Summary of Contents for Sunsky Realand M515
- Page 1 Face Recognition Time Attendance & Access Control Hardware User Manual Rev: 1.1...
-
Page 2: Table Of Contents
Content Chapter 1 Notice ......................4 Operating Environment ..................4 Notes for Installation ..................4 Chapter 2 Quick Guide ....................5 Product Diagram ....................5 User Verification ....................5 2.2.1 Face Verification ..................5 2.2.2 Password Verification .................. 6 2.2.3 Card Verification .................. - Page 3 Chapter 5 Settings ....................15 System ......................15 5.1.1 Basic ......................15 5.1.2 Advanced ....................16 Lock Control ..................... 17 Communication ....................17 Data Management .................... 20 Attendance Setting ................... 20 Chapter 6 FAQ ......................22 Cannot download the data via USB flash drive..........22 How to remove the manager? ................
-
Page 4: Chapter 1 Notice
Chapter 1 Notice Thanks for purchasing our Face Time Attendance & Access Control Terminal. Please refer to this user manual carefully before using, which helps you improve the efficiency of using this device. 1.1 Operating Environment Avoid installing the device at places where irradiated by strong light directly. The strong light affects the collecting of fingerprints that would lead to the failure of the fingerprint verification. -
Page 5: Chapter 2 Quick Guide
Chapter 2 Quick Guide 2.1 Product Diagram 2.2 User Verification 2.2.1 Face Verification The standing position as the picture is recommended. When verify, we recommend that the distance between the person and the device is 0.5m (accommodating the height range from 1.5m to 1.85m). -
Page 6: Password Verification
Noted: Wearing sunglasses Wearing a hat may and fringe may Recommended affect verification affect verification Unnatural expression Profile may affect may affect verification verification. 2.2.2 Password Verification Click the “LOCK” button → input the Enroll ID → Input Password → click “OK”. 2.2.3 Card Verification ○... -
Page 7: Basic Operation
[User] You could enroll user, edit user info and delete user info. [Setting] It includes five submenus: [Basic], [Advanced], [Comm.], [Data] and [Att]. [U-Disk] You could download the attendance log, user info and upload user info. [Lock Control] You could set Unlock Delay, Sensor Delay, Sensor Check, etc. - Page 8 Menu Click [ ], then you could enter [User], [Setting], [U-Disk], [Lock Control], [Log] or [System] menu according to your needs. Note: If the device has been registered admin, users need to be validated when enter the main menu. ...
-
Page 9: Chapter 3 User Management
Chapter 3 User Management Click [ ] and select [User] to enter the submenu, which includes [Enroll], [Edit] and [Delete]. 3.1 Verify There are three verification methods: Face/Card/Password, Face/Password and Face. Each user has a unique Enroll ID, which must be the same on the device and the desktop software. -
Page 10: Edit User
Name: We suggest that edit the user name on the software if there are a huge number of users. Level: There are 4 levels—User, Manager, Registrar and Querier. You could enroll no more than 10 administrators (Manager/Registrar/Querier). Note: When query a user information, you just need to input the far left digit of the Enroll ID. For example, when the Enroll ID is ‘000000050’, you just need to input ‘50’... -
Page 11: Chapter 4 Data Management
Chapter 4 Data Management 4.1 Delete Data 4.1.1 Delete User Information You could delete a user and delete all user. Delete a user: The details please view ‘3.4 Delete User’. Delete all user: Click [ ] → select [Setting] → select [Data] → select “Del. All User”. 4.1.2 Delete Records You could delete GLog (attendance records) and SLog (management/ operation records). -
Page 12: View Attendance Log
You could view the registered amount and the max capacity (Max User=10000; Max Card=10000; Max Password=10000; Max Face=1000). Log: It’s the amount of attendance records. Max = 100,000. Super Log: It’s the amount of administrator(s) entering the menu to operate. Max = 10,000. -
Page 13: Download
4.3.1 Download Download Attendance Log Down NewLog: It means to download the latest attendance logs since the last attendance logs you downloaded. If you have downloaded all logs, there is no data in this option. Down AllLog: It means to download all the attendance logs in this device. ... -
Page 14: Upload
The new attendance logs are saved in the file named “NewFlog_xxx_yyy.csv”. The new management logs are saved in the file named “HisGLog_xxx_yyy.csv”. “yyy” means the date & time you download the logs; “xxx” means the device No. 4.3.2 Upload ... -
Page 15: Chapter 5 Settings
Chapter 5 Settings 5.1 System 5.1.1 Basic Click [ ] → select [Setting] → select [Basic]. Item Description You could set the language as English or Language Chinese. You could calibrate date and time when Time they are incorrect. Turn it on and the device prompts when Voice verify. -
Page 16: Advanced
5.1.2 Advanced Click [ ] → select [Setting] → select [Advanced]. Item Description There three verification mode: FC/C/P, Verify Mode FC/P and FC. Max Mngr Max manager=10. Please view “4.3.3 Upgrade Firmware” for Upgrade FW more details. To reset all the settings to the default, but Factory reset... -
Page 17: Lock Control
the user info and logs won’t be deleted. Set a time to reset the device. For Reset time example, the reset time is 07:30:00, that means the device will reset at 07:30:00 every day when it plugs in. Sleep Time To set how long the device will be on sleep mode after no one operate it in order to save power. - Page 18 Note: Weak WIFI hotpot signal may cause failed connection. TCP/IP ○ 1 Plug in the Ethernet cable.
- Page 19 ○ 2 Click [ ] → select [Setting] → select [Comm.] → turn on DHCP. ○ 3 Confirm if the IP address of the device and the IP address of the PC are in the same network segment. You could test it via “PING”. ○...
-
Page 20: Data Management
5.4 Data Management Click [ ] → select [Setting] → select [Data]. Log Warning: The device prompts when the capacity of attendance log is equal to the setting value. The max capacity of attendance log is 100,000. SLog Warning: The device prompts when the capacity of Slog is equal to the setting value. - Page 21 [Att] You could set the time of six states--Duty On, Duty Off, In, Out, OT-On and OT-Out. You could set no more than 24 groups.
-
Page 22: Chapter 6 Faq
Chapter 6 FAQ 6.1 Cannot download the data via USB flash drive. Make sure the USB flash drive works. We suggest to use 2~8G USB flash drive. If there are any conflicted files, please format the USB flash drive. We suggest to use a specialized one for attendance data. - Page 23 ○ 3 When the device connected to the software successfully, click “Cancel Privilege”. If the bottom left shows “Operation Complete”, the admin is removed.
-
Page 24: Remove By Hardware
○ 4 If you need you enroll a new admin, please refer to the enrollment details above. 6.2.2 Remove by Hardware You could remove the admin privilege by pressing a key on the mainboard. Steps: Disassemble the device → press the button ‘KEY5’ on the mainboard → press ‘OK’ button...
