Summary of Contents for Hartke HyDrive HL Series
- Page 1 HyDrive HL Series Bass Cabinets Owner's Manual...
- Page 2 By doing so you will ensure that your disposed product under- goes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health. Hartke ©2021, V1.1 278-B Duffy Ave Hicksville, NY 11801 Phone: 1-800-372-6766 www.hartke.com...
- Page 3 We appreciate your business and congratulate you on purchasing a Hartke HL Series cabinet. Welcome to the Hartke family! Before you plug in and start playing we suggest you take a seat and read through this quickstart guide. The HyDrive HL series is our first generation of lightweight bass speaker enclosures featuring Hartke’s patented HyDrive hybrid cone bass speakers with Neodymium...
- Page 4 NOTE: Never connect more than one amplifier to a HyDrive HL series enclosure. This will damage the speaker cabinet and void the warranty. NOTE: Use only unshielded speaker wire with a gauge of 12 – 18 AWG. Do not use shielded instrument cables when connecting an amplifier to a speaker cabinet or when connecting an extension cabinet.
-
Page 5: About Impedance
Hartke HyDrive HL speaker cabinet input jacks are parallel connections. The formula to calculate the total impedance of a parallel speaker system is: 1/Rt = 1/R1 + 1/R2 + 1/R3 + …... -
Page 6: Specifications
Specifications HL410 Description 4 x 10” Bass Cabinet Power Handling 1000 Watts RMS Impedance 8 Ohms LF Drivers 250 watt, 10”, paper/aluminum hybrid cones with neodymium magnets HF Driver 1” Tweeter HF level control 3-position switch (0,-6dB, Off) Frequency Response 45Hz - 17kHz -3dB -10dB LF Response 30Hz... - Page 7 Black perforated steel Weight 24.9lb 11.3kg Dimensions (H/W/D) 16.5” x 19.2” x 15” 421.5mm x 489mm x 383mm At Hartke we are continually improving our products, therefore specifications and images are subject to change without notice. HyDrive HL Series Cabinets...
- Page 8 278-B Duffy Ave Hicksville, NY 11801 Phone: 1-800-372-6766 www.hartke.com...
