  • Page 1 WVD-A09T1WK14B WINIA Notice utilisation lave-linge WINIA WVD-A09T1WK14B Washing Machine / User Manual WVD-A09T1WK14B Informations techniques de votre appareil: - Liste des pièces détachées - Schéma électrique - Manuel de service WVD-A09T1WK14B...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...

  • Page 3: Table Of Contents

    CONTENTS 1. SAFETY INSTRUCTIONS ....................1 1.1 General Safety Warnings ....................2 1.2 During Use ........................7 1.3 Packaging and Environment...................8 1.4 Savings Information ......................8 2. TECHNICAL SPECIFICATIONS ..................10 2.1 Technical Specifications ....................10 3. INSTALLATION ........................11 3.1 Removing the Transit Bolts...................11 3.2 Adjusting the Feet / Adjusting Adjustable Stays............

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS Operating voltage / frequency (220-240) V~/50Hz Total current (A) Water pressure (Mpa) Maximum 1 Mpa / Minimum 0. 1Mpa Total power (W) 2200 Maximum washing capacity (dry laundry) (kg) • Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base.

  • Page 5: General Safety Warnings

    You can download a copy of this user manual, directly from our WINIA website, at the following address: “ https://winia.fr ”. All you have to do is select the model of your device and then go to the download tab.
  • Page 6 put softener or detergent in the drawer at the beginning of each wash. • Unplug your Washing Machine and switch off the water supply if the Washing Machine is left unused for a long time. We also recommend that you leave the door open to prevent build up of humidity inside the Washing Machine.
  • Page 7 • Please follow the manufacturers’ instructions regarding the use of fabric conditioner or any similar products that you intend to use in your Washing Machine. • Make sure that the door of your Washing Machine is not restricted and can be opened fully. Install your machine in a location that can be fully ventilated and preferably has constant air circulation.
  • Page 8 RISK OF DEATH FROM ELECTRICAL CURRENT • Do not connect your Washing Machine to the mains electricity supply using an extension lead. • Do not insert a damaged plug into a socket. • Never remove the plug from the socket by pulling the cord.
  • Page 9 machine. • Please ensure that garments loaded into your Washing Machine are free from foreign objects such as nails, needles, lighters and coins. Risk of fire and explosion Risk of falling and injury • Do not climb on your Washing Machine. •...

  • Page 10: During Use

    1.2 During Use • Keep pets away from your machine. • Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 11: Packaging And Environment

    Specifications for the machine may vary NOTE: depending on the product purchased. Replacement of drive belt, only by authorized service. Only original spare belt must use. 1.3 Packaging and Environment Removal of packaging materials Packaging materials protect your machine from any damage that might occur during transportation.
  • Page 12 CE Declaration of conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 13: Technical Specifications

    2.1 Technical Specifications 2. TECHNICAL SPECIFICATIONS Operating voltage / (220-240) frequency V~/50Hz (V/Hz) Total current Maximum: Water 1 Mpa pressure Minimum : (Mpa) 0.1 Mpa Total power 2200 Maximum dry laundry capacity (kg) Spinning revolution 1400 (rev / min) Programme number General Appearance 1.

  • Page 14: Installation

    3.2 Adjusting the Feet / 3. INSTALLATION Adjusting Adjustable Stays 3.1 Removing the Transit Bolts 1. Do not install your machine on a surface (such as carpet) that would prevent ventilation at the base. To ensure silent and vibration-free • operation of your machine, install it on a firm surface.

  • Page 15: Water Inlet Hose Connection

    The mains cord of your washing should be connected to cold water inlet • machine is equipped with an earthed and red capped hose to the hot water plug. This plug should always be inlet (if applicable). inserted to an earthed socket of 10 To prevent water leaks at the joints, •...

  • Page 16: Water Discharge Connection

    3.5 Water Discharge Connection 4.1 Detergent Drawer (*) Connect the water drain hose to a • standpipe or to the outlet elbow of a household sink, using additional equipment. Never attempt to extend the water drain • hose. Do not put the water drain hose from •...

  • Page 17: Sections

    4.2 Sections 4.3 Program Dial Main wash detergent compartment: This compartment is for liquid or powder To select the desired programme, turn detergents or limescale remover. The fluid • the programme dial either clockwise or detergent level plate will be supplied inside anti-clockwise until the marker on the your machine.

  • Page 18: Using Your Washing Machine

    curtains or place them in a washing net 5. USING YOUR or bag. WASHING MACHINE 6. Reverse textiles such as pants, knitwear, t-shirts and sweat shirts. 5.1 Preparing Your Laundry 7. Wash socks, handkerchiefs and other small items in a washing net. Can be Normal washing...

