Summary of Contents for INVT GRP5.12-WLV

  • Page 1 GRP5.12-WLV V1.1-20231203...

  • Page 2: Table Of Contents

    GRP5.12-WLV Operation Manual CONTENTS 1 Technical Data 2 Product Overview Brief Introduction Interface Introduction 2.2.1 Switch ON/OFF 2.2.2 LED Indicator Definition 2.2.3 CAN / RS485 Port 2.2.4 RS232 Port 3 Installation Guide Checking Before Installation 3.1.1 Checking Outer Packing Materials 3.1.2...

  • Page 3: Technical Data

    TECHNICAL DATA NOTE Operating current derating according to cell voltage and battery temperature.

  • Page 4: Product Overview

    For multiple GRP5.12-WLV in parallel, switch ON circular weak current switch on all discharge state and balance state. batteries, long press (more than 3 seconds) ON/OFF button of MASTER battery, LED will flash.
  • Page 5 When all slave pack are closed, the master pack will be closed (sleep mode). For a single GRP5.12-WLV, turn off the Circular weak current switch. For multiple GRP5.12-WLV in parallel, turn off the Circular weak current switch on the main battery first.
  • Page 6 Quantit Quantit Battery box Wall mounting bracket Ground screw Hanging bracket Bottom support bracket Desiccant User manual Outgoing Inspection Report Connet cable...

  • Page 7: Tools

    3.2 Tools 3.4 Installation Instructions 3.4.1 Dimensions Model Tools Knife Measuring tape Socket wrench （10/16mm） Installation Rubber mallet Cross Screwdriver Hammer drill（10mm） ESD gloves Safety goggles Anti-dust respirator Protection Safety shoes 141.5 Minimum mounting distance between battery pack and equipment: 3.3 Installation requirements 150mm 150mm...

  • Page 8: Installation Procedure

    STEP 3 3.4.2 Installation Procedure Hang GRP5.12-WLV on the wall bracket and tighten it STEP 1 Drill the hole with an 10mm drill bit as follows and fix the wall bracket to the wall. Fastening (M4*20) Screw STEP 2 STEP 4 Install the hanging bracket.
  • Page 9 STEP 7 STEP 5 When multiple batteries are connected in parallel, follow the following wiring mode. Connect power cable. MASTER SLAVE SLAVE to Inverter to Inverter to Inverter to Inverter to Inverter to Inverter STEP 6 Connect communication cable. Link in CAN to Inverter CAN port Link out S232...
  • Page 10 to Inverter to Inverter...
