Page 1 Products Solutions Services BA02322D/06/EN/01.23-00 71637045 2024-03-15 Valid as of version 01.00.zz (Device firmware) Operating Instructions Proline Teqwave MW 500 Total solids measurement via microwave transmission HART...
Page 2 Proline Teqwave MW 500 HART • Make sure the document is stored in a safe place such that it is always available when working on or with the device. • To avoid danger to individuals or the facility, read the "Basic safety instructions" section carefully, as well as all other safety instructions in the document that are specific to working procedures.
Page 3: Table Of Contents
Proline Teqwave MW 500 HART Table of contents Table of contents 6.1.3 Special mounting instructions ..25 About this document ....6 Mounting the measuring device .
Page 4 Table of contents Proline Teqwave MW 500 HART 8.4.7 Logging out ....66 Operation ..... . . 118 Access to the operating menu via the 11.1 Reading off the device locking status .
Page 5 Proline Teqwave MW 500 HART Table of contents Maintenance ....160 13.1 Maintenance work ....160 13.1.1 Exterior cleaning .
Page 6: About This Document
About this document Proline Teqwave MW 500 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Teqwave MW 500 HART About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.2.5 Symbols for certain types of information Symbol...
Page 8: Documentation
About this document Proline Teqwave MW 500 HART Symbol Meaning Safe area (non-hazardous area) Flow direction Documentation For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate •...
Page 9: Safety Instructions
Proline Teqwave MW 500 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Safety instructions Proline Teqwave MW 500 HART NOTICE Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Device-Specific It Security
Proline Teqwave MW 500 HART Safety instructions Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in- operation safety if used correctly. The following list provides an overview of the most...
Page 12: Access Via Web Server
Safety instructions Proline Teqwave MW 500 HART WLAN passphrase: Operation as WLAN access point A connection between an operating unit (e.g. notebook or tablet) and the device via the WLAN interface (→  68), which can be ordered as an optional extra, is protected by the network key.
Page 13: Product Description
Proline Teqwave MW 500 HART Product description Product description The device consists of a transmitter and a sensor. The device is available as a remote version: The transmitter and sensor are mounted in physically separate locations. They are interconnected by connecting cables.
Page 14: Incoming Acceptance And Product
Incoming acceptance and product identification Proline Teqwave MW 500 HART Incoming acceptance and product identification Incoming acceptance Are the order codes on the delivery note (1) and the product sticker (2) identical? Are the goods undamaged? Does the data on the...
Page 15: Product Identification
Proline Teqwave MW 500 HART Incoming acceptance and product identification Product identification The following options are available for identification of the device: • Nameplate • Order code with details of the device features on the delivery note • Enter the serial numbers from the nameplates in the Device Viewer (www.endress.com/deviceviewer): all the information about the device is displayed.
Page 16: Sensor Nameplate
Incoming acceptance and product identification Proline Teqwave MW 500 HART 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0051311 Name of sensor Manufacturer address/certificate holder Order code Serial number (Ser. no.) Extended order code (Ext. ord. cd.) Full scale value;...
Page 17: Symbols On The Device
Proline Teqwave MW 500 HART Incoming acceptance and product identification 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring device to discover the type of potential danger and measures to avoid it.
Page 18: Storage And Transport
Storage and transport Proline Teqwave MW 500 HART Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 19: Packaging Disposal
Proline Teqwave MW 500 HART Storage and transport Packaging disposal All packaging materials are environmentally friendly and 100% recyclable: • Outer packaging of device Stretch wrap made of polymer in accordance with EU Directive 2002/95/EC (RoHS) • Packaging • Wood crate treated in accordance with ISPM 15 standard, confirmed by IPPC logo •...
Page 20: Mounting Procedure
Mounting procedure Proline Teqwave MW 500 HART Mounting procedure Mounting requirements 6.1.1 Mounting position Installation point Installation in pipe Do not install the device: • At the highest point of the pipe (risk of gas bubbles accumulating in the measuring tube) •...
Page 21 Proline Teqwave MW 500 HART Mounting procedure Installation near pumps • Install the device in the direction of flow downstream from the pump. • Also install pulsation dampers if reciprocating, diaphragm or peristaltic pumps are used. A0041083 Installation upstream from a down pipe If installing upstream of down pipes with a length h ≥...
