Fitting the end caps and rail covers...... 9 5.10 Initialising the control system........ 9 5.11 Finishing the installation .......... 9 Manual operation ....... 9 Reinitialising the control system ....... 10 Annex .......... 11 Wiring diagram and wiring connections.... 11 Technical data ............ 12 3317248A_II_Marine Roof 50 Series...
Purpose of this document Intended use These Installation Instructions (II) are part of the product and The Marine Roof 50 Series is an electrically operated sliding roof contain the information you need for correct and safe installa- for ventilation purposes.
– Apply a bead of sealant along the contour of the roof Installation requirements cut-out. The surface on which you install the Marine Roof 50 Series must – Apply a bead of sealant around all fixing holes. comply with the following requirements: In case of other materials (e.
The deviation to the left, right, front, and rear must not ex- ceed 2 mm. Attach the glass panel (2) to the connecting brackets (4) us- ing 2x3 tooth lock nuts M5 (1). Tighten the nuts (1) at the threaded ends (3) to 4 Nm. 3317248A_II_Marine Roof 50 Series 5 / 14...
Align the rails with the rear beam of the top frame. Fig. 12 Drilling holes in the deck NOTE Misalignment of the rails Make sure the rails do not move while drilling. NOTE Drill only one hole in each rail near the front end. 6 / 14 3317248A_II_Marine Roof 50 Series...
Page 7
Drill holes with the correct diameter. measured before. Place the screws in the holes (1). Fig. 16 Closing the roof 1 Close button 14. Push and hold the Close button to close the roof. 3317248A_II_Marine Roof 50 Series 7 / 14...
Fig. 19 Mounting the rails Apply a thin layer of grease (Isoflex® Topas L32) to the in- side of the guides. 20. Place the rails. 21. Place and tighten all fixing screws to 4 Nm. 8 / 14 3317248A_II_Marine Roof 50 Series...
WMS000019 Fig. 28 Opening or closing the Marine Roof 50 Series manually Insert the key in the slot of the motor. Turn the key to close or open the Marine Roof 50 Series. NOTE After manual operation, you must reinitialise the Marine Roof 50 Series.
Make sure that the available power source can supply a min- imum current of 20 A. Press and hold the Close button. – The Marine Roof 50 Series closes as far as possible. Release the Close button. Within 1 second press and hold the Close button.
Annex Wiring diagram and wiring connections Webasto Customer 20 A WMS000016A Fig. 30 Wiring diagram Motor Battery Wiring harness Control switch (Typical) Fuse Wire colours blue brown yellow green grey orange black purple white 3317248A_II_Marine Roof 50 Series 11 / 14...
887 mm Width 1,600 mm +4 / -0 mm Corner radius, front / rear 80 mm ± 2 mm Cross curvature 9,237 mm Front radius 2,032 mm Longitudinal curvature Uncurved Table 4: Cut-out dimensions 12 / 14 3317248A_II_Marine Roof 50 Series...
Page 13
Corner radius glass panel, front 25 mm Front radius glass panel 2,057 mm Cross curvature 9,295 mm Longitudinal curvature Uncurved Glass panel displacement “tilt” (Z-direction) 22 mm “slide” (X-direction) Approx. 680 mm Table 5: Marine roof dimensions 3317248A_II_Marine Roof 50 Series 13 / 14...
Page 14
To request this documentation in another language, please locate and contact your local Webasto dealer. You can find your nearest dealer at: https://dealerlocator.webasto.com/en-int. To provide feedback (in English or German), please email: feedback2tdt@webasto.com Webasto Thermo & Comfort SE UK only:...
