- Page 1 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Instructions of How to Disassemble the X7 Amp Module www.fiio.net...
-
Page 2: Tools Required
音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Tools required PH0 Cross Screwdriver, T5 screwdriver, Tweezers (tips wrapped with masking tap), Art Knife (blade wrapped with masking tape), Hot Air Gun www.fiio.net... - Page 3 All manuals and user guides at all-guides.com Born for Music and Happy Step 1. Separate the amp module from the X7 body Use the T5 screwdriver to remove the screws at the left/right sides of the amp module, then separate the amp module from the X7 body...
- Page 4 Note: the muzzle of the hot air gun should be put close to the heated spot, but not in touch with it (suggested to keep a distance of 1~5 mm). And the temperature should not be too high, otherwise it may cause damage to the plastic frame inside www.fiio.net...
- Page 5 Insert the tweezer tip slowly into the gap at Note: Please move the tweezer tip slowly when the right corner of the module (as marked inserting and be careful not to make any scratches on in the above image) until it’s getting the front cover 5~10mm deep www.fiio.net...
- Page 6 All manuals and user guides at all-guides.com Born for Music and Happy Step 4. Reheat the right side of the front cover Reheat the right side of the front cover (as marked in the above image) with hot air gun for 30 ~ 60 seconds www.fiio.net...
- Page 7 Insert the knife blade slowly into the gap beside the Note: Please move the knife blade slowly when tweezer tip until it's getting 5~10mm deep. After inserting and be careful not to break the plastic that take out the tweezer tip frame www.fiio.net...
- Page 8 Step 6. Reheat the front cover Heat both the left and right side of the front cover (as marked in the above image) with hot air gun for 1~3 minutes; In the mean time slowly move the blade around 5mm deeper into the gap www.fiio.net...
- Page 9 Move the blade slowly to the other side of the Note: If you find it difficult to move the blade, you module to separate the front cover from the may try to heat the front panel with hot air gun a plastic frame longer time www.fiio.net...
- Page 10 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Wear a pair of gloves then take off the front cover the front cover after taken off www.fiio.net...
- Page 11 All manuals and user guides at all-guides.com Born for Music and Happy Step 8. Disassemble the plastic frame and PCB Use the cross screwdriver to remove the 4 screws on the frame, then take off the frame and PCB from the shell www.fiio.net...
- Page 12 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Step 9. Separate the PCB boards Separate the two PCB boards www.fiio.net...
- Page 13 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Parts after disassembled www.fiio.net...
- Page 14 Clean the remained glue on the front cover Note: The remained glue should all be cleaned, and and plastic frame with the art knife, then be careful not to break the front cover or frame with wipe them with a cloth moistened by alcohol the knife www.fiio.net...
- Page 15 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy Assembly Step 2. Assembly the PCB First assemble the two PCB boards then install them to the frame by matching their locating holes www.fiio.net...
- Page 16 Install the frame & PCB to the shell by Note: It's suggested to fully check the functions of the matching their locating holes then lock the 4 amp module before proceeding to the next step screws with the cross screwdriver www.fiio.net...
- Page 17 Assembly Step 4. Stick the front cover to the frame Note: The mixing ratio of the A type glue and B type Put some AB glue to the old glue marks on glue should be close to 1:1 the frame www.fiio.net...
- Page 18 After as soon as possible. Otherwise it might be difficult to that tie up the module with rubber bands clean after it gets dry and keep for 15~20 minutes. www.fiio.net...
- Page 19 Born for Music and Happy Assembly Step 6. Final check 1. Check if there's any glue at the edges of the front cover 2. Check if the front cover is fixed 3. Check if all surfaces of the module are clean www.fiio.net...
- Page 20 音乐 乐无限 All manuals and user guides at all-guides.com Born for Music and Happy THE END… Thank you ! www.fiio.net...