Page 22 Mounting procedure Proline Teqwave MW 500 HART Orientation A0052238 Vertical orientation Horizontal orientation Vertical orientation The device should ideally be installed in a rising pipe: • To avoid having a partially filled pipe • To avoid any gas accumulation • The measuring tube can be completely drained and protected against the buildup of deposits.
Page 23 Proline Teqwave MW 500 HART Mounting procedure Inlet and outlet runs When installing the device, no inlet and outlet runs need to be taken into account. No special precautions need to be taken for fittings that create turbulence, such as valves, elbows or T-pieces, as long as no cavitation occurs.
Page 24: Environmental And Process Requirements
Mounting procedure Proline Teqwave MW 500 HART 6.1.2 Environmental and process requirements Ambient temperature range Technical data for the ambient temperature range →  176 If operating outdoors: • Install the measuring device in a shady location. • Avoid direct sunlight, particularly in warm climatic regions.
Page 25: Special Mounting Instructions
Proline Teqwave MW 500 HART Mounting procedure 6.1.3 Special mounting instructions Weather protection cover 213 (8.4) 203 (8.0) A0029552  5 Unit mm (in) A weather protection cover is available as an accessory.→  163 Endress+Hauser...
Page 26: Mounting The Measuring Device
Mounting procedure Proline Teqwave MW 500 HART Mounting the measuring device 6.2.1 Preparing the measuring device 1. Remove all remaining transport packaging. 2. Remove any protective covers or protective caps present from the sensor. 3. Remove stick-on label on the electronics compartment cover.
Page 27 Proline Teqwave MW 500 HART Mounting procedure A0047715  6 Mounting the sensor Washer Screw/mounting bolt Gasket Screw tightening torques NOTICE Failure to observe screw tightening torques or mounting instructions The process connection may be overloaded if screw tightening torques are not observed or the mounting instructions cannot be followed.
Page 28: Mounting The Transmitter
Mounting procedure Proline Teqwave MW 500 HART Nominal diameter Pressure rating Screws Max. screw tightening torque [mm] [in] [mm] PN 10 12 x M20 220 Nm (162.3 lbf ft) PN 16 12 x M24 250 Nm (184.4 lbf ft) PN 10 12 x M20 220 Nm (162.3 lbf ft)
Page 29 Proline Teqwave MW 500 HART Mounting procedure Wall mounting Required tools: Drill with drill bit ⌀ 6.0 mm 17 (0.67) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0029054  7 Engineering unit mm (in) Depends on order code for "Transmitter housing"...
Page 30: Post-Mounting Check
Mounting procedure Proline Teqwave MW 500 HART Pipe mounting Required tools: • Open-ended wrench AF 10 • Torx screwdriver TX 25 NOTICE Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter. ‣ Tighten the fixing screws as per the tightening torque: 2.5 Nm (1.8 lbf ft) ø...
Page 31: Electrical Connection
Proline Teqwave MW 500 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 32 Electrical connection Proline Teqwave MW 500 HART Relay output Standard installation cable is sufficient. Current input 0/4 to 20 mA Standard installation cable is sufficient Status input Standard installation cable is sufficient Cable diameter • Cable glands supplied: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) •...
Page 33: Terminal Assignment
Proline Teqwave MW 500 HART Electrical connection 7.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 34: Preparing The Connecting Cable
Electrical connection Proline Teqwave MW 500 HART 7.2.5 Preparing the connecting cable When terminating the connecting cable, pay attention to the following points: ‣ For cables with fine-wire cores (stranded cables): Fit the cores with ferrules. Transmitter Sensor 90 (3.54)* 70 (2.76)
Page 35: Connecting The Measuring Device
Proline Teqwave MW 500 HART Electrical connection Connecting the measuring device NOTICE An incorrect connection compromises electrical safety! ‣ Only properly trained specialist staff may perform electrical connection work. ‣ Observe applicable federal/national installation codes and regulations. ‣ Comply with local workplace safety regulations.
Page 36 Electrical connection Proline Teqwave MW 500 HART Connecting the connecting cable to the sensor connection housing 10 (0.4) 3 mm TX 20 TX 20 22 mm 24 mm A0029616 1. Loosen the securing clamp of the housing cover. 2. Unscrew the housing cover.
