4
Assembling your Gokart
(Requires two adults to assemble)
Operating the Ninebot S/S-PRO
The Gokart is assembled by attaching the Gokart Kit to a Ninebot
S/S-PRO. Before assembly of the Gokart, please review the Ninebot
S/S-PRO User Manual and follow all instructions contained in it. Once the
Ninebot S/S-PRO has been properly activated and charged you can begin
assembly of the Gokart.
Update the Ninebot S/S-PRO firmware
1
Install the app
Download the Segway-Ninebot app (hereinafter referred to as the app)
by any of the following methods:
Scan the QR code below
Download in Google Play Store
or Apple's App Store
Segway-Ninebot App
Segway-Ninebot App
* Your mobile phone requires Bluetooth 4.0 or later, iOS system 8.0
or later, or Android™ 4.3 or later.
Pair your mobile phone and the Ninebot S/S-PRO
Turn on the phone's Bluetooth.
Press the power button to turn
Searching
on the Ninebot S/S-PRO.
Open the app to search for and
S-PRO0001
connect your Ninebot S/S-PRO.
Update firmware and switch modes
In the upper right corner of the app, tap Settings
Firmware Update.
On the Ninebot settings page, tap "Gokart mode".
Enable "Gokart mode".
Gokart Mode
Gokart Mode
Vehicle
Vehicle
Gokart Kit installation tutorial
About Gokart
Firmware
Update
Gokart
Mode
* This firmware update does not involve activation of the Ninebot S/S-PRO. If you need to use the
Ninebot S/S-PRO, please refer to the Ninebot S/S-PRO User Manual for related operations.
5
Driving the Gokart
Activate the Gokart
Press the power button on the Ninebot S/S-PRO to turn on the
Gokart.
The Gokart will automatically power o when idle for 10 minutes.
Open the Segway-Ninebot APP and connect your Gokart.
Searching
Gokart0001
Follow the instructions in the app to activate the Gokart
and complete the corresponding tutorial and exercises.
Activate the
Gokart
For your safety, the default values of the Gokart speed and
sensitivity are set to low. Use the app to learn how to drive
safely, then the speed limit can be gradually raised.
Remove the steering bar from the Ninebot S/S-PRO
2
Scan the QR code on the
right to review Assembly
Instructions.
Ninebot S-PRO
Assembly
Instructions
This manual uses the Ninebot S-PRO as an example. If you have a Ninebot S, please
watch the video by scanning the left QR code.
a.
Press the power button
b.
to turn o the Ninebot
S-PRO.
d.
Use a 5/32" hex wrench
to remove the screws in
the steering bar bracket
and pull o the bracket.
Disassembly is completed
after removing the steering
bar bracket. If you cannot
remove the bracket by
hand, continue to step e.
c.
e.
Use the tools provided to remove the steering bar bracket from the Ninebot S-PRO.
The steps are as follows:
Place the steering
Attach the metal
Insert the 5/32"
bar bracket
mold to the
hex wrench and
removal tool into
steering bar.
go through the
the screw holes on
metal mold.
the steering bar
bracket.
Check the status of the Ninebot S-PRO
3
Use and charging
1
Fastening the seat belt
1
Sitting on the seat, buckle the left and
right parts of the seat belt in front of you.
5
Driving
2
Acceleration: lightly press the throttle (right
pedal) to go forward.
Deceleration: lightly press the brake (left
pedal) to decelerate.
Steering: steer the Gokart by slightly turning the
6
steering wheel clockwise or counterclockwise.
Do not pump the brake pedal to decelerate.
Reversing
3
When the Gokart is stopped, double-press
the brake (left pedal). After you hear a beep,
the Gokart has switched to reverse mode.
Press the throttle to drive the Gokart in
reverse. Double-press the brake (left pedal)
again to return to forward mode.
Emergency braking
4
In the event of a situation that requires an
emergency stop, pull the hand brake handle on
the right side of the Gokart to engage the
emergency brake.
Follow the relevant charging instructions in the manual and the common battery maintenance and safety knowledge for
maintenance. Ninebot products are designed with overheat protection. If the vehicle temperature exceeds 104 °F (40°C),
the vehicle cannot be charged as normal. Wait until the vehicle cools to below 104 °F (40°C) before charging.
Assembling and disassembling the Gokart
Before assembly, update the app's firmware and turn on
Gokart mode.
Assembly
Ninebot S Assembly
Plug the power extension cord into the charging port of the Ninebot S/S-PRO,
1
Instructions
tighten by turning clockwise.
2
Install the adapter pad.
Power extension
Located under the frame. Remove
cord
the attachment strap before
removing from the frame.
Do not plug the power
Unlock the steering bar
extension cord into the
tool-free release, remove
Ninebot S/S-PRO if the
power extension cord
the steering bar.
Power
or charge port is wet.
button
Place the Gokart frame on the Ninebot S/S-PRO.
3
The installation direction is as shown below.
Be sure to align the steel frame with the
Remove the rubber plug on
adapter pad as shown in the enlarged view.
the steering bar bracket.
Power
button
Insert and tighten
the M6 screw with
the 3/16" hex
wrench.
< 19°
If lifting the frame by yourself, do not lift the
backside more than 19° or you may
damage the bumper.
