Summary of Contents for Global CB 300S
- Page 2 Thank you for purchasing Auto Tape DispenserCB-300S. CB-300S is a compact, unique feeding system which allows to many kinds of tape, includes minimum size of thin tapes. Please read this Instruction Manual carefully. For your safety, please keep this Instruction Manual for reference, retrain- I ng and trouble shooting.
- Page 3 Indicates a potentially hazardous situation which if not avoided, could result in death or serious injury Indicate that carelessness of handling may resui danger and that the operator is at risk of injury, or the machine is at risk of damage. Indicates Caution A symbol within the triangle, or the description, will indicate a specific hazard.
- Page 4 Do not plug in, unplug the cord, or operate the machine with wet hands. Failure to observe this may result in injury due to electric shocks. Never insert your finger, or any other body part, or any foreign object into the machine. Failure to observe this may result in injury.
- Page 5 Identification of Parts \, Brake lever Guide set Guide roller Guide plate Front cover Switch panel � Main cover Knife set Tape outlet Auto senser Discharge guide Parts of the switch panel Auto/Manual button Display Tape feeding roller ... � Tape seat button Start button...
- Page 6 ■ ■ ■ ■ Loading the Tape Roll '\ ■ Insert the AC cord into the inlet of the main body. AC Cord Inlet ■ Plug in the earth terminal. ■ Turn off the product and plug in. ■ Turn on the product. ��...
- Page 7 ■ ■ ◊ Setting the Tape Length \ -, n ■ Check if the length you want is displayed. :., LI ◊ "'The length to cut tape is displayed with A to F and numbers. 0 R-F Set the length to cut tape. i<>b<>c <>d<>E <>F :.;.·Set the length by pressing the + or - button...
- Page 8 Cutting the number of tape set is finished, the buzzer informs you. This mode is available automatically and manually. Setting is available up to 999. Select the cutting length desired (A to F) by pressing the Select button. Push the Select button more than I sec, Leon is displayed. The Select button push briefly again, P mode is on.
- Page 9 Raise the guide set by pressing the guide set button. Widen it by pushing the brake lever of the guide set. Close the guide set. When the tape is curled up in spite of using the brake roller, hold it stronger using the width controller. : ., The lengths of cutting and setting might be different depending on the type of tape or conditions of use.
- Page 10 The Cutter unit is a consumable item. Replace the cutter unit if cutting condition worsens . Turn off the product first . Raise and separate the Cutter unit by pulling the cutter holder to the front. w Check if the lower side of the new cutter is parallel to the outlet. w If it is not, push it up to the lower end by using a screw driver and so on.
- Page 11 ■ ■ ■ ■ ■ ■ Checking and replacing the roller \, The roller which is damaged or cannot be used any more can be easily exchanged. Refer to the following when the tape is stuck at the outlet or not rolled out smoothly. ■...
- Page 13 Malfunction Please check the following before deciding the product is out of order. " Not working with eChed< if the cord is connected r i(jit. eAC cord disconnection. the power on. eReplace the fuse to new one. If the eFuse disconnection. fuse disconnection continues, stop using the product.
- Page 14 AUTO TAPE DISPENSER CB .. JOOS 000. 5241) {525 �...
- Page 15 /(9�� � � �r � �- 4061) � l4110 ,...--.. 4071...
- Page 16 0 ;) · · : . NUMBER PARTS NAME FIGURE NUMBER PARTS NAME FIGURE .:-· Body Cover The blade components 1121 •.. 2070/2110 <.,/: - i , .• : �:>;..-' (!· '-_ c \ . �;? 1111 Front cover 2120 Upper Knife Fix Plate Spring -·...
- Page 17 10\)t, W l ._ ,1J' NUMBER PARTS NAME FIGURE NUMBER PARTS NAME FIGURE " \ � , Cushion Rubber(A) Knife Main Gear (_ · _ - � ) 3140 4031 ,i>f "l , J ,. "·�-- -�- - Knife Gear Bearing �) Tape Wide Control Plate ..
- Page 18 ·1- v-l ' • NUMBER PARTS NAME PARTS NAME FIGURE NUMBER FIGURE ,'\'." • : J · r · , 0 fJ; Rugged Roller Bushing 4190 5071 Driver board i_ . � . . ·1..1 f�\;1 •1 4090(-1) The left clamp 5080 �...
- Page 19 IJUMBER PARTS NAME FIGURE NUMBER PARTS NAME FIGURE �� Tape Regulating Plate 6041 6320 Side Frame PCB Cable " '= � � f:, Tape Guide Frame Set 6060 Brush 7000 � t � ' Tape Support Roller A 7010 Tape Guide Frame (A) If �' , , "...