Page 37 Proline Teqwave MW 500 HART Electrical connection Connecting the connecting cable to the transmitter TX 20 TX 20 10 (0.4) 22 mm 24 mm A0029597 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover.
Page 38: Connecting The Signal Cable And The Supply Voltage Cable
Electrical connection Proline Teqwave MW 500 HART 7.3.2 Connecting the signal cable and the supply voltage cable A0028200 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output Terminal connection for connecting cable between sensor and transmitter Terminal connection for signal transmission, input/output;...
Page 39: Potential Equalization
Proline Teqwave MW 500 HART Electrical connection WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. NOTICE Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter.
Page 40: Special Connection Instructions
Electrical connection Proline Teqwave MW 500 HART Special connection instructions 7.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA A0029055  10 Connection example for 4 to 20 mA HART current output (active) Automation system with current input (e.g. PLC) Ground cable shield at one end.
Page 41 Proline Teqwave MW 500 HART Electrical connection HART input 4...20 mA A0028763  12 Connection example for HART input with a common negative (passive) Automation system with HART output (e.g. PLC) Active barrier for power supply (e.g. RN221N) →  174 Ground cable shield at one end.
Page 42 Electrical connection Proline Teqwave MW 500 HART Pulse/frequency output 12345 A0028761  15 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  170...
Page 43 Proline Teqwave MW 500 HART Electrical connection Current input A0028915  18 Connection example for 4 to 20 mA current input Power supply Terminal box External device (for reading in the flow rate value in order to calculate the load rate)
Page 44: Ensuring The Degree Of Protection
Electrical connection Proline Teqwave MW 500 HART Ensuring the degree of protection The measuring device fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure. To guarantee the degree of protection IP66/67, Type 4X enclosure, carry out the following steps after electrical connection: 1.
Page 45: Post-Connection Check
Proline Teqwave MW 500 HART Electrical connection Post-connection check Are cables or the device undamaged (visual inspection)?  Do the cables used comply with the requirements →  31?  Does the supply voltage match the specifications on the transmitter nameplate →  174? ...
Page 46: Operation Options
Operation options Proline Teqwave MW 500 HART Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 47: Structure And Function Of The Operating Menu
Proline Teqwave MW 500 HART Operation options Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device...
Page 48: Operating Philosophy
Operation options Proline Teqwave MW 500 HART 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter User role and tasks...
Page 49: Access To Operating Menu Via Local Display
Proline Teqwave MW 500 HART Operation options Access to operating menu via local display 8.3.1 Operational display X X X X X X X 5.53 A0051675 Operational display Device tag Status area Display range for measured values (up to 4 lines)
Page 50 Operation options Proline Teqwave MW 500 HART Temperature Conductivity The number and display format of the measured variables can be configured via the Format display parameter (→  97). Totalizer Symbol Meaning Totalizer Output Symbol Meaning Output  The measurement channel number indicates which of the outputs is displayed.
Page 51: Navigation View
Proline Teqwave MW 500 HART Operation options 8.3.2 Navigation view In the submenu In the wizard /../Operation /../Curr. output 1 User role Proc.var.outp Operator Temperature Locking status Display A0053523-EN A0053524-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 52 Operation options Proline Teqwave MW 500 HART Setup Is displayed: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnosis Is displayed: • In the menu next to the "Diagnostics" selection •...
Page 53: Editing View
Proline Teqwave MW 500 HART Operation options 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  21 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 54 Operation options Proline Teqwave MW 500 HART Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. • Pressing the key for > 3 s calls up the wizards: Compare measured value with reference value.
Page 55: Operating Elements
Proline Teqwave MW 500 HART Operation options 8.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist In wizards Goes to previous parameter In the text and numeric editor Move the entry position to the left.
Page 56 Operation options Proline Teqwave MW 500 HART Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 57: Navigating And Selecting From List
Proline Teqwave MW 500 HART Operation options 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 58: Changing The Parameters
Operation options Proline Teqwave MW 500 HART Calling up and closing the help text The user is in the navigation view and the selection bar is on a parameter. 1. Press  for 2 s.  The help text for the selected parameter opens.
