dtm Galactic User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Galactic
F U N C T I O N O F R E M OT E A S S I G N I N G O F R E M OT E C O N T R O L S
user manual
v.1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Galactic and is the answer not in the manual?

Questions and answers

Summary of Contents for dtm Galactic

  • Page 1 Galactic F U N C T I O N O F R E M OT E A S S I G N I N G O F R E M OT E C O N T R O L S user manual v.1.2...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS GENERAL INFORMATION ..................... 3 1.Principle of operation of Galactic function ..........3 ELEMENTS OF GALACTIC SYSTEM ................4 I. GPROG PROGRAMMER ................4 1. Principle of operation ................4 2. Technical data ..................4 3. Elements of the programmer ..............4 4. Connecting to the computer ..............4 II.

  • Page 3: General Information

    Assigning the remote control with Galactic function is based on the compliance verification of the so called authentication code of the remote with the authentication code set in the radio receiver.

  • Page 4: Elements Of Galactic System

    ELEMENTS OF GALACTIC SYSTEM I. GPROG PROGRAMMER 1. PRINCIPLE OF OPERATION GPROG programmer is a device which allows for wireless programming of the remote controls with Galactic function. 2. TECHNICAL DATA power supply operating range 2-3 cm external case size 55x20x90 mm 3.

  • Page 5: Gsoft Programme

    - it is required to install .net framework version 4.0 or newer 3. INSTALLATION AND START-UP Download the GSOFT program from the producer's website www.dtm.pl. Run the Gsetup.exe installation file. During the installation proceed according to the guidelines of the programme installer.
  • Page 6 Fig. 3 View of the main window of GSOFT programme with the information about the lack of connection of the GPROG programmer. It is recommended to update the software to the latest version of the GSOFT program available on the manufacturer's website www.dtm.pl.

  • Page 7: Programme Main Window

    4. PROGRAMME MAIN WINDOW Fig. 4 View of GSOFT programme main window with function description. “Programming” with the icon informing about the connection or lack of connection. “Profiles list” enables creating profiles databases. “Remote programming” button starts remote control programming operation. “Bank”...
  • Page 8 Remote model selection field. “Authentication code” field to write in authentication code. Table of remote control buttons and receiver channels connection. Marking the fields assigns remote buttons to the channels. Information field. It displays notices about current status of programme and programmer.

  • Page 9: Programme Functions

    If the user is not in the main window it is necessary to choose “Programming” (fig.4 pt 1). Remote control with Galactic function gives the possibility to sign in the memory from one to three authentication codes together with configuration of buttons and channels connections. The choice of appropriate bank enables data edition.

  • Page 10: Remote Control Programming Manual Configuration

    5.1.1. REMOTE CONTROL PROGRAMMING - MANUAL CONFIGURATION Put the remote control with Galactic function on shown place on the GPROG programmer. Choose “Custom profile” in the “Profile selection” field. Choose appropriate remote in “Remote selection”. Enter authentication code that consists of 4 letters or digits from 0-9 and A –...

  • Page 11: Remote Control Programming Profile Choice

    5.1.2.REMOTE CONTROL PROGRAMMING - PROFILE CHOICE Put the remote control with Galactic function on shown place on the GPROG programmer. Choose one of available and earlier configured profiles in the “Profile selection” field. Profile configuration – pt 5.2 In the case of many configured profiles, you can use the search engine window by entering the search phrase of a previously configured profile.

  • Page 12: Deleting Remote Control

    5.1.3. DELETING REMOTE CONTROL MEMORY Put the remote control with Galactic function on shown place on the GPROG programmer. Press “Delete remote” button. Deleting the memory of remote control is signaled by the notice “DELETING SUCCESSFUL” shown in information window.

  • Page 13: Profiles List

    5.2. PROFILES LIST To increase the comfort of using the programme it was equipped with module for simple creating and managing the profile database. It allows the user to use ready profile by choosing “Profile selection” when they want to programme particular remote control. 5.2.1.

  • Page 14: Profile Edition

    5.2.2. PROFILE EDITION Go to adding and editing profiles window by clicking “Profiles list” icon (fig.4 pt 2). Specify on the profiles list which profile is to be edited. Double click on the profile shown or click “Editing profile” icon. Editing profile window is opened.

  • Page 15: Profiles Databases

    5.3. PROFILES DATABASES GSOFT programme enables to create profiles databases. The user has the possibility to create many profiles databases, exporting and importing data from the files. 5.3.1. CREATING NEW PROFILES DATABASE Go to adding and editing profiles window by clicking “Profiles list” icon (fig.4 pt 2). Click “New database”...

  • Page 16: Profiles Database Export

    5.3.2. PROFILES DATABASE EXPORT The user has the possibility to export active profiles database to the new file. Go to adding and editing profiles window by clicking “Profiles list” icon (fig.4 pt 2). Click “Export” button. Window “Save as” appears. It is necessary to specify the location and enter the name of the file in the “Save as”...

  • Page 17: Profiles Database Import

    5.3.3. PROFILES DATABASE IMPORT “Import” option is used to read into the programme data from other, earlier created and exported profiles database. Go to adding and editing profiles window by clicking “Profiles list” icon (fig.4 pt 2). Click “Import” button. Window “Open” appears.

  • Page 18: Programme Access Security

    5.4. PROGRAMME ACCESS SECURITY To ensure protection against access of unauthorized people, the programme gives the possibility to set the password. It is switched off as default. 5.4.1. SETTING THE PASSWORD Click “Options” button (fig.4 pt 11). Window of password setting appears. Mark “...

  • Page 19: Changing The Password

    5.4.2. CHANGING THE PASSWORD Click “Options” button (fig.4 pt 11). Window of password setting appears. When the password is set, “Require a password when the programme starts” option box is marked and instead “Set password” it is visible “Password change” field where it is possible to change the password by giving old password and writing the new password twice.

  • Page 20: Remote Control With Galactic Function

    To assign programmed remote with the use of Galactic function it is necessary to press and hold in the receiver radio range any two remote buttons for five seconds. The remote control transmits adding packet once.

  • Page 21: Practical Galactic Function

    PRACTICAL GALACTIC FUNCTION To administer inhabitants access comfortably the installer can use the Galactic function by properly setting authentication codes of the receivers. The example of such usage of the Galactic function is shown on the scheme below. BLOCK 1 BLOCK 2...
  • Page 22 group 2 - underground garage UG2 and gate G2 – authentication code of both receivers ABCD group 3 – car park on the grounds of the complex and gate G3 – authentication code 11AA Inhabitants of block B1 receive remote controls programmed with the codes of groups 1 and 3. Thanks to this solution they have access to gate G1, underground garage UG1 and gate G3 to the common car park.
  • Page 24 D T M S y s t e m h e r e b y declares that the device complies with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following website: DTM System ul. Brzeska 7, 85-145 Bydgoszcz, Polska, tel. +48 52 340 15 83, www.dtm.pl...
