PLM Series Precision Leveling Mount
Safety notices
Please carefully read through these instructions before installing and commissioning the air spring
system and keep them for future reference.
If any questions arise at this point or if clarification is required, do not commission the air spring
system and instead first contact
Failure to comply with this instruction manual can cause the PLMs to burst and lead
to injury (risk of crushing).
Applicable national legislation has priority over these instructions.
If the equipment is installed by the customer, ACE shall not be held liable for any
installation and assembly mistakes and the damage that could result.
Explanation of icons
IMPORTANT NOTES:
o Do not inflate PLM isolation mounts unless static weight of equipment is placed on
the mounts
o Do not use PLM isolation mounts under static loads greater than the indicated
maximum (see Chart B).
o Do not pressurize PLM isolation mounts above indicated maximum pressure. Check
pressure with pressure gauge. (See Chart B)
o Completely deflate isolation mounts before moving or relocating equipment.
o Support base of machine should be level and horizontal.
info@ace-int.eu · www.ace-ace.com
Operating/Installation Instructions
ACE Stoßdämpfer GmbH.
T +49 (0)2173-9226-20
Safety and maintenance information
Attention: Risk of crushing!
Attention: Risk of bursting!
Rev. 2
1/6
22_23_0171 / Stand 10.2023
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for STABILUS ACE PLM Series
- Page 1 PLM Series Precision Leveling Mount Operating/Installation Instructions Safety notices Please carefully read through these instructions before installing and commissioning the air spring system and keep them for future reference. If any questions arise at this point or if clarification is required, do not commission the air spring ACE Stoßdämpfer GmbH.
-
Page 2: Intended Purpose
INTENDED PURPOSE: The properly use of the PLMs is the vibration isolation from microscopes, optical equipment, and similar equipment. The PLM isolation mounts are not usable as dynamic dampers! INSTALLATION: 1. Support base of machine should be level within ±1mm (± 1/32”) before inflating isolation mounts. - Page 3 5. If the isolation mount has a Schrader valve, the air will flow in and out the PLM by pushing the valve. 6. Sequentially pressurize each mount through valve until dimension "X" is 1,6mm (1/16”) (see drawing on page 5). 7.
-
Page 4: Maintenance & Disposal
UNINSTALLATION 1. Completely remove air from all isolation mounts. 2. Move, relocate, or change static weight. MAINTENANCE & DISPOSAL: The PLM isolation mounts are maintenance-free. The pressure must get controlled occasionally. We recommend a moist cloth with neutral PH cleaner for cleaning the PLM. No sand-, chloride- or acidic cleaner and solvents. - Page 5 Dimensions in mm Chart A □A in mm □B in mm C Metric C Inch ØD in mm H in mm Adjustment Selectable Selectable (Working Height) range in mm PLM1 76,2 60,3 3/8-16 62,5 ±3 PLM3 106,4 88,9 ½-13 63,5 ±3 PLM6 130,2...
-
Page 6: Operating Information
Operating information Chart B Max. load Max. Pressure lbs. PLM1 PLM3 PLM6 PLM12 1,212 PLM24 1.100 2,425 PLM48 2.200 4,850 PLM96 4.400 9,700 PLM192 8.800 19,400 ACE Stoßdämpfer GmbH Albert-Einstein-Straße 15 40764 Langenfeld Germany T +49 (0)2173-9226-20 info@ace-int.eu www.ace-ace.de Rev. 2 info@ace-int.eu ·...