Page 59: Disabling Write Protection Via Access
Proline Teqwave MW 500 HART Operation options Access authorization to parameters: "Operator" user role Access code status Read access Write access After an access code has been defined.  – Despite the defined access code, certain parameters can always be modified and thus are excluded from the write protection as they do not affect the measurement: write protection via access code →...
Page 60: Access To Operating Menu Via Web Browser
Operation options Proline Teqwave MW 500 HART Access to operating menu via web browser 8.4.1 Function range With the integrated web server, the device can be operated and configured via a web browser service interface (CDI-RJ45) or WLAN interface. The structure of the operating menu is the same as for the local display.
Page 61: Connecting The Device
Proline Teqwave MW 500 HART Operation options Settings Interface CDI-RJ45 WLAN JavaScript JavaScript must be enabled. JavaScript must be enabled.   If JavaScript cannot be enabled: The WLAN display Enter http://192.168.1.212/servlet/ requires JavaScript basic.html in the address bar of the web support.
Page 62 Operation options Proline Teqwave MW 500 HART 2. Connect the computer to the RJ45 plug via the standard Ethernet cable →  68. 3. If a 2nd network card is not used, close all the applications on the notebook.  Applications requiring Internet or a network, such as e-mail, SAP applications, Internet or Windows Explorer.
Page 63: Logging On
Proline Teqwave MW 500 HART Operation options 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 Device name: Device tag: Signal Status: Web server language...
Page 64: User Interface
Operation options Proline Teqwave MW 500 HART 8.4.5 User interface 2 3 4 Device name: Device tag: Signal Status: Total solids adjustment Measured values Menu Instrument health status Data management Network Main Menü Display language English Operation Setup Diagnostic Expert...
Page 65: Disabling The Web Server
Proline Teqwave MW 500 HART Operation options Functions Meaning Data exchange between computer and measuring device: • Device configuration: • Load settings from the device (XML format, save configuration) • Save settings to the device (XML format, restore configuration) Data management •...
Page 66: Logging Out
Operation options Proline Teqwave MW 500 HART Function scope of the "Web server functionality" parameter Option Description • The Web server is completely disabled. • Port 80 is locked. HTML Off The HTML version of the Web server is not available.
Page 67 Proline Teqwave MW 500 HART Operation options A0028747  24 Options for remote operation via HART protocol (active) Control system (e.g. PLC) Field Communicator 475 Computer with web browser (e.g. Microsoft Edge) to access the integrated device web server or computer with operating tool (e.g.
Page 68 Operation options Proline Teqwave MW 500 HART Service interface Via service interface (CDI-RJ45) A point-to-point connection can be established to configure the device onsite. With the housing open, the connection is established directly via the service interface (CDI-RJ45) of the device.
Page 69 Proline Teqwave MW 500 HART Operation options A0037682 Transmitter with integrated WLAN antenna Transmitter with external WLAN antenna LED lit constantly: WLAN reception is enabled on measuring device LED flashing: WLAN connection established between operating unit and measuring device Computer with WLAN interface and web browser (e.g. Microsoft Internet Explorer, Microsoft Edge) for accessing the integrated device web server or with operating tool (e.g.
Page 70: Field Xpert Sfx350, Sfx370
Operation options Proline Teqwave MW 500 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 71: Devicecare
Proline Teqwave MW 500 HART Operation options Access is via: • HART protocol →  66 • CDI-RJ45 service interface →  68 • WLAN interface →  68 Typical functions: • Transmitter parameter configuration • Loading and saving of device data (upload/download) •...
Page 72: Ams Device Manager
Operation options Proline Teqwave MW 500 HART The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →  74 8.5.5...
Page 73: System Integration
Proline Teqwave MW 500 HART System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.00.zz • On the title page of the manual • On the transmitter nameplate • Firmware version Diagnostics →...
Page 74: Operating Tools
System integration Proline Teqwave MW 500 HART 9.1.2 Operating tools Different operating tools can be used for local or remote access to the measuring device. Depending on the operating tool used, access is possible with different operating units and via a variety of interfaces.
Page 75: Measured Variables Via Hart Protocol
Proline Teqwave MW 500 HART System integration Measured variables via HART protocol 9.2.1 Dynamic variables Measured variables can be assigned to the dynamic variables (PV, SV, TV and QV). This assignment of variables can take place via local operation or via an operating tool.
