American International TOYK964 Manual

KIT ASSEMBLY INSTRUCTIONS
Double DIN & Double ISO Mount Applications
1) Remove the Shaded tab from the back edge of each left and right mounting bracket
(see Fig. B below). (Right tab not shown)
2) Cut and remove center rib from main bracket.
3) Attach the left and right side brackets to the main bracket.
4) Attach a rear support bracket to the rear of the radio components and adjust as needed to allow
rear support bracket to rest in the sub-dash (optional).
NOTE: : ISO trim ring (DITR964) must be used in place of after-market radio's trim rings. For ISO mount applications, mount after-
market radio components to side brackets using screws provided with radio when possible or hardware included with kit.
Fig. A
Cut
2500 East Francis Street Ontario, CA 91761, U.S.A.
USA Sales (800) 336-6500
Canada Sales (888) 922-3006 • USA Fax (805) 388-7950
CUSTOMER HELP LINE
USA 800-323-4329 • Canada 800-245-8777
For ISO mount only: Attach (1) ISO Spacer to the inside of lower sections
on both Left & Right mounting brackets as shown in Fig. A.
Fig. B
Cut
VEHICLE APPLICATIONS
2004-08 SOLARA
Toyota
©2015 AMERICAN INTERNATIONAL INDUSTRIES, INC.
iTOYK964 TECH Ver. 01/15 PRINT Ver. 01/15
