- Page 1 AUTOOL C100 Fuel System Cleaner User Manual www.autooltech.com...
-
Page 3: Copyright Information
AUTOOL. The information contained herein is designed only for the use of this unit. AUTOOL is not responsible for any use of this information as applied to other units. ●... - Page 4 ● Manual are either trademarks, registered trademarks, service marks, domain names, logos, company names or are otherwise the property of AUTOOL or its affiliates. In countries where any of the AUTOOL trademarks, service marks, domain names, logos and company names are not registered, AUTOOL claims other rights associated with unregistered trademarks, service marks, domain names, logos, and company names.
- Page 5 CAUTIONS Warning ● Wear protect gloves and cloth when operating. Must stop engine if there have any fuel leak! ● Bind up the pipe as disconnect the pipe to avoid splash and fire. ● Please prepare at least a fire extinguisher when doing on-vehicle cleaning.
- Page 6 See Fig.01. ● Connect the disconnected other ends (A, D) with proper hose, or remove the fuel pump fuse, or disconnect the power cable of engine fuel pump. Fig.01 C100 Injector Engine Cleaner & Tester Fuel-return hose Fuel-inlet hose from engine...
- Page 7 Engine fuel supply hose Auto filter Engine fuel return hose Auto fuel pump Auto tank Without return hose connecting The hose line connection of theengine without returnhose is shown as in Fig.02. ● Disconnect the fuel supply hoses (E, F) of engine fuel system (wrap the connector when disconnecting the connector), and then choose a proper connector and connect it to the E end.
- Page 8 C100 Cleaner & Tester Engine Fuel-inlet hose Stopper to engine Auto filter Auto tank Engine fuel supply hose Auto fuel pump...
- Page 9 Pour the mixture of gasoline and detergent into steel bottle of the C100. ● Close the valve of C100’s fuel-outlet pipe and open the valve of C100’s air-inlet port and then connect to the compress air. Adjust the pressure of air within 0.3 to 0.4MPa ( 3 to 4kgf/cm2 ) by air control valve.
- Page 10 Valve and Air Pressure Regulating Valve to keep the air pressure as zero. ● Connect the TWC Flushing Kit to the output pipe of the C100. ● Disconnect the Intake Vacuum Pipe which near the throttle and insert the TWC Flushing Nozzle into Intake Vacuum Pipe as shown.
- Page 11 Adjust the air pressure to about 0.5MPa ( 5kgf/cm2 ) and then close the Ball Valve of air inlet port. ● Connect the spray nozzle kit to the fuel outlet port of the C100. ● Remove the pipe ahead of throttle before flushing as shown.
- Page 12 ● Put the spray nozzle kit in the throttle body as shown and start the engine. And then open the Ball Valve of fuel outlet port. ● Keep the engine speed up to 1000 rpm and press the accelerator every 3~5 minutes to make the engine speed up to 2000~3000 rpm and keep this state for 30seconds.
- Page 13 Caution It must initialize the Throttle Position Sensor by automo- tive scan tool after cleaning. Otherwise the fault indicat- ing lamp will lighten on, and PCM will record a DTC.
-
Page 14: Maintenance & Service
MAINTENANCE SERVICE ● Our products are made of long-lasting and durable mate- rials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspection work, which ensures that each product has excellent quality and performance. Maintenance To maintain the performance and appearance of the product, it is recommended that the following product care... - Page 15 ● Regularly clean and replace consumable parts such as oil pump and oil filter; adjust the clearance of various parts and replace worn (broken) parts. Avoid contact with corrosive liquids. ● When not in use, please store the product in a dry place. Do not store the product in hot, humid, or non-ventilated places.
-
Page 16: Warranty
The repair or replacement of products is determined by ● the actual breakdown situation of product. ● It is guaranteed that AUTOOL will use brand new compo- nent, accessory or device in terms of repair or replace- ment. ● If the product fails within 90 days after the customer... - Page 17 We AUTOOL pride ourselves on superb design and excel- lent service. It would be our pleasure to provide you with any further support or services. Disclaimer ● information, illustrations, specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice.
- Page 18 RETURN & EXCHANGE SERVICE Return & Exchange If you are an AUTOOL user and are not satisfied with the ● AUTOOL products purchased from the online authorized shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;...
- Page 19 China 400-032-0988 Oversea Zone +86 0755 23304822 E-mail aftersale@autooltech.com Facebook https://www.facebook.com/autool.vip YouTube https://www.youtube.com/c/autooltech...