Page 76: Device Variables
System integration Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection Factory setting Assign TV The Load rate option is only Assign measured variable to • Conductivity Electronics available if the volume flow of the third dynamic variable • Corrected...
Page 77: Other Settings
Proline Teqwave MW 500 HART System integration Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣ Burst configuration 1 to n Burst mode 1 to n →...
Page 78 System integration Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting entry Burst variable 0 The Load rate option is only For HART command 9 and 33: • Conductivity Total solids available if the volume flow of select the HART device •...
Page 79 Proline Teqwave MW 500 HART System integration Parameter Prerequisite Description Selection / User Factory setting entry Min. update period – Enter the minimum time span Positive integer 1 000 ms between two burst commands of burst message X. Max. update period –...
Page 80: Commissioning
Commissioning Proline Teqwave MW 500 HART Commissioning 10.1 Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-mounting" check→  30 • Checklist for "Post-connection check" →  45 10.2...
Page 81: Configuring The Measuring Device
Proline Teqwave MW 500 HART Commissioning 10.5 Configuring the measuring device The Setup menu with its guided wizards contains all the parameters needed for standard operation. X X X X X X X 20.50 Main menu Display language English Display/operat.
Page 82: Defining The Tag Name
Commissioning Proline Teqwave MW 500 HART ‣ Total solids adjustment →  99 ‣ Advanced setup →  100 10.5.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 83: Setting The System Units
Proline Teqwave MW 500 HART Commissioning 10.5.2 Setting the system units In the System units submenu the units of all the measured values can be set. The number of submenus and parameters can vary depending on the device version. Certain submenus and parameters in these submenus are not described in the Operating Instructions.
Page 84: Displaying The I/O Configuration
Commissioning Proline Teqwave MW 500 HART 10.5.3 Displaying the I/O configuration The I/O configuration submenu guides the user systematically through all the parameters in which the configuration of the I/O modules is displayed. Navigation "Setup" menu → I/O configuration ‣...
Page 85: Configuring The Current Input
Proline Teqwave MW 500 HART Commissioning 10.5.4 Configuring the current input The "Current input" wizard guides the user systematically through all the parameters that have to be set for configuring the current input. Navigation "Setup" menu → Current input ‣...
Page 86: Configuring The Status Input
Commissioning Proline Teqwave MW 500 HART 10.5.5 Configuring the status input The Status input submenu guides the user systematically through all the parameters that have to be set for configuring the status input. Navigation "Setup" menu → Status input 1 to n ‣...
Page 87: Configuring The Current Output
Proline Teqwave MW 500 HART Commissioning 10.5.6 Configuring the current output The Current output wizard guides you systematically through all the parameters that have to be set for configuring the current output. Navigation "Setup" menu → Current output ‣ Current output 1 to n Terminal number →...
Page 88 Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Current range output – Select current range for • 4...20 mA NE Depends on country: process value output and (3.8...20.5 mA) • 4...20 mA NE upper/lower level for alarm •...
Page 89: Configuring The Pulse/Frequency
Proline Teqwave MW 500 HART Commissioning 10.5.7 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 90 Commissioning Proline Teqwave MW 500 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode If the Pulse option is selected, Define the output as a pulse, • Pulse Pulse the Load rate option must be frequency or switch output.
Page 91 Proline Teqwave MW 500 HART Commissioning Assign frequency output →  91 Minimum frequency value →  91 →  91 Maximum frequency value Measuring value at minimum →  92 frequency Measuring value at maximum →  92 frequency Failure mode →...
Page 92 Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Measuring value at minimum The Frequency option is Enter measured value for Signed floating-point Depends on country frequency selected in the Operating minimum frequency. number and nominal mode parameter (→...
Page 93 Proline Teqwave MW 500 HART Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  93 Terminal number →  93 Signal mode →  93 Switch output function →...
Page 94 Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior • Limit •...
Page 95: Configuring The Relay Output
Proline Teqwave MW 500 HART Commissioning 10.5.8 Configuring the relay output The Relay output wizard guides the user systematically through all the parameters that have to be set for configuring the relay output. Navigation "Setup" menu → Relay output 1 to n ‣...
