Aosom A113-003-001 Assembly Instructions Manual

4 piece patio furniture set

Download this manual

4 Piece Patio Furniture Set

Assembly Instructions

KINDLY NOTICE-

HASSEL-FREE WARRANTY

We proudly provid 1-YEAR warranty,if there is

any questions with the products,please feel free

to contact with us.

A113-003-001

The assembly will be easier with

2 people while 1 person could

also do the job.

Around 40 MINS ASSEMBLY

Need help?

Do you have a question about the A113-003-001 and is the answer not in the manual?

Page 1 4 Piece Patio Furniture Set Assembly Instructions A113-003-001 KINDLY NOTICE- HASSEL-FREE WARRANTY The assembly will be easier with 2 people while 1 person could We proudly provid 1-YEAR warranty,if there is also do the job. any questions with the products,please feel free to contact with us.
Page 2: Parts List
Parts List Note: All parts of the screws should not be completely tightened the first time please tighten all screws after all parts are installed. Overview AA 2PCS AB 2PCS BA 1PCS BB 1PCS C 2PCS M6*30 D 2PCS E 1PCS F 1PCS G 1PCS H 24PCS...
Page 3 Assembly-Sibgle Chair Note: All parts of the screws should not be completely tightened the first time please tighten all screws after all parts are installed. Step1 Step2 Connect A to one side of C and D by using Hx4pcs, Use H to connect C and D,as shown below. and connect B to the other side of C and D by using Hx4pcs.
Page 4 Assembly-Loveseat Note: All parts of the screws should not be completely tightened the first time please tighten all screws after all parts are installed. Step1 Step2 Connect E and F together with Hx2pcs. Attach B and A to the left and right sides of E and F using Hx4pcs and Jx4pcs.
Page 5 Assembly-Table Note: All parts of the screws should not be completely tightened the first time please tighten all screws after all parts are installed. Step1 Step2 Use K to secure each of the four L pieces to the G. Turn the table over and place it smoothly. K x 8pcs...
