Summary of Contents for medalounger modulax HAKU 7116
- Page 1 HAKU 7116 User Manual...
- Page 2 HAKU 7116 Assembly Instructions...
- Page 3 ITEM NO:7116 HAKU EDTE PART LIST Description Drawing Quantity A-Table top B-Long Leg frame C-Short Leg frame D-Connector E-Bolt M8x20mm F-Washer φ20xφ8x1.5mm G-Allen key 6# H-Adaptor I-Extention cable Tools needed for assembly 1 of 8...
- Page 4 1 of 8 Assembly Instructions Carefully unpack all parts before assembly. Friendly reminder: Please put some soft support under the table top (A) when assembling to advoid any damage or scratch on it. As shown in the drawing: 1.Please turn the table top (A) over, assemble the leg frame (B&C) to the corresponding position at the table top (A) with bolts (E) &...
- Page 5 2 of 8 3.Please fix the bolts (E) to connect the table top and leg for 100%; 4.Please fix the bolts (E) of the connector for 100%; 3 of 8...
- Page 6 5.Please turn the table do not hold the table top,use the metal leg and frame to hold and turn around the table; 4 of 8...
- Page 7 6.Recommended to place the dining table on a flat area surrounded by a space in order to avoid phase with surrounding objects collision when the dining table is expanded,should be reserved in advance before and after more than 40cm space; 7.Please adjust the adjustable plastic feet to level the table,use a leveler on the table top;...
- Page 8 8.Please connect the battery cable to the actuator in the bottom of the table; 9.Please charge the battery with the provided adaptor for 7~8 hours.The system can be used whyle charging; 6 of 8...
- Page 9 10.Please extend the table by pressing S1,then remove the 2 pieces of foam and keep them for later use in case of transportation; 11.Please do not put heavy objects on the edge of the table; 7 of 8...
- Page 10 12.The table is not designed for sitting on the edge, please refrain from doing so; 13. The table requires a minimum of two individuals to facilitate its movement. Please refrain from gripping the tabletop and instead utilize the metal leg and frame for support. 8 of 8...
-
Page 11: Table Of Contents
HAKU 7116 User Manual Table of the contents 1.Safety Instructions…………………………………………………………...1 2.Usage………………………………………………………………………..2-4 3.Function……………………………………………………………………….4 4.Disclaimer and exclusion of liability………………………………………...4-5 5.Maintenance and Service……………………………………………………5-6 6.Decommissioning and Disposal…………………………………………..6... -
Page 12: Safety Instructions
1.Safety Instructions Please carefully read and follow the instructions to ensure the safe use of the motor. Non-observance of the safety instructions may cause considerable damage. KEEP OPERATING INSTRUCTIONS IN A SAFE PLACE. Indoor use only Some electrical and electrical equipment forbid to abandon and disposal at will CE mark This product must not be use ：... -
Page 13: Usage
1 of 6 2.Usage ●S1: short press S1 to extend the table. ●S2: short press S2 to retract the table. ●S1+S2: hold S1+S2 for 5 seconds to activate /deactive the child-lock function **the table is battery supported. When the power is low, the battery will remind user to charge battery with a beeping sound. - Page 14 2 of 6 ● Please don’t place items with a thickness of less than 10mm on the middle top to prevent the gap between the middle and side tops from being damaged the sensor. ● Please don’t attempt to place your fingers in between the table tops even if there is a press sensor, especially to keep it away from babies.
-
Page 15: Function
3 of 6 ● According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points where available. -
Page 16: Maintenance And Service
4 of 6 * We reserve the right to make unannounced technical changes in the course of our continual product improvement process. * The table is designed with build in safety functions. the user shall not rely on the safety functions only and will make sure no objects or bodyparts shall interfere the system while in use. -
Page 17: Decommissioning And Disposal
5 of 6 ● As there is sensor in between side and middle tops, so please keep it clean,no oil,no damage,no shedding. ● Moving parts always need to be well lubricated to help them move smoothly and function correctly. It is possible that during transportation the lubricant applied can get time we therefore recommend to apply a lubricant to the footrest.
