Page 3: Package Contents
Package Contents The Red Cloud Node (Ethernet+Wireless) comes standard with Ethernet as well as an onboard power supply that is built into the controller. Optional wireless and PoE modules are also available and may be purchased separately. Red Cloud Node (Ethernet+Wireless) -
Page 4: Pre-Installation Requirements
Compliance Conforms to UL 294 Installation This section of the manual provides instructions for installing the ProdataKey Red Cloud Node (Ethernet+Wireless). Before you begin the installation, read the instructions thoroughly. Make sure you have read and understood the Safety Information. -
Page 5: Mounting Instructions
Wire crimper/stripper Mounting Instructions Mount the Red Cloud Node (Ethernet+Wireless) at the door/device or as centrally located as possible. Install the Red Cloud Node (Ethernet+Wireless) in an environmentally controlled and secure area. These instructions allow you to easily fasten the box properly and securely to a wall surface. Prior to beginning, ensure you have the package contents, tools, and necessary materials for the installation on an appropriate surface (i.e., drywall, wood). -
Page 6: Power / Battery
Use the Red Cloud Node (Ethernet+Wireless) box to mark the hole positions on the wall, and drill holes into the surface. If mounting onto drywall, insert the anchors into the holes to secure the screws to the surface. Align the enclosure’s holes to the holes in the wall surface and mount the controller box with the screws so the box is securely fastened to the wall. -
Page 7: Board Overview
Battery Maintenance, Replacement, & Disposal The Red Cloud Node (Ethernet+Wireless) features a battery charger and constantly monitors the battery’s health and statistics. Check the battery regularly and replace it only with an identical battery or a ProdataKey recommended battery. - Page 8 WiMAC Antenna (A) - Attach the Antenna for Wireless Communication. Standard Ethernet Board (B) - An Ethernet connection is the Red Cloud Node (Ethernet+Wireless) communication option.
- Page 9 Connectors This section describes the Red Cloud Node (Ethernet+Wireless) connector's technical specifications.
- Page 10 The voltage end connector will be 12/24VDC. 5-Pin Connector Port Notes Power Output Positive 12VDC Out Power Output Negative 12VDC Out Reader Data Input Data 0 / OSDP B Reader Data Input Data 1 / OSDP A Reader LED Trigger Reader LED Output Trigger 3-Pin Connector Port...
- Page 11 Controller Power Input 12/24 VDC Negative Important Note: Power into the Red Cloud Node (Ethernet+Wireless) Controller board is polarity sensitive, meaning that it has fixed positive and negative connections. Board Systems LED Indicators LED indicators are shown on the controller board for POWER, HEART, LINK, and ethernet LEDS located on the...
- Page 12 Diagram Wiring Diagram Diagram NOTE: For UL-certified wire installations, all wire running from a Red Cloud Node (Ethernet+Wireless) to a lock, strike, or reader device must be less than 98.5 feet (30 meters). Strip the wire ends as required. Install the reader, and attach the wires, meeting your reader configurations.
- Page 13 (+) and ground (-). DC voltage is polarized, meaning that it has fixed positive and negative connections. The diode must be installed in the direction shown in the illustrations: gray stripe to positive (+), black to negative or ground (-). Reader Connectors This section describes the Red Cloud Node (Ethernet+Wireless) connector's technical specifications.
- Page 14 (A) Main Reader - The main reader is mounted at the door with a 22/5 or 22/6 wire ran to the door controller. Wire the reader to the controller as shown above. Be sure to check polarity and voltage prior to powering the controller. (B) OSDP - Place jumper(s) to enable OSDP multi-drop capabilities, NOTE:...
- Page 15 Green: to 1 connector Door Position Sensor (DPS) Wiring Diagram DPS: The Door Position Sensor is mounted on the door frame in the desired location with a 22/2 wire running from the DPS to the controller. When using two DPS sensors for double doors, wire them in series with only two conductors running back to the controller.
- Page 16 closed. When the electromagnet is energized, a current passing through the electromagnet causes the plate to attract the electromagnet, creating a locking action. NOTE: For UL-certified wire installations, all wire running from a door controller to a lock, strike, or reader device must be less than 98.5 feet (30 meters).
- Page 17 latch just like a fixed strike. (A) Diode: The provided diode MUST be installed when using a strike. Install at the strike with the stripe of the diode on positive (+) and the black on negative (-). IMPORTANT: The diode MUST be installed as close to the lock as possible. The best scenario (if possible) is directly across the screw terminals on the lock.
-
Page 18: Compliance Information
(A) Diode: The provided diode MUST be installed when using a strike. Install at the strike with the stripe of the diode on positive (+) and the black on negative (-). IMPORTANT: The diode MUST be installed as close to the lock as possible. The best scenario (if possible) is directly across the screw terminals on the lock. -
Page 19: Fcc Compliance
Safety Disposal and Recycling Notices The ProdataKey Red Cloud Node (Ethernet+Wireless) is intended for indoor use only. The ProdataKey product shall be installed by a trained professional. The ProdataKey product shall be used in compliance with local laws and regulations. -
Page 20: Intellectual Property Rights
The ProdataKey product shall be installed within a secured area. A backup battery is required for UL 294 installations. A UL 294 listed direct plug-in power supply with a “power ON” indication is required with the following ratings: 14 VDC 2 Amp 28 Watt. The power supply shall be visible after installation and located within 6 feet from the panel. -
Page 21: Trademark Acknowledgments
Trademark Acknowledgments ProdataKey, Prodata Key, prodatakey, PDK, Prodata, are registered trademarks or trademark applications of ProdataKey in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. Permission to use, copy, modify, and distribute this software and its documentation for any purpose with or without fee is hereby granted, provided that the copyright notice appears in all copies and that both the copyright notice and this permission notice appear in supporting documentation. -
Page 22: Disposal And Recycling
Supported Readers Most Wiegand and OSDP readers are compatible with the ProdataKey hardware. For information regarding the ProdataKey readers, see the available product data sheets at ProdataKey Readers PDK Certification and Tutorials Visit ProdataKey accesscontrol101.com for certification training and tutorials. - Page 23 ProdataKey, LLC and may be registered. All other trademarks are the property of their respective owners. ProdataKey assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. Red Cloud Node (Ethernet+Wireless) Instruction Manual ProdataKey Door Controllers Ver. 1.1.0...
