- Page 1 USER’S GUIDE DR-I4F Signal Converter for Impulses and Frequency Signals, Isolated, for Industrial Applications omega.com | info@omega.com For latest product manuals: omega.com/en-us/pdf-manuals...
- Page 2 CONTACT Omega Engineering, Inc. omega.com/contact-us Toll-Free: 1-800-826-6342 (USA & Canada only) Customer Service: 1-800-622-2378 (USA & Canada only) Engineering Service: 1-800-872-9436 (USA & Canada only) Telephone: (203) 359-1660 Fax: (203) 359-7700 Email: info@omega.com For other locations visit: omega.com/worldwide The information contained in this document is believed to be correct, but Omega accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
-
Page 3: Table Of Contents
Table of Contents How to Order ..................................4 Material Included ................................4 Additional Information ...............................4 Installation and Start-Up ..............................4 Typical Applications ................................5 SOS Mode .....................................5 Messages ....................................5 Predefined Configuration Codes ............................6 Predefined Sensors ................................7 Reading Channels ................................7 11. Connections and Dimensions (mm (inch))) ........................8 12. -
Page 4: How To Order
Signal converter for impulses and frequency signals, isolated, for industrial applications Isolated signal converter for frequency signals. Configurable to work with NPN, PNP, pick-up, Namur, mechanical contact, reed contact and other types of sensors. Dedicated input to measure frequency from AC voltage signals up to 600 V AC. -
Page 5: Typical Applications
Typical Applications To measure frequency signals from low voltage sensors such as NPN, PNP, Namur, pick-up and similar. To measure frequency signals from flow meters. To measure frequency signals from AC power networks up to 600 V AC. Signal acquisition, linearization and transmission to remote acquisition devices. Isolation between circuits provided. -
Page 6: Predefined Configuration Codes
converters are being used, to measure 0/1000 Hz. Each DR-I4F can be configured the following label for easy identification: • Label for engine 1 frequency measurement : Eng1.hZ • Label for engine 2 frequency measurement : Eng2.hZ • Label for engine 3 frequency measurement : Eng3.hZ Predefined Configuration Codes Select the desired code for your application, and check the wing sections for more information:... -
Page 7: Predefined Sensors
Predefined Sensors Select the desired sensor for your application and check the following sections for more information: • for information on how to select a predefined sensor, see section 16.1 • to customize the sensor configuration, see section 16.2 Table 3 | Predefined sensors and associated configuration Pull Trigger Anti... -
Page 8: Connections And Dimensions (Mm (Inch)))
11. Connections and Dimensions (mm (inch))) Table 4 | INPUT signal connections INPUT Input terminals signal V AC ~V AC ~V AC (<600 V AC) V AC ~V AC ~V AC (<60 V AC) common signal (2 wires) signal Vexc (2 wires) NPN, PNP common... -
Page 9: How To Operate The Instrument
Table 5 | Output Signal Connections Output terminals OUTPUT Connections signal 4/20 mA active (in) (out) output 4/20 mA passive output* (*external (out) (in) loop power needed) 0/10 V DC common +V DC 12. How to Operate the Instrument 12.1. Configuration System The instrument is fully configurable from the 3 push button keypad a the 4 red digit led display at the front of the instrument (see Table 6). -
Page 10: How To Operate The Configuration Menu
• key ‘LE’ () activates the ‘messages’ function (see section 12.5). ‘ECO’ FUNCTION (‘DISPLAY’ POWERED OFF) The ‘Eco’ function powers off the display under the following conditions: • the instrument is in ‘normal mode’ of operation. • there is no interaction from the operator for 60 seconds. The decimal point remains active (flashing), indicating that the instrument is working correctly. -
Page 11: How To Operate The 'Force' Menu
12.4. How to Operate the ‘Force’ Menu HOW TO ENTER THE ‘FORCE’ MENU With the instrument in ‘normal mode’ of operation (see section 12.2), press and hold the ‘UP’ () key for 1 second. The horizontal LEDs light from bottom to top. When the upper led lights, the instrument enters into the ‘force’... -
Page 12: How To Activate The 'Messages' Function
12.5. How to Activate the ‘Messages’ Function HOW TO ACTIVATE ‘MESSAGES’ FUNCTION With the instrument in ‘normal mode’ of operation (see section 12.2), press the ‘LE’ () key to activate the ‘messages’ function. The ‘messages’ function displays information about the instrument. The information available is configurable (see section 16.8). -
Page 13: Ac Frequency Signals
13.2. V AC Frequency Signals SIGNALS ACCEPTED The instrument has a dedicated input to read frequency from voltages up to 600 V AC and voltages up to 60 V AC. Phase-to-phase and phase-to-neutral connections are accepted. PREDEFINED CONFIGURATION CODES See ‘Table 2’ for a list of predefined configuration codes for input-output signal ranges. To activate a code see section 16.1. -
Page 14: Technical Specifications
14. Technical Specifications SENSORS NPN, PNP, pick-up, push-pull, mechanical contact, reed contact, V AC, types of sensor see the ‘Advanced sensor’ menu (see section 16.2) for sensor configuration max. voltage at terminals (see Table 3) input impedance (see Table 11) maximum frequency (see Table 11) 15 V DC @50 mA... - Page 15 Table 11 | Sensor types and specifications Sensor Max. voltage at terminals Minimum detectable signal / detection levels 5.1 KOhms ±30 V DC ‘0’ level <1 V, ‘1’ level >2 V 5.1 KOhms ±30 V DC ‘0’ level <1 V, ‘1’ level >2 V Mechanical 5.1 KOhms ±30 V DC...