  • Page 19: Adding Detergent To The Machine

    The following table shows approximate Put softener in the middle compartment • weights of typical laundry items: of the detergent drawer. Do not exceed the MAX level. LAUNDRY TYPE WEIGHT (gr) Thick softeners may cause clogging of • Towel the drawer and should be diluted. Linen It is possible to use fluid detergents in •...

  • Page 20: Additional Functions

    (*)Machinery specifications may vary 3. Delay Timer (*) depending on the product purchased. 5.7 Additional Functions 1. Temperature Selection Use the washing water temperature adjustment button to alter the automatically programmed washing water temperature. Auxiliary function button 3 Delay Timer You can use this auxiliary function to delay the start time of the washing cycle for 1 to 23 hours .
  • Page 21 4. Anti- Allergic(*) 7. Extra Rinse(*) Auxiliary function button 3 Anti- Allergic Auxiliary function button 3 Extra Rinse You can add an additional rinse operation to You can add an additional rinse operation your laundry using this additional function. Your machine will carry out all rinsing steps to the end of the selected wash programme using this additional function.

  • Page 22: Child Lock

    9. No Spin(*) Start/Pause button Auxiliary function button 3 No Spin If you don’t want to perform wringing on By pressing on the Start/Pause button, your laundry, you can use this auxiliary you may start the programme you have function. You may make the programme selected or suspend a running active by pressing the wringing cancel programme.

  • Page 23: Cancelling The Programme

    5.9 Cancelling the Programme To cancel a running programme at any time: 1. Turn the programme dial to the “STOP” position. 2. Your machine will stop the washing operation and the programme will be cancelled. 3. Turn the programme dial to any other programme to drain the machine.

  • Page 24: Programme Table

    6. PROGRAMME TABLE Laundry type / Descriptions Programme Very dirty, cotton and flax textiles. (Underwear, linen, tablecloth, towel COTTON *60-90-80-70-40 (maximum 4.5 kg), bedclothes, etc.) Dirty cotton and flax textiles. (Underwear, linen, tablecloth, towel ECO 40-60 *40 - 60 (maximum 4.5 kg), bedclothes, etc.) Dirty cotton and flax textiles.
  • Page 25 NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF LAUNDRY, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. (*) Washing water temperature of the programme is the factory default. (**) If your machine has the rapid wash auxiliary function, you can enable the quick wash option on the display panel and load the machine with 2 kg or less laundry to wash it in 30 minutes.
  • Page 26 • The most efficient programmes in terms of energy consumption are generally those that perform at lower temperatures and longer duration. • Loading the household washing machine up to the capacity indicated by the manufacturer for the respective programmes will contribute to energy and water savings.

  • Page 27: Important Informations

    6.1 Important Informations • Use detergents, softeners and other additives suitable for automatic washing machines only. Excessive foam has occurred and automatic foam absorption system has been activated due to too much detergent usage. • We recommend that periodic cleaning for washing machine every 2 months. For periodic cleaning please use Drum Clean programme.

  • Page 28: Cleaning And Maintenance

    7.2 Water Inlet Filters 7. CLEANING AND Water inlet filters prevent dirt and foreign MAINTENANCE materials from entering your machine. We recommend that these filters are cleaned when your machine is unable to receive 7.1 Warning sufficient water, although your water supply is on and the tap is open.

  • Page 29: Pump Filter

    7.3 Pump Filter meet the holes on the front panel side. 6. Close the filter cover. WARNING: The water in the pump may be hot, wait until it has cooled down before carrying out any cleaning or maintenance. (*) Specifications may vary depending on the machine purchased.

  • Page 30: Body / Drum

    any softener residue. Refit the flush 8. Body / Drum stopper after cleaning and check that it is seated properly. 1. Body Use a mild, non-abrasive cleaning agent, or soap and water, to clean the external casing. Wipe dry with a soft cloth. 2.

  • Page 31: Troubleshooting

    9. TROUBLESHOOTING Repair of your machine should be carried out by an authorised service company. If your machine requires repair or if you cannot solve an issue with the information provided below, then you should: Unplug your machine from the mains power supply. •...

  • Page 32: Automatic Fault Warnings And What To Do

    FAULT POSSIBLE CAUSE TROUBLESHOOTING Increase the amount of detergent following the Hard water. manufacturer’s instructions. Unsatisfactory washing result. Your laundry is too tightly packed Check that your laundry is spread out. together in the drum. As soon as the machine is The end of water drain hose is too Check that the drain hose is at a suitable height.
  • Page 33 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 34 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 35 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 36 WINIA Co., Ltd. 559, Yonga-ro, Gwangsan-gu, Gwangju, Korea ( du Sud) Importateur WINIA ELECTRONICS FRANCE SASU 294 avenue du Bois de la Pie 95700 Roissy-en-France, France The minimum period of supply of spare parts for household clothes dryers is 10 years.
