Elegant Furniture And Lighting FAS-9001 Manual

Thank you for purchasing our faucet. The faucet you have purchased is
crafted out of the highest quality nickel, brass and stainless steel. Each and
every faucet was tested and carefully inspected by hand before delivering to
our retailers.
Please read the instructions carefully to prevent any malfunction and
damages to your plumbing and property.
The tools below are required to complete the installation. Some may not be
needed depending on the model of the faucet that you are installing. For
additional information, check with your local hardware store on the
requirements for your installation.
(NOT PROVIDED)
Philips Screwdriver Thread Seal Tape
Adjustable Wrench
Pliers
1. Lever style handle with temperature indicator on the escutcheon
2. Handle operates upward through a 23° arc.The rotation angle of
temperature is 100.Maximum hot through 50° in clockwise direction.
Minimum cold through 50° incounterclockwise.
3. Adjustable temperature limit stop to control maximum hot water
temperature.
4. Pressure balancing mechanism maintains selected discharge temperature
to 土3.6°F(士2°C)
Daily maintenance
1.Dip the cloth into mixture of white vinegar and water (50/50) and
scrub to remove hard-water spots.
2.Check aerator (if present) regularly for calcium build up are when water
stream is not optimum.
3.DO NOT use caustic cleaning products as the use will break down
finish and will void the product warranty.
4.Acceptable cleaners include mixture of white vinegar and water
(50/50) or mild non-abrasive liquid detergents.
5.If the water pressure appears to be less than optimum remove, inspect,
clean or replace aerator.
Shower Room Faucet
Flashlight
FAS-9001 FAS-9002
Safety Glasses
Mounting Depth
155x100mm
6-1/10 ' 'x3-47/50''
80 - 90mm
3-1/8"-3-1/2"
Two function
FAS-9004
FAS-9003
155x100mm
6-1/10 ' 'x3-47/50''
80 - 95mm
3-1/8"-3-3/4"
Three function
Helpful Hint:
Always use the supplied
rubber washers on water
supply connectors to prevent
leaking. Also, always use an
adequate amount of
plumber's putty or thread
sealing tape to prevent
connectors from leaking.
Notice
Notes before installation :
1.Please check that all components are present.
2.Before installation ensure that all feed lines are clear of debris and on/off valve
is present.
3.Ensure water pressure is between 20-125 PSI (includes combination of hot
and cold feed lines).
4.Pictures in the manual are general in content and may not represent exactly
your purchased faucet. If you are having difficulties please contact a
professional plumber.
5.If you will be away from home for an extended period you should shut off the
main water.
6.Rinse all water pipes before installation to insure no impurities remain inside.
7.When welding the shower valve to the water pipe, take out the cartridge and
any seals in the valve. When welding is complete,wait for body of the valve to
cool down, then re-install the cartridge and the seal parts.
8.A force of 11-13 N.m is needed to securely lock the cartridge.
9.All valves have to passed air and pressure testing before shipment. If you wish
to request pressure testing beforeinstallation, it must be through a
professionally licensed plumber and air pressure must not exceed 125 PSI.
Warranty
The warranty does not apply to the following cases:
1. Failure to provide purchase re-ceipt.
2. Material damage caused by carelessness or during transport.
3. Due to improper installation.
4. Alterations or repairs by un-authorized persons.
5. Damaged of the nickel plating because of unauthorized
cleaning methods (hard and heavy deter-gent).
ACCESSORIES CATEGORY WARRANTY PERIOD
SHOWER SET
BATHTUB FAUCET/POTFILLER
CARTRIDGE
BASIN/KITCHEN FAUCET
SHOWER/KITCHEN FAUCET TUBE 1 YEAR
1 YEAR
SHOWER HOSE
1
KITCHEN FAUCET SPOUT YEAR
SHOWER HEAD, HAND SHOWER 1 YEAR
SHOWER/KITCHEN/BASIN MIXER BODY 5
YEARS
(CHROME COLOR)
SHOWER/KITCHEN/BASIN MIXER BODY
2 YEARS
( BRUSH NICKEL,MATTE BLACK,BRUSH GOLD,
GUN BLACK)
(FUNCTION,APPEARANCE)
2
YEARS
(THERMOSTATIC/HOT &COLD)
2 YEARS
5 YEARS
