Summary of Contents for Reno PEDESTAL
- Page 1 PEDESTAL Installation www.renoevc.com sales@renoevc.com 905-604-4666...
-
Page 2: Table Of Contents
• The evse charging station is to be connected to a grounded, metal, permanent wiring system. 5.1.2 Pedestal Installation ..........7 The evse pedestal is to be connected to a separate ground conductor run and connected to the 5.1.3 Mounting the charging station ........9 grounding lug at the pedestal mounting pole. -
Page 3: Mounting The Base
3. Concrete Base Requirements Step1 Step1 Prepare the Concrete Base Mark the 4 holes on the concrete foundation using the base-plate of the pedestal. Make sure that the connection cable is located precisely underneath the opening in the base-plate. 15.75 in (400 mm) Step2 Drill the 4 mounting holes: Diameter 10mm;... -
Page 4: Anchoring
USER MANUAL USER MANUAL 4. Anchoring 5. Installation Fix the pedestal（Lower Part）to the concrete foundation with 4 sets of M8*100mm expansion screws 5.1 Pedestal Installation 5.1.1 Packing list Single Back-to-back Side-by-side Version Version Version Description QTY.(PCS) QTY.(PCS) QTY.(PCS) Pedestal（Middle Part）... -
Page 5: Pedestal Installation
Notice: the positional ordering of spring washer and flat Washer Step2 Release the 8pcs of M5*18mm screws of the wiring window at the back， connect the ground wire to the terminal inside the Pedestal Step3 Insert one cable gland to the pedestal for single pedestal properly. -
Page 6: Mounting The Charging Station
5.1.3 Mounting the charging station Step1 For back to back version： Take off the wall-mounted bracket , and fix it in the corresponding position on the pedestal with 4 pcs of M8*18mm screws. For side by side version： ①Take off the wall-mounted bracket , and fix it in the corresponding position on the side by side Step7 bracket with 8 pcs of M8*18mm. -
Page 7: Connecting
Single Back-to-back Side-by-side Step1 Version Version Version Description Thread the connection cables from the bottom through the pedestal upwards through the wiring QTY.(PCS) QTY.(PCS) QTY.(PCS) window. Pedestal (Upper Part) Step2 Pedestal (Lower Part) Perform the electrical connection and commissioning in accordance with the instructions in the "User Cable retractor manual"... - Page 8 Description QTY.(PCS) QTY.(PCS) QTY.(PCS) Metal Cover（For NPT） Metal Cover：φ50.3 Metal Cover：Unhole PEDESTAL Installation M50 Sealing Cover M8 External Tooth Lock Star Washer Cable Clamp Installation Toolkit Adapter M5*18 Countersunk head screws Check the box to ensure you have this installation guide and these parts: www.renoevc.com...
-
Page 9: Upper Part Installation
Step7 Insert the pedestal(Middle Part)into the Lower Part with Attach the adapter to the Pedestal ( Middle Part) with 4 sets of M6*18mm screws with spring washer 4 sets of M6*18mm screws with spring washer and flat and flat washer. - Page 10 USER MANUAL Step8 Step10 Insert the pedestal(Upper Part) with cable management system into the Middle Part with Positioning the cable clamp. 4 sets of M6*18mm screws with spring washer and flat Washer. （1）Determine where to position the charging station cable clamp (Please choose the suitable cable steeve, which is marked the size inside cable steeve).Recommendation: The cable portion...
-
Page 11: Bracket Installation
8 pcs of M8*18mm screws. Step2 Fix side-by-side bracket on to the Middle Pedestal with 4pcs of M8*18mm screws with spring washer and flat washer. Notice：Add an M8 External Tooth Lock Star Washer to any of the 4 sets of M8 screws. -
Page 12: Connecting
USER MANUAL USER MANUAL 5.2.5 Connecting 6.Warranty Step1 LIMITED 1 YEAR WARRANTY AND EXCLUSIONS Joint warrants to the original consumer purchaser and not for the benefit of anyone else that this Perform the electrical connection and commissioning in accordance with the instructions in the product at the time of its sale by Joint is free of defects in materials and workmanship under normal "User manual"...