Page 96: Configuring The Local Display
Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description User interface / Factory setting Selection / User entry Assign flow direction check The Flow direction check Select process variable for flow option is selected in the Relay direction monitoring. output function parameter. Assign limit •...
Page 97 Proline Teqwave MW 500 HART Commissioning Format display →  97 Value 1 display →  97 →  97 0% bargraph value 1 100% bargraph value 1 →  97 Value 2 display →  98 Value 3 display →...
Page 98 Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting entry Value 2 display • A local display is provided. Select the measured value that • None None • The Load rate option is only is shown on the local display.
Page 99: 10.5.10 "Total Solids Commissioning" Wizard
Proline Teqwave MW 500 HART Commissioning 10.5.10 "Total solids commissioning" wizard The Total solids commissioning wizard is used to perform the basic settings for adjusting the measured value based on a reference value. Wizard description →  129. Navigation "Setup" menu → Total solids commissioning ‣...
Page 100: Advanced Settings
Commissioning Proline Teqwave MW 500 HART 10.6 Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 Main menu Display language English...
Page 101: Using The Parameter To Enter The Access Code
Proline Teqwave MW 500 HART Commissioning ‣ WLAN settings →  106 ‣ Heartbeat setup →  107 ‣ →  108 Configuration backup ‣ Administration →  110 10.6.1 Using the parameter to enter the access code Navigation "Setup" menu → Advanced setup...
Page 102: Configuring The Totalizer
Commissioning Proline Teqwave MW 500 HART 10.6.2 Configuring the totalizer The totalizer is used to calculate the total load rate. The Load rate option is only available if the volume flow of the medium is read in via the Current input 1 to n.
Page 103: Carrying Out Additional Display Configurations
Proline Teqwave MW 500 HART Commissioning 10.6.3 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display Format display →...
Page 104 Commissioning Proline Teqwave MW 500 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 105 Proline Teqwave MW 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 3 A measured value is specified Select the number of decimal • x x.xx in the Value 3 display places for the display value. • x.x parameter.
Page 106: Wlan Configuration
Commissioning Proline Teqwave MW 500 HART 10.6.4 WLAN configuration The WLAN Settings submenu guides the user systematically through all the parameters that have to be set for the WLAN configuration. Navigation "Setup" menu → Advanced setup → WLAN settings ‣...
Page 107: Heartbeat Technology Application
Proline Teqwave MW 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Network security – Select the security type of the • Unsecured WPA2-PSK WLAN network. • WPA2-PSK • EAP-PEAP with MSCHAPv2 • EAP-PEAP MSCHAPv2 no server authentic.
Page 108: Configuration Management
Commissioning Proline Teqwave MW 500 HART 10.6.6 Configuration management After commissioning, you can save the current device configurationor restore the previous device configuration. The device configuration is managed via the Configuration management parameter. Navigation "Setup" menu → Advanced setup → Configuration backup ‣...
Page 109 Proline Teqwave MW 500 HART Commissioning Function scope of the "Configuration management" parameter Options Description Cancel No action is executed and the user exits the parameter. Execute backup A backup copy of the current device configuration is saved from the HistoROM backup to the memory of the device.
Page 110: Using Parameters For Device Administration
Commissioning Proline Teqwave MW 500 HART 10.6.7 Using parameters for device administration The Administration submenu systematically guides the user through all the parameters that can be used for device administration purposes. Navigation "Setup" menu → Advanced setup → Administration ‣...
Page 111 Proline Teqwave MW 500 HART Commissioning Parameter overview with brief description Parameter Description User interface / User entry Factory setting Operating time Indicates how long the device has been in Days (d), hours (h), minutes – operation. (m) and seconds (s) Reset access code...
Page 112: Simulation
Commissioning Proline Teqwave MW 500 HART 10.7 Simulation Via the Simulation submenu, it is possible to simulate various process variables in the process and the device alarm mode and verify downstream signal chains (switching valves or closed-control loops). The simulation can be performed without a real measurement (no flow of medium through the device).
Page 113 Proline Teqwave MW 500 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign simulation process variable The Load rate option is only Select a process variable for • Off available if the volume flow of the simulation process that is •...
