Vicpas Vision V1210-T20BJ User Manual

Vision™PLC+HMI
General Description
V700 OPLCs are programmable logic controller that comprise a built-in operating panel containing a 7" Color Touchscreen
You can find additional information, such as wiring diagrams, in the product's installation guide located in the Technical Library at
www.unitronics.com
I/O Options
Screen
Keypad or Function Keys
Programming Com Port, Built-in
RS232/485
Ethernet
USB device,
mini-B
Com Ports, separate order, installed
by user
* V700 comprises both RS232/485 and USB ports; note that only one channel may be used at a time.
Standard Kit Contents
Controller
Terminal Block
Battery
Mounting Brackets
Rubber Seal
Alert Symbols and General Restrictions
When any of the following symbols appear, read the associated information carefully.
Symbol Meaning
Danger
Warning
Caution Caution
▪
Before using this product, the user must read and understand this document.
▪
All examples and diagrams are intended to aid understanding, and do not guarantee operation. Unitronics accepts no responsibility for
actual use of this product based on these examples.
▪
Please dispose of this product according to local and national standards and regulations.
▪
Only qualified service personnel should open this device or carry out repairs.
Failure to comply with appropriate safety guidelines can cause severe injury or property damage.
▪
Do not attempt to use this device with parameters that exceed permissible levels.
▪
To avoid damaging the system, do not connect/disconnect the device when power is on.
Environmental Considerations
▪
Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in
accordance with the standards given in the product's technical specification sheet.
▪
Do not place in water or let water leak onto the unit.
▪
Do not allow debris to fall inside the unit during installation.
▪ Ventilation: 10mm space required between controller's top/bottom edges & enclosure walls.
▪
Install at maximum distance from high-voltage cables and power equipment.
UL Compliance
The following section is relevant to Unitronics' products that are listed with the UL.
The following models: V700-T20BJ is UL listed for Hazardous Locations.
The following models: V700-T20BJ, V700-T4-T20BJ-N, are UL listed for Ordinary Location.
For models from series V700, that include "T4" in the Model name, Suitable for mounting on the flat surface of Type 4X enclosure.
For examples: V700-T20BJ will be modified V700-T4-T20BJ
Unitronics
User Guide
V700-T20BJ
V700-S-T20BJ
Snap-in I/O Modules / I/O Expansion Modules
7" Color Touch
None
Yes
Yes
Yes
The user may install one or both of the following ports:
•
CANbus port (V100-17-CAN)
•
RS232/RS485 port (V100-17-RS4/V100-17-RS4X)
Yes
Yes (3 pin)
Yes
Yes (4 parts)
Yes
Description
The identified danger causes physical and property damage.
The identified danger could cause physical and property damage.
Use caution.
1
