YoLink Relay

YS5706-UC

Installa on & User Guide

Rev 1.1

Table of Contents

Need help?

Do you have a question about the YS5706-UC and is the answer not in the manual?

Questions and answers

Summary of Contents for Yolink YS5706-UC

Page 1 YoLink Relay YS5706-UC Installa on & User Guide Rev 1.1...
Page 2 Thank you for purchasing YoLink products and for entrus ng us with your smart home needs! Your 100% sa sfac on is our goal. If you experience any problems with se ng up your new YoLink Relay, please give us a chance to assist you, before returning your purchase.
Page 3: Table Of Contents
····· ····· ···················································· · · · ·· · ·1 Introduc on ······························································································2 Set Up ····································································································· ·4 · Installa on ·······························································································6 Using the YoLink App ················································································13 About YoLink Control ······························ ················ ··································20 Maintenance ······················································································· ···24 · Speciﬁca ons ····················································································· ····26 ·...
Page 4: In The Box
A. In the Box A. YoLink Relay B. Quick Start Guide 5V-24V DC power supply (required) not included...
Page 5: Introduc
B. Introduc on The YoLink Relay is a smart, dry contact relay that can be controlled by your iOS and Android devices and by Alexa and Google Assistants, and 3rd-party IoT integra on, such as IFTTT. The YoLink Relay can be used to make any non-smart low voltage or high voltage* device or equipment smart. Simply add the YoLink Relay to the YoLink app (YoLink Hub required, not included) and enjoy remote status display and control of your device/equipment, including on/oﬀ...
Page 6 Green Relay is On Relay is Oﬀ Blinking Green Connec ng to Cloud Fast Blinking Green Establishing Connec on with YoLink System (YoLink Control) Slow Blinking Green Upda ng Fast Blinking Red Removing Connec on to YoLink System (YoLink Control)
Page 7: Set
C. Set Up C-1. Set Up - First-Time YoLink Users (Exis ng users proceed to C-2. Add Device, next page) Download the YoLink app through Apple App Store or Google Play Apple iPhone or tablet that is iOS 9.0 or...
Page 8 C-2. Add Device Ta p “ ” b u o n , t h e n s c a n Q R C o d e o n t h e d e v i c e . F o l l o w t h e s t e p s t o a d d t h e d e v i c e Power up the relay by plugging in (or turning on) the power supply.
Page 9: Installa
5-24V DC input power, only (do not power the Relay with other than 5-24V power supply) If your YoLink Relay will output a switched current over 5 amps (120V AC/30V DC), you must provide a dumb relay (with contacts rated for the load)
Page 10 D-3. Begin Installa on: Loosen the four terminals on the YoLink Relay using a small slo ed screwdriver Connect the posi ve (white or red, typically) wire on the power supply Relay 5-24V 5-24V to t h e “ D C + 5 - 2 4 V ” te r m i n a l ;...
Page 11 Relay Terminals Example Diagrams (a) Relay 5-24V 5-24V Equipment / Relay Posi ve (+) Terminal or Wire From Equipment / Relay Power Supply Nega ve (-) Terminal or Wire (DC 5-30V) Low Voltage Device/Equipment (Low Voltage Relay) Diagram...
Page 12 Relay Terminals Example Diagrams (b) Relay 5-24V 5-24V Home Appliance / Relay 120V Hot Terminal or Wire From 120VAC Home Appliance / Relay 120V Neutral Terminal or Wire 120V Appliance/Equipment (or 120V Relay) Diagram...
Page 13 D-4. Test Your Relay: Turn o circuit(s) at the controlled Using the YoLink app, test the opera on of the equipment a er installa on Relay (turn it on, then oﬀ, etc.). If it is not working properly, double-check or re-do steps on page 7, as needed.
Page 14 D-5. Installa on Methods ( Plas c Electrical Box or Wall-moun ng) Please refer to device environmental opera ng range informa on on page 26. Use this device outside the recommended ranges at your own risk Method A: Place in a electrical box (plas c recommended) 1.
Page 15 Method B: Wall-moun ng the relay with double-sided moun ng tape (not included) Before installing the relay, place it in the appropriate posi on. Ensure the wires connected to the terminals on the YoLink Relay are connected securely Clean the installa on area...
Page 16: Using The Yolink App
* Tap to go to Details page(refer to page 8 & 9) Connec on Status of YoLink Relay and Hub Real- me Status of YoLink Relay: Turned on or turned oﬀ Control Bu on of YoLink Relay: Turn on or turn oﬀ...