Page 114 Commissioning Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting entry Diagnostic event category – Select a diagnostic event • Sensor Process category. • Electronics • Configuration • Process Diagnostic event simulation – Select a diagnostic event to •...
Page 115: Protecting Settings From Unauthorized Access
Proline Teqwave MW 500 HART Commissioning 10.8 Protecting settings from unauthorized access The following write protection options exist in order to protect the configuration of the measuring device from unintentional modification: • Protect access to parameters via access code →  115 •...
Page 116: Write Protection Via Write Protection
Commissioning Proline Teqwave MW 500 HART 2. Define a 16-digit (max.) numeric code as the access code. 3. Enter the access code again in the Confirm access code parameter (→  110) to confirm.  The web browser switches to the login page.
Page 117 Proline Teqwave MW 500 HART Commissioning Enable/disable write protection A0029673 1. Open the housing cover. 2. Remove the display module. 3. Fold open the terminal cover. 4. Enable or disable write protection: Move the write protection switch on the main electronics module into position: ON hardware write protection enabled/OFF (factory setting) hardware write protection disabled.
Page 118: Operation
Operation Proline Teqwave MW 500 HART Operation 11.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 119: Reading Off Measured Values
Proline Teqwave MW 500 HART Operation 11.5 Reading off measured values With the Measured values submenu, it is possible to read all the measured values. Navigation "Diagnostics" menu → Measured values ‣ Measured values ‣ Process variables →  119 ‣...
Page 120: Input Values" Submenu
Operation Proline Teqwave MW 500 HART Parameter Prerequisite Description User interface Conductivity – Shows the conductivity currently Floating-point number measured. Corrected conductivity – Shows the conductivity measured Floating-point number compensated for temperature. Load rate The volume flow of the medium is read Shows the total solids flow rate.
Page 121: Output Values
Proline Teqwave MW 500 HART Operation Navigation "Diagnostics" menu → Measured values → Input values → Status input 1 to n ‣ Status input 1 to n Value status input →  121 Parameter overview with brief description Parameter Description...
Page 122 Operation Proline Teqwave MW 500 HART Parameter overview with brief description Parameter Description User interface Output current Displays the current value currently calculated for the current 3.59 to 22.5 mA output. Measured current Displays the current value currently measured for the current 0 to 30 mA output.
Page 123: Totalizer" Submenu
Proline Teqwave MW 500 HART Operation Parameter overview with brief description Parameter Description User interface Switch state Indicates the current switch state of the output. • Open • Closed Switch cycles Shows number of all performed switch cycles. Positive integer Max.
Page 124: Performing A Totalizer Reset
Operation Proline Teqwave MW 500 HART 11.6 Performing a totalizer reset The totalizers are reset in the Operation submenu: • Control Totalizer • Reset all totalizers Navigation "Operation" menu → Totalizer handling ‣ Totalizer handling →  124 Control Totalizer 1 to n Preset value 1 to n →...
Page 125: Function Range Of "Reset All Totalizers" Parameter
Proline Teqwave MW 500 HART Operation Options Description Preset + totalize The totalizer is set to the defined start value in the Preset value parameter and the totaling process is restarted. Hold Totalizing is stopped. Visible depending on the order options or device settings 11.6.2...
Page 126: Displaying The Measured Value History
Operation Proline Teqwave MW 500 HART 11.7 Displaying the measured value history The Extended HistoROM application package must be enabled in the device (order option) for the Data logging submenu to appear. This contains all the parameters for the measured value history.
Page 127 Proline Teqwave MW 500 HART Operation Data logging control →  128 Data logging status →  128 →  128 Entire logging duration ‣ Display channel 1 ‣ Display channel 2 ‣ Display channel 3 ‣ Display channel 4...
Page 128 Operation Proline Teqwave MW 500 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 4 • The Load rate option is only Assign a process variable to For the picklist, see available if the volume flow logging channel.
Page 129: Adjusting The Measured Value With The Aid Of
Proline Teqwave MW 500 HART Operation 11.8 Adjusting the measured value with the aid of wizards In practice, the measurement typically needs to be adjusted based a reference value (e.g. lab value) when commissioning the device to ensure optimum measurement performance during subsequent operation.
