Flat Head Screw Driver
Visit our YouTube channel to
watch helpful installation videos
youtube.com/viewrail
Quick Slide Handrail - LED Installation Instructions V4.1 Modified: 02/23/2024