Page 17 Connec on Signal Status of reley and Hub: Strong; Good; Weak m. Firmware Version “#### ready now ” indicates a new update is available (refer to page n. Remove Device From Current Account * Tap to delete the device from your YoLink account...
Page 18 E-3. Timer The mer will run only once. You can set a new mer a er the mer has already run or a er you cancel it b. Edit the mer b-1 Enable “Turn On A er” and (or) “Turn Oﬀ A er” b-2 Set the mer dura on in “Hours and Minutes”...
Page 19 E-4. Schedule 1. You can have a maximum 6 schedules at one me 2. You may add as many schedules as you want in Automa on se ngs. Automa on se ngs are saved in the cloud Swipe Le d. Click to edit the schedule 1.
Page 20 E-5. Scene Go to the “Smart” screen, and default is “Scene” screen There are four pre-set scenes, you can choose to either edit or delete each of them Swipe Le b. Add a scene c. Click to edit the scene b-1 Edit name 1.
Page 21 E-6. Automa on (Set Up Rules For “If This Then Do That”) Go to the “Smart” screen, tap “Automa on” YoLink Relay can be set as either a trigger or an ac on device, with two op ons: turn on or turn oﬀ b. Add an automa on...
Page 22 E-7. Voice Assistants Connect YoLink with third-party voice assistants to control (turn on or turn oﬀ ) or monitor the status of your devices through voice commands Tap “ ” in the upper le corner to go to My Proﬁle Go to Se ngs >...
Page 23: About Yolink Control
Hub or an internet connec on. (Use of YoLink Control is op onal; you can use the Automa on feature in the app OR use YoLink Control, but YoLink Control oﬀers the beneﬁt of opera on without the Hub or internet connec on.) One device controls another, directly.
Page 24 (this may happen a er only blinking two or three mes) 1. If you want to turn oﬀ the YoLink Relay when the door is open, turn oﬀ the YoLink Relay ﬁrst , and let it enter pairing mode 2. For the same Door Sensor and YoLink Relay, you can only choose to either turn on or turn oﬀ the...
Page 25 Opera on When the door is open, the YoLink Relay will now immediately turn on. The relay will remain turned on un l turned oﬀ using the OFF bu on or via the app More advanced sequences, controlling mul ple outputs (e.g. turn oﬀ relay and ac vate siren)
Page 26 Upon un-pairing, the Door Sensor LED will stop blinking and turn oﬀ, and the YoLink Relay LED will stop blinking and return to the previous color (green for turned on, red for c. SET Bu on turned oﬀ)
Page 27: Maintenance
G. Maintenance G-1. Firmware Update To ensure our customers have the best user experience, we highly recommend you update to the newest version ﬁrmware when an update is available In “Firmware”, if a new version is listed as available (#### ready now), click it to start the ﬁrmware update process You may use your device during the update as it is performed in the background.
Page 28 Factory reset will erase all of your se ngs and restore it to factory defaults. A er the factory reset, your device will remain in your Yolink account Hold the SET bu on for 20-25 seconds un l the status light blinks red and green alternately,...
Page 29: Specifica Ons
H. Speciﬁca ons 5-24V DC Input Voltage: ≥ 300mA Input Current: Device Current Draw: ≤ 60mA (on), ≤ 25mA (standby) Switched Current: 5A @120VAC/@30VDC (Maximum) Environment: Temperature: -4°F - 122°F (-20°C - 50°C) Humidity: 5-85% non-condensing...
Page 30 Dimensions: Unit: inches (millimeters) 1.93 (49.0) 0.98 (25.0) 1.93 (49.0) FRONT SIDE...
Page 31: Troubleshoo
- Power outages (before or during) can prevent the mer from execu ng. Press the SET bu on once to turn on/oﬀ the relay, also you can turn on/oﬀ the relay via YoLink app or set a new mer. (When you add a rese ng/one- me-use mer this will need to be amended with that new informa on.)
Page 32: Warning
, a n d w i l l vo i d t h e wa r ra nt y If your YoLink Relay does get dirty, please clean it by wiping it down with a clean, dry cloth.
Page 33: Customer Service &Warranty
This warranty does not cover abuse or misused products or products used in commercial applica ons. This warranty does not apply to YoLink Relays that have been improperly installed, modiﬁed, put to a use other than designed, or subjected to acts of God (such as ﬂoods, lightning, earthquakes, etc.).
Page 34 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec on against harmful interference in a residen al installa on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc ons, may cause harmful interference to radio communica ons.
Page 35 Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modiﬁca ons to this equipment. Such modiﬁca ons could void the user’s authority to operate the equipment. FCC RF Radia on Exposure Statement This equipment complies with FCC RF radia on exposure limits set forth for an uncontrolled environment.
