Summary of Contents for CSL DigiPlus
- Page 1 DigiPlus DIGIPLUS INSTRUCTION MANUAL...
- Page 2 Digital Communicators) that use Fast Format DTMF signalling on PSTN telephone lines for alarm reporting. DigiPlus is suitable for use in systems installed to conform to EN50136 standard for ATS 1-3, and is suitable for EN50131 Security Grade 1-3 installations. In addition, it is suitable for use in systems installed to conform to PD 6662:2010 at Grades 1-3 and for EN50136 environmental classifications 1&2.
-
Page 3: Installation
Using a short length of 2 core wire, connect the power supply (9 to 15v DC) to the ‘SUPPLY’ terminals (- 12v +) on the DigiPlus. The 3, Red, Yellow and Green LEDs will all be on for 1 or 2 seconds. - Page 4 DigiPlus Instruction Manual Connection...
-
Page 5: Factory Default
Communicator and its account/chip number. When Self Learning is complete, the call made by the Digital Communicator will stop and the DigiPlus LEDs will change to: Red off, Yellow off and the Green LED on with a ‘blink’ every 2 seconds. - Page 6 3 seconds) until the Red LED indicates that dialling has started. ( A pre-digit ‘9’ will be automatically added to the telephone numbers where required.) The Red LED will show the call progress to CSL Tech Support via the Gemini Network (see page 7).
-
Page 7: Test Calls
(about 3 seconds) until the Red LED indicates that dialing has started. The DigiPlus will send two calls. One test call will go to the ARC’s X25 receiver via the Gemini Network and one test call to the ARC’s PSTN receiver via the PSTN path. -
Page 8: Led Indications
Message successfully sent Call ARC. Confirm correct Off to the ARC reception of the message Call in progress with the On with 3 'blinks' every Call CSL Tech Support for DigiPlus Up/download second programming service Server Yellow LED, 2 Meaning... -
Page 9: Specification
DigiPlus Instruction Manual Specification Model CS2121 DigiPlus Dimensions (h x w x d) 20 x 94 x 62 mm Weight 75 grams -20C to +60C transit, -4C to +50C Temperature operating Humidity 0 - 80% non-condensing Mounting Any orientation Warranty... - Page 10 DigiPlus Instruction Manual Regulatory Constraints Before attempting to install DigiPlus, the installer must be aware that the CS2121 may only be installed by a professional installer. The Ringer Equivalence Number (REN) of the apparatus is 0.3. The sum of RENs of the individual items connected to one PSTN line should not exceed 4.
- Page 11 Now that the DigiPlus knows the message to be sent, it dials on the PSTN and sends the message to the ARC via its primary path. This may be the Gemini Network to the ARC’s X25 receivers or the telephone lines to the ARC’s PSTN receivers.
- Page 12 DigiPlus will not need to handle it. In this case, the DigiPlus will dial on the PSTN the same number as it detected from the Panel's digi and then connect the Panel's digi directly to the PSTN line. Thus the Panel can make an outgoing call to its up/downloader.
