- Page 1 AUDIO INTERFACE User Manual ™ ™ ®...
- Page 2 Contact and Support User Resources support@harvest-tech.com.au Further information to content outside the scope of the user guide. Harvest Technology Pty Ltd 7 Turner Avenue, Technology Park Bentley WA 6102, Australia Extra pointers or suggestions in harvest.technology executing instructions.
- Page 3 Disclaimer and Copyright Whilst Harvest Technology will endeavor to keep the information in this user guide up to date, Harvest Technology makes no representations or warranties of any kind, express or implied about the completeness, accuracy, reliability, suitability or availability with respect to the user guide or the information, products, services or related graphics contained in the user guide, website or any other media for any purpose.
-
Page 4: Table Of Contents
CONTENTS Getting Started ���������������������������������������������������������������������������������������������������������� 1 Introduction ������������������������������������������������������������������������������������������������������������������������������������������������������������� 1 Key Features ....................................... 1 Typical System Setup ..................................1 Connections / UI ����������������������������������������������������������������������������������������������������������������������������������������������������� 2 Rear ........................................2 Side ........................................2 UI .......................................... 3 Configuration ������������������������������������������������������������������������������������������������������������� 4 Overview ������������������������������������������������������������������������������������������������������������������������������������������������������������������ 4 Web Interface ���������������������������������������������������������������������������������������������������������������������������������������������������������� 4 Initial Configuration ................................... -
Page 5: Getting Started
NCM User Manual ® Getting Started Introduction Welcome to your Nodestream Nodecom (NCM) device. The NCM is designed to for use as a single channel desktop audio streaming device for communication with other Nodestream devices within your Nodestream group. Integrated UI allows for intuitive control and feedback of system status. -
Page 6: Connections / Ui
NCM User Manual ® Connections / UI Rear Power Input USB C - 5VDC (5.1VDC preferred). USB-A 2�0 Used for connection of accessories, i.e. speakerphone, headset. Gigabit Ethernet An RJ45 connection used to connect to the customer network. WiFi Antenna SMA connector for connection of supplied WiFi antenna. - Page 7 NCM User Manual ® Status LED RGB LED to indicate system status. Push to Talk Controls audio input when an audio connection is active. LED ring indicates audio connection status. Volume Control Controls input and output volume levels, press to toggle mode. LED ring indicates current level. Nodestream devices are supplied with a Quick Start Guide for installation and detailed UI function.
-
Page 8: Configuration
NCM User Manual ® Configuration Overview Configuration of your Nodestream device is performed via the system Web Interface. From here you can: • View system information • Configure network(s) • Set user login credentials • Enable/Disable remote support • Manage Enterprise Server settings •... -
Page 9: Initial Configuration
NCM User Manual ® Non DHCP Enabled Network When a device is connected to a non DHCP enabled network, and its network has not been configured, the device will fall-back to a default IP address of 192.168.100.101. 1. Connect the Ethernet port of your device to your LAN and power it up. 2. -
Page 10: Network
NCM User Manual ® Network This section of the Web Interface provides information on device software version, network information, testing , and configuration of device network adapters. Information Displays information related to the selected port (port can be selected from the drop down in the “Port” section) Name Name of the port Status... -
Page 11: Testing
NCM User Manual ® Testing Helpful network testing tools for confirmation of network settings and capabilities. Speed Test For testing available upload and download bandwidth. Ping For testing connection to the Nodestream server (www.avrlive.com) or to confirm connection to other devices on your network 1. -
Page 12: Ethernet
NCM User Manual ® Ethernet 1. Select the port you’d like to configure from the “Port” drop down. DHCP 1. Select "DHCP" from the "IPv4" drop down, if not already selected, then save. 2. When prompted, confirm IP settings change. Network setting applied prompt will be displayed. 3. -
Page 13: Wifi
NCM User Manual ® WiFi 1. Select "WiFi" from the “Port” drop down. 2. Select network from list of available networks from the “Visible Networks” drop down. 3. Confirm security type is correct and enter password. DHCP 1. Select "DHCP" from the "IPv4" drop down, if not already selected, then save. 2. - Page 14 NCM User Manual ® Manual 1. Select “Manual” from the “IPv4” drop down and enter network details as provided by your Network Administrator, then save. 2. When prompted, confirm IP settings change a network setting applied prompt will be displayed. 3.
-
Page 15: Firewall Settings
• Devices must be able to send UDP packets between each other in the range of: • UDP port: 45000 - 50000 • All traffic is protected with 384-bit encryption • All port ranges are inclusive • Contact Harvest support for further information. support@harvest-tech.com.au page 11 of 19 HTG-TEC-GUI-012_0... -
Page 16: System
Enterprise Server Settings Nodestream devices can be managed via the Harvest server or a dedicated "Enterprise Server". If your Nodestream device is managed by an Enterprise Server, you will need to input its details in this section. Contact your company Nodestream administrator for further information. -
Page 17: Options
4. Configure the network or your device. Refer “Initial Configuration” on page Remote Support Remote support enables Harvest support technicians to access your device if advanced troubleshooting is required. To enable/disable remote support, click the “Remote Support" button. Enabled Disabled... -
Page 18: Updates
NCM User Manual ® Updates This section of the Web Interface provides control and management of the device update system. Automatic Updates Automatic updates are enabled by default, downloading and installation occur in the background. During this process the device may restart. -
Page 19: Operation
NCM User Manual ® Operation User Interface Status LED Displays device power and network status. Power on Network issue PTT (Push To Talk) Displays software and connection status and provides control of microphone input. (also used for factory reset) Press and Hold Start talking Release to mute... -
Page 20: Audio
Speaker Left Inputs are selected and configured via your Harvest control application. Control Applications Nodestream device connections and associated input/output configurations are managed via Harvest control applications. Nodester A control only iOS application developed for iPad. Typically used in control applications or when a customer's Nodestream group comprises only of hardware devices. -
Page 21: Appendix
NCM User Manual ® Appendix Technical Specifications Physical Physical dimensions (HxWxD) 50 x 120 x 120 mm (1.96" x 4.72" x 4.72") Weight 475g (1.6lbs) Power Input USB Type C - 5.1VDC Consumption (operating) 5W typical Environment Temperature Operating: 0°C to 35°C (32°F to 95°F) Storage: -20°C to 65°C (-4°F to 149°F) Humidity Operating: 0% to 90% (non-condensing) -
Page 22: Troubleshooting
Increase output volume at the connected device or via your Harvest control application Input volume too low Level set too low Increase mic level at the connected device or via your Harvest control application Microphone obstructed or too far Ensure microphone is not obstructed... - Page 23 Bentley WA 6102, Australia harvest.technology All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, photocopy, recording or otherwise without the written consent of the ®...
