PedalPCB Concrete Jungle Distortion Manual page 2

LOCATION VALUE
R1 2M2
R2 1K
R3 10K
R4 220K
R5 150K
R6 47K
R7 100K
R8 100R
R9 1K
R10 47K
R11 2K2
R12 2K2
R13 10K
R14 1K
R15 47K
R16 510K
R17 10K
R18 100R
R19 10K
R20 100K
R21 100K
R22 220K
R100 10K
R101 10K
CLR 4K7
C1 47n
C2 100p
C3 10u
C4 10u NP
C5 1u
C6 1n
C7 100p
C8 1u
C9 10n
C10 10n
C11 2n2
C12 22n
C13 470n
C14 10u NP
C100 100u
C101 47u
D1 1N4148
D2 1N4148
D3 1N4148
D4 1N4148
D100 1N5819
Q1 BC184C
Q2 2SC3198-GR
IC1 NJM4558D
LEVEL A100K
GAIN A50K
BASS C50K
TREBLE B50K
Concrete Jungle Distortion
Concrete Jungle Distortion
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 5.0mm
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Film capacitor, 7.2 x 5.0mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 5.0mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Schottky diode, DO-41
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
Dual op-amp, DIP8
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Copyright © 2024 - PedalPCB.com
NOTES
* LED current limiting resistor
Non-polarized
Non-polarized
Page 2 of 5
