INSTRUCTION MANUAL
GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STA6445TC and is the answer not in the manual?

Questions and answers

Related Manuals for Smeg STA6445TC

Summary of Contents for Smeg STA6445TC

  • Page 1 INSTRUCTION MANUAL GUIDE FOR USING THE DISHWASHER AND THE WASHING PROGRAMS...

  • Page 3: Table Of Contents

    Cleaning and maintenance _______________________________ 31 Troubleshooting ________________________________________ 35 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need about the right conditions for the proper, safe use of your dishwasher.

  • Page 4: Safety And Operating Instructions

    THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND MARKINGS IS VISIBLY POSITIONED ON THE INNER EDGE OF THE DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST NEVER BE REMOVED. DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED WITHIN THE HOME.

  • Page 5: Safety Instructions

    DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE WHICH MAY CAUSE AN EXPLOSION. DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS. DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM...
  • Page 6 WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER. The manufacturer declines all responsibility for damage to persons or property resulting from failure to observe the above precautions, from tampering with even a single component of the appliance, or from the use of non original spare parts.

  • Page 7: Installation And Hook-Up

    Make sure to tighten the locking ring-nut once the pipes have been placed in the direction required. A hole at least 8 cm in diameter is required to allow the power supply cable and pipes to pass.

  • Page 8: Water Supply Connection

    The free end should be positioned at a height of between 30 and 100 cm, and should never be submerged in water. If a horizontal drain extension hose is used (for a maximum of 3 m) the drain hose can be placed at a maximum height of 85 cm from the ground.
  • Page 9 BELOW AND THE REGULATIONS IN FORCE. L = brown N = blue = yellow-green In the event of damage to the supply cord, have it replaced by the manufacturer or an Authorized Technical Service Centre in order to avoid any risk.
  • Page 10 Fit replacement 13A fuse into fuse cover. Refit both into plug. The fuse cover must be refitted when changing a fuse and if the fuse cover is lost the plug must not be used until a correct replacement is fitted.

  • Page 11: Description Of The Controls

    Delayed start 1 - 24 hours Error message Err01,…….Err09 Some components are live even with the ON/OFF button in the OFF position. Before maintenance work on the appliance, remove the plug or turn off the power supply at the wall switch.
  • Page 12 User instructions SETTING THE WASHING PROGRAM AND SWITCHING ON To select the most suitable program for the dishes to be washed refer to the table below, which indicates the most appropriate program according to dish type and degree of soiling.
  • Page 13 1,60 even with dried-on 2 cold rinses residues. Rinse at 70°C **** IMPORTANT: see “NOTES AND REFERENCES” table on the following pages. The washing cycle will not take place if the dishwasher door is left open or not properly closed.
  • Page 14 2 cold rinses on residues. Rinse at 70°C IMPORTANT: see “NOTES AND REFERENCES” table on the following pages. The washing cycle will not take place if the dishwasher door is left open or not properly closed.
  • Page 15 Only run the soak program with half loads. Options cannot be used with the soak program. The ENERSAVE option (if featured) cannot be used with soak, ultra clean, or any programs which do not include the final drying stage. Standard programme under EN 50242. If present, the ENERSAVE option must be enabled.

  • Page 16: Washing Programs

    Select this option together with any washing program (except the soak program) to SHORTEN the cycle by from a minimum of 10% to a maximum of 55%, depending on the cycle selected. To activate this option, press the QUICK TIME button (light comes on) after selecting the program required.
  • Page 17 (the light goes out). If the water hardness has been set on a value above H3, and the option is activated, the relative light flashes, warning of a setting error. Multi- function products are not suitable for use with very "hard"...
  • Page 18 After approximately 1 minute the dishwasher will advance to the end of cycle. CHANGING THE PROGRAM To change the program in progress, simply open the door and select a new program. When the door is closed the dishwasher will automatically select the new program.
  • Page 19 User instructions If the door has to be opened while washing is in progress, the program will be interrupted. The relative light will keep flashing and a beeper will signal that the cycle has not been completed. You must wait about 1 minute before closing the door to restart the program.

