- Page 1 User Guide AXE5400 Wi-Fi 6E Bluetooth PCIe Adapter MA86XE REV1.0.0 1910080121...
- Page 2 Specifications are subject to change without notice. is a registered trademark of MERCUSYS TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from MERCUSYS TECHNOLOGIES CO., LIMITED.
- Page 3 CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. OPERATING FREQUENCY (the maximum transmitted power) 2400MHz-2483.5MHz(20dBm) 5150MHz-5250MHz(23dBm) 5250MHz-5350MHz(23dBm) 5470MHz-5725MHz(23dBm) 5945MHz-6425MHz(23dBm) RF Exposure Information...
- Page 4 Attention: This device may only be used indoors in Great Britain. EU declaration of conformity Mercusys hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2011 /65/EU and (EU) 2015/863.
- Page 5 · 清潔本產品之前請先拔掉電源線。 請勿使用液體、 噴霧清潔劑或濕布進行清潔。 · 注意防潮， 請勿將水或其他液體潑灑到本產品上。 · 插槽與開口供通風使用， 以確保本產品的操作可靠並防止過熱， 請勿堵塞或覆蓋開口。 · 請勿將本產品置放於靠近熱源的地方。 除非有正常的通風， 否則不可放在密閉位置中。 · 不要私自拆開機殼或自行維修， 如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 Equipment name 設備名稱：AXE5400 Wi-Fi 6E Bluetooth PCIe 型號（型式）：MA86XE Adapter 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚...
- Page 6 Safety Information Ǵ Keep the device away from water, fire, humidity or hot environments. Ǵ Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. Ǵ Do not use the device where wireless devices are not allowed. Ǵ...
- Page 7 Caution, risk of electric shock Energy efficiency Marking Protective earth Earth Frame or chassis Functional earthing Caution, hot surface Caution Operator’s manual Stand-by “ON”/”OFF” (push-push) Fuse Fuse is used in neutral N RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE).
- Page 8 Caution, avoid listening at high volume levels for long periods Disconnection, all power plugs Switch of mini-gap construction Switch of micro-gap construction (for US version) µ Switch of micro-gap / micro-disconnection construction (for other versions except US) ε Switch without contact gap (Semiconductor switching device)
-
Page 9: Table Of Contents
CONTENTS Conventions ....................... 01 Chapter 1 Introduction ..................02 Product Overview ..................... 02 1.1 Features ..........................02 Chapter 2 Installation Guide ................03 2.1 Hardware Connection ...................... 03 2.2 Driver Installation ......................04 Chapter 3 Connect to a Wireless Network ............06 Chapter 4 Pair With Bluetooth Devices ............07 Chapter 5 Uninstall Driver .................. -
Page 10: Conventions
Conventions The Adapter or MA86XE, or device mentioned in this User Guide stands for MA86XE AXE5400 Wi-Fi 6E Bluetooth 5.3 PCIe Adapter without any explanations. Note: Features of the adapter may vary by model and driver version. All images, steps, and descriptions in this guide are only examples and may not reflect your actual adapter experience. -
Page 11: Chapter 1 Introduction
Wi-Fi 6E devices, which prevents drops in speed and interference from legacy devices. Note: Please note: MA86XE is not compatible with the low-profile bracket because of the fixed antennas. Features Ǵ Unstoppable Tri-Band Speed — Speeds up to 2402 Mbps (6 GHz) + 2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz) -
Page 12: Chapter 2 Installation Guide
Chapter 2 Installation Guide Chapter 2 Installation Guide Before You Start If you plan on using Bluetooth and already have connected Bluetooth devices, skip to Step 2. proceed with Step 1. Otherwise, 1. Disable your Bluetooth a. Right-click My Computer, select Manage, go to Device Manager. b. - Page 13 Chapter 2 Installation Guide 3. Locate an available PCI-E slot (X1, X4, X8, or X16) and remove the corresponding slot cover on the rear panel. Then insert the adapter carefully. 4. Locate an available 9-pin connector and carefully plug the Bluetooth USB cable into it.
-
Page 14: Driver Installation
Windows. 1. Insert the CD and run the Autorun.exe. Tip: You can also check the new release and download the driver at www.mercusys.com/support. 2. Install the Wi-Fi and Bluetooth drivers. a. Wi-Fi: Click and follow the onscreen instructions to complete the Wi-Fi installation. -
Page 15: Chapter 3 Connect To A Wireless Network
Chapter 3 Chapter 3 Connect to a Wireless Chapter 3 Connect to a Wireless Network With both the hardware and software successfully installed into your computer, you can quickly connect to a wireless network via Windows wireless utility. The following instructions take Windows 10 as an example. The steps may vary slightly from other versions of Windows. -
Page 16: Chapter 4 Pair With Bluetooth Devices
Chapter 4 Chapter 4 Pair With Bluetooth Chapter 4 Pair With Bluetooth Devices MA86XE makes your PC Bluetooth-capable with ultra-fast Bluetooth 5.3 which achieves more stable connection, farther range and faster transmission speeds than Bluetooth 4. Just connect your Bluetooth devices to your computer and enjoy with ease. -
Page 17: Chapter 5 Uninstall Driver
• Uninstall Wi-Fi driver 1. Start Control Panel, go to Programs and Features, click Uninstall a program. 2. Find and uninstall the Mercusys program MERCUSYS MA86XE Wi-Fi Driver. 3. Follow the on-screen instructions to complete the uninstallation. 4. Restart your computer. -
Page 18: Appendix: Specifications
Appendix: Appendix: Specifications Appendix: Specifications Normal Wireless Standards IEEE 802.11a/b/g/n/ac/ax 2402 Mbps on 6 GHz Wi-Fi Speeds 2402 Mbps on 5 GHz 574 Mbps on 2.4 GHz 6 GHz: 11ax HE160 MCS0:-86 dBm 11ax HE160 MCS11:-56 dBm 5 GHz: 11ax HE80 MCS0: -90 dBm 11ax HE80 MCS11: -59 dBm 11a 54Mbps: -77 dBm Reception...