Disassembly
Press the power button to turn
Disconnect the electrical connection
o the Gokart.
cable.
2
3
4
Shutdown
5
Make sure the vehicle is completely stopped
before getting o . Press the power button to
turn o the Gokart.
Charging
6
Charge the Gokart by plugging the Ninebot S/S-PRO
power cord into the power extension cord.
Do not connect the charger if the charge
port or power cable is wet.
This assembly is for adults only. Do not power on the Ninebot S/S-PRO during assembly or disassembly.
Once fully assembled, make sure:
9
The Ninebot S/S-PRO adapter pad and
the Ninebot S/S-PRO are facing the cor-
rect direction.
The attachment straps are properly at-
tached and tightened.
The electrical connection cable is
plugged into the power extension cord.
The body length and steering wheel
height is appropriate for the rider.
The battery compartment is closed.
If anything appears to be incorrect,
stop using the Gokart and
contact after-sales
service.
Pass the attachment straps through the
5
Plug the electrical connection
4
bottom of the Ninebot S/S-PRO and the
cable of the Gokart into the
strap fixing holes. Tighten the straps.
power extension cord. Align
the groove and do not force
Please make sure the location of the logo
the cord in.
is correct on the straps. If not, return to
Charge ports must be dry.
step
for adjustment.
3
Refer to the assembly procedure and
carry it out in reverse order.
6
Specifications
Name
Ninebot Gokart Kit
Product
Model
N4MZ98
Supported
NinebotS (Model:N3M240)
Name and model
models
Ninebot S-PRO (Model:N3M260, N3M320)
After extension (Max status): 54×32×24 in (1383×822×600 mm); before extension
Vehicle size
(Min status): 40×32×18 in (1004×822×459 mm)
Size
Package size
43.1×34.1×20.1 in (1095×865×510 mm)
Max payload
220 lbs (100 kg)
Weight
Net weight
58.9 lbs (26.7 kg)
Height requirement
51-75 in (130-190 cm)
Driving
Recommended Age
8+ years old
Speed limit
15 mph (24 km/h)
Novice speed limit
5 mph (8 km/h)
Reversing speed limit
2 mph (3 km/h)
Typical Range
[1]
9 mile (15km)
Steering ratio
2.1:1
Machine
Ground clearance
1.6 in (40 mm)
Parameters
Maximum slope
[2]
15°
Traversable Terrain
Hardened road, flat road surface, slopes below 15°
Operating temperature
14°F~ 104°F (-10~40℃)
Storage temperature
-4°F~ 122°F (-20~50℃)
IP rating
IPX4
Front
compartment
Model/Quantity
6 AA Batteries
battery
[3]
Front tires
Tire width: 3 in (80 mm); flatness ratio: 60%; hub diameter: 5 in (127 mm)
Tires
Type
Non-inflatable hollow tire
Headlight
0.2 Watt white LED light bar
Light
The indicator comes in three colors: blue, yellow, and red. Blue means that the vehicle is in normal
condition. Yellow means that the vehicle needs to be activated or the batteries in the front compartment
Status indicator
need to bereplaced. Red means that the vehicle has a performance failure, and you need to open the
app to check the cause of the failure and contact the after-sales service.
Braking method
Electronic brake + mechanical handbrake
Brake
Braking distance
[4]
20 ft (6 m)
Install the Gokart batteries.
8
Unscrew the battery
compartment cover and
insert batteries into the
compartment. Close and
tighten the cover.
To avoid issues that may be
caused by corrosion,
remove the batteries if not
using the Gokart for an
extended period of time.
7
Adjust the steering wheel height:
a
Raise the steering wheel to a
suitable height.
a
b
Insert the quick release
screw into the hole of the
b
d
c
corresponding height.
c
Tighten the quick release nut.
d
Press to fix the steering wheel
quick release components.
e
Ensure the steering wheel does
b
not shake. Otherwise, repeat
the steps b, c, d, e.
d
a
b
Four screws
c
already inserted
into the screw
holes.
6
Stretch the frame and adjust the length of the body:
a
With both hands holding the steering wheel and the seat,
stretch the frame out to a suitable position along the
horizontal direction of the connection tube.
b
Align the scalable structure of the frame with the
marking on the connection tube.
c
Positioning: Use a 3/16" hex wrench to press the two
screws into the holes on the left and right connection
tube in order, as shown in the figure above
(The screw is
set to a depth of about 1cm for successful
position).
d
Tighten the 4 screws.
[1] Typical Range : Under the
circumstances of full power, 154
lbs (70kg) load, and 77°F(25℃)
ambient temperature, and
measured on a flat road at an
average speed of 9 mph (15
km/h).
[2] Maximum slope: Refers to the
maximum slope that a 220 lbs
(100 kg) driver can climb at a
speed not faster than 3 mph (5
km/h).
[3] Front compartment battery:
The battery compartment inside
the frame that is used to power
the frame indicator/headlight.
When the battery is low, the blue
indicator light turns yellow and
blinks. You need to replace the
batteries yourself.
[4] Braking distance: Under the
circumstances of full power, 154
lbs (70kg) load, and measured on
a flat hard road at an average
speed of 12.4 mph (20 km/h).
Note:
You can also open the App
for more specific tips.