  • Page 20: Operating Instructions

    Before replacing the cap, remove any salt residues from around the opening. • When using the dishwasher for the first time, in addition to the salt it is also necessary to add one litre of water to the container. •...
  • Page 21 (h.-0, h.-1, h.-2…h.-5). Refer to the "Water hardness table" to select the value. • To exit the programming mode press one button or do not touch the keypad for 2 seconds.

  • Page 22: Using The Rinse Aid And Detergent Dispensers

    Contact your local water board for information on the hardness of your water supply. After adjustment or display of the current setting, simply do not touch the button for a few seconds; the dishwasher will automatically return to standard mode, quitting the adjustment mode.
  • Page 23 • Replace the cover and turn it in a clockwise direction. • Use a cloth to remove any spillage of rinse aid which might lead to the formation of excess foam. ADJUSTING THE RINSE AID DISPENSER SETTING The dishwasher is factory set for medium water hardness. However it possible to change the setting by turning the dispenser’s selector to the...
  • Page 24 • The detergent packs must be sealed and stored in a dry place to prevent the formation of lumps which may negatively affect washing results. Once opened the detergent packs should not be kept for too long, otherwise the detergent loses its effectiveness.

  • Page 25: General Warnings And Recommendations

    The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 26 If in doubt as to the fastness of the colours, it is advisable to wash just a few items at a time for approximately one month.
  • Page 27 The dishwasher has a capacity of 13 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
  • Page 28 Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples:...
  • Page 29 The basket has removable top grids into which items of cutlery should be inserted to keep them properly spaced and allow water to pass between them effectively. The top grids and central lid are in the bag of accessories. The central lid functions as a lid only.
  • Page 30 It is recommended to load the upper basket with small- or medium-sized items such as glasses, small plates, tea or coffee cups, shallow bowls and light objects made from heat resistant plastic. If the upper basket is used in the lowermost position, it can also be loaded with serving dishes, provided they are only slightly soiled.
  • Page 31 User instructions Depending on the models, the basket may be equipped with some or all of the following accessories: Supports for cups or long objects (ladles, spoons…), on the left; can be tipped to the vertical position when not in use.
  • Page 32 • Return the stops to their original position. The left hand and right hand sides of the basket must always be set at the same height. Version B: with adjustment in three positions on both sides. The sides of the basket must always be set at the same height.

  • Page 33: Cleaning And Maintenance

    CLEANING THE WATER INTAKE FILTER The water intake filter A located at the outlet of the water supply tap needs to be cleaned periodically. After having closed the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it delicately under running water.
  • Page 34 CLEANING THE FILTER UNIT • It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; • push the centre filter D from the underside to remove it from the micro-filter: •...
  • Page 35 DISUSE: • Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. • Plug the power cord back into the socket.
  • Page 36 If there are visible traces of rust inside the tank: • the tank is made of steel, and therefore any rust marks are due to external elements (fragments of rust from the water pipes, pots, cutlery, etc.). Special products are commercially available to remove such marks;...

  • Page 37: Troubleshooting

    To “reset” an alarm is necessary: • Open and close the door, or turn off and on the machine. At this point is possible to program the dishwasher again. If the malfunction persists, contact your authorised Service Centre.
  • Page 38 820 mm to 890 mm Height (depending on models) from 860 mm to 930 mm Capacity 13 Standard place settings Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Electrical characteristics See rating plate...
  • Page 39 552,00 mm ATTENZIONE: montare la porta e regolare la tensione delle molle laterali prima dell’installazione. IMPORTANT: door template, do not destroy. Fit door and adjust hinge tension before installation. ATTENZIONE: montare la porta e regolare la tensione delle molle laterali prima dell’installazione. IMPORTANT: door template, do not destroy. Fit door and adjust hinge tension before installation.
