Scala SC 4280 Instruction Manual

Body Fat Scale SC 4280
instruction manual
1. Specifications:
1) High precision strain gauge sensor system.
2) Measuring range: 5 kg-180 kg (Unit: kg lb st:lb)
Remark: The scale would be switched on when a weight of 6 kg or more is
placed on it. After switching on, the minimum weight of this scale can
measured is 5kg. Resolution of the LC display: 100g
3) Power off: automatically after 10 seconds of no use
4) Indication of overload: Err
5) Indication of low batteries: Lo
6) Backlight LCD
7) Memory: 10 user memory (storage of personal data)
8) Measurement: Weight, body fat (%), body water (%), muscle (%), bone
substance, BMI and quantity of calories which you need per day.
2. About buttons:
SET: Mode button and press to confirm the data.
▲,▼: Press it to change the data during setting.
3. Battery installation:
a)
Before using the scale, check the battery
compartment and remove any plastic insulation
strips.
b)
If you are replacing the batteries, make sure
the positive and negative contacts are properly
aligned.
4. Change the unit:
With the switch in the battery compartment you
can change the unit.
5. How to measure the body weight:
1)
Use the scale on the flat, level surface. Do not
weigh on carpet as it may affect accuracy.
2) Step on the platform, once the weight is stabilized,
it will be locked data on the display.
3) The scale will turn off automatically after 10 seconds of no use.
6. Setting the Body Fat Scale SC 4280 according user data:
You can store data for 10 user.
If you use the scale for measurement the body weight only the following
settings are not necessary.
Note: The body fat scale must be power off.
Press the SET button and the personal code P0 will
being flash, Press "▲" or "▼" button to select a number
from P0 to P9 as your personal code, once you choose
your target number, please press "SET" button to
confirm.
Then the second flash is the Gender symbol, Press "▲"
or "▼" button to choose male or female, then press
"SET" button to confirm.
Then the third flash is "age", Press "▲" or "▼" button to
reach your own age, then press "SET" button to confirm.
The last flash is height, Press "▲" or "▼" button to reach
your target height then press "SET" button to confirm;
i.e. your height is 172cm.
Please note if you choose weight in KG, your height unit
is "cm"; if weight in lb, the height is in ft:in. Now the setting
is finished.
7.
How to measure Weight, body fat(%), body water(%), muscle(%), bone
substance, BMI and quantity of calories which you need per day:
Use the scale on the flat, level surface. Do not weigh on carpet as it may affect
accuracy.
1. Press the SET button and choose (with "▲" or "▼" button) your personal
code. The LC display shows step by step your personal data (gender, age,
height).
2. When the LC display change to 0,0 kg, step on the scale gently and keep
your bare feet in touch with the electrodes, not moving.
The LC display will show your weight, then it is the flash
fat (%), body water (%), muscle (%), bone substance, BMI and quantity of
calories which you need per day will be displayed on the LCD within seconds.
, then body