-
Page 16: Frequency Calculation Modes
15. Frequency Calculation Modes The instrument calculates the frequency applying the ‘slow’ mode or the ‘fast’ mode. Fast mode ‘Fast’ mode activates when the ‘input high signal’ parameter (see section 16.5) is higher or equal than 500 Hz. The frequency calculated is the number of impulses received during a time window, divided by the time window value in seconds. -
Page 17: Configuration Menu
16. Configuration Menu 16.1. Function Codes and Sensor The fastest way to configure the instrument, is to select a predefined configuration code (see Table 2) and a predefined sensor (see Table 3). At the ‘Configuration code’ (codE) parameter use keys ‘UP’ () and ‘LE’ () to move up and down through the list of codes. -
Page 18: Sensor Configuration
16.2. Sensor Configuration Sensor configuration is a critical part of the configuration. If the sensor is correctly configured, the instrument will be able to read impulses. If the sensor is not correctly configured, the instrument will not be able to read any impulse signal and it will be considered a 0 Hz signal. -
Page 19: Input Range
At the ‘Gate’ (GAtE) parameter configure the value to ‘0.25’, ‘0.50’, ‘1.0’, ‘2.0’ or ‘4.0’ seconds. Applies only in ‘fast’ mode (see section 15). At the ‘Time to 0’ (tt0) parameter configure a value between ‘1.0’ and ‘10.0’ seconds. Applies only in ‘slow mode’... -
Page 20: Output Range
16.4. Output Range At the ‘Output range’ (out) menu entry, select the output signal range to 4/20 mA (value ‘420’) or to 0/10 V DC (value ‘010’). The output signal range selected can be later customized to operate in a reduced range of signal (see section 16.5). -
Page 21: Display Information
16.6. Display Information At the ‘Display information’ (dISP) menu select one parameter to read on display when the instrument is in ‘normal mode’ of operation. If you need access to more than one information, see the ‘messages’ function (see section 16.8) associated to front key ‘LE’ (). -
Page 22: Key 'Le' ('Messages' Function)
16.8. Key ‘LE’ (‘Messages’ function) The key ‘LE’ () at the front of the instrument gives access to a configurable set of information messages. At the ‘Key LE (messages function)’ (K.LE) menu, select the informations to be displayed when the front key ‘LE’ () is pressed (see section 12.5). -
Page 23: Tools' Menu
16.9. ‘Tools’ Menu The ‘Tools’ (tool) menu groups several functions. • at the ‘Eco mode’ (Eco) parameter, define the time to wait before the display is powered off (while in ‘normal mode’ of operation). Default value is 60 seconds. Configure ‘0’ to disable the function and maintain the display always on. - Page 24 value, are treated as a ‘0’. This parameter applies to all measuring ranges. • the ‘Version’ (VEr) parameter informs about the firmware version running in the instrument. • at the ‘Password’ (PASS) parameter define a 4 digit code to block access to the ‘configuration menu’. Activate the password to prevent access to the instrument configuration by non authorized personnel.
-
Page 25: Full Configuration Menu
Full Configuration Menu Press ‘SQ’ () for 1 second to access the ‘configuration menu’. For a description on how to operate inside the menus see section 12. For a full vision of the ‘configuration menu’ structure see section 16. Full Configuration Menu... - Page 26 DR-I4F User's Manual...
-
Page 27: Factory Default Parameters
18. Factory Default Parameters Function code (codE) (c.025) Predefined sensors (SnSr) (nPn) Advanced sensor configuration (Ad.Sn) Pull resistors (PuL.r) pull-up (P.uP) Gain amplification (GAIn) (G 1) Trigger level (TrIG) Antirrebound filter (rnbd) [milliseconds] Excitation voltage (V.EXc) 15 V DC (15 V) Reading channel (chL) ‘B’... -
Page 28: Error Codes And Messages
• press key ‘UP’ () to locate ‘Factory reset’ and press ‘SQ’ () • value ‘no’ appears on display, press key ‘UP’ () and ‘Yes’ appears • press key ‘SQ’ () to apply the factory reset • the LEDs light a round shape while the new configuration is applied •... -
Page 29: Ce Declaration Of Conformity
Maintain clean by using a humid rag and do NOT use abrasive products such as alcohols, solvents, etc. General recommendations for electrical installations apply, and for proper functionality we recommend: if possible, install the instrument far from electrical noise or magnetic field generators such as power relays, electrical motors, speed variators, ... - Page 30 WARRANTY/DISCLAIMER OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEGA’s WARRANTY adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maximum coverage on each product.