Page 130 Operation Proline Teqwave MW 500 HART Taking a sample The 1 - Take a sample wizard is used to: • set the system time (if not already defined in the Commissioning wizard) • have the total solids measured by the device •...
Page 131: Calling Up Wizards
Proline Teqwave MW 500 HART Operation 11.8.3 Calling up wizards • Commissioning wizard The wizard is called up via the main menu: Setup → Total solids adjustment → Commissioning • Take a sample wizard, Enter lab value wizard and Assistent Perform adjustment: You can call up the wizard options via the operating menu or during local operation from the operational display by holding down the Enter key...
Page 132 Operation Proline Teqwave MW 500 HART 2. Select Total solids adjustment.  The available wizards are displayed. Endress+Hauser Device name Device tag Status signal Total solids adjustment Menu Instrument health status Data management Network Logout (Maintenance) Measured values Main menu >...
Page 133: Diagnosis And Troubleshooting
Proline Teqwave MW 500 HART Diagnosis and troubleshooting Diagnosis and troubleshooting 12.1 General troubleshooting For local display Fault Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 134 Diagnosis and troubleshooting Proline Teqwave MW 500 HART Fault Possible causes Remedial action Device measures incorrectly. Configuration error or device is operated outside 1. Check and correct parameter configuration. the application. 2. Observe limit values specified in the "Technical Data".
Page 135 Proline Teqwave MW 500 HART Diagnosis and troubleshooting Fault Possible causes Remedial action Operation with FieldCare or DeviceCare via Firewall of the PC or network is blocking Depending on the settings of the firewall used service interface CDI-RJ45 (port 8000) is not communication.
Page 136: Diagnostic Information Via Leds
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.2 Diagnostic information via LEDs 12.2.1 Transmitter Different LEDs in the transmitter provide information on the device status. A0029689 Supply voltage Device status Not used Communication Service interface (CDI) active 1. Open the housing cover.
Page 137: Sensor Connection Housing
Proline Teqwave MW 500 HART Diagnosis and troubleshooting Color/behavior Meaning White Communication active. Service interface (CDI) LED off Not connected or no connection established. Yellow Connected and connection established. Flashing yellow Service interface active. 12.2.2 Sensor connection housing Various light emitting diodes (LED) on the ISEM electronics unit (intelligent sensor electronics module) in the sensor connection housing provide information about the device status.
Page 138: Diagnostic Information On Local Display
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 139 Proline Teqwave MW 500 HART Diagnosis and troubleshooting Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 140: Calling Up Remedial Measures
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 141: Diagnostic Information In The Web Browser
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.4 Diagnostic information in the web browser 12.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 142: Calling Up Remedy Information
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 143: Diagnostic Information In Fieldcare Or
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.5 Diagnostic information in FieldCare or DeviceCare 12.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 144: Calling Up Remedy Information
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 145: Adapting The Diagnostic Information
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 146 Diagnosis and troubleshooting Proline Teqwave MW 500 HART Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 147: Overview Of Diagnostic Information
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.7 Overview of diagnostic information In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed. Change the diagnostic information →  145 Diagnostic...
Page 148 Diagnosis and troubleshooting Proline Teqwave MW 500 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Firmware update failed 1. Update firmware of device Warning 2. Restart device Writing in HistoROM 1. Replace user interface board...
Page 149 Proline Teqwave MW 500 HART Diagnosis and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Current input 1 to n Deactivate simulation Warning simulation active Current output 1 to n Deactivate simulation...
Page 150 Diagnosis and troubleshooting Proline Teqwave MW 500 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Conductivity out of 1. Check process conditions Warning specification 2. Clean measuring tube 3. Replace sensor electronic module...
Page 151: Pending Diagnostic Events
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 152 Diagnosis and troubleshooting Proline Teqwave MW 500 HART / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  33 Using the example of the local display To call up the measures to rectify a diagnostic event: • Via local display →  140 •...
Page 153: 12.10 Event Logbook
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.10 Event logbook 12.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Events list / ../Eventlist...
Page 154: 12.10.3 Overview Of Information Events
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 155 Proline Teqwave MW 500 HART Diagnosis and troubleshooting Info number Info name I1625 Write protection activated I1626 Write protection deactivated I1627 Web server: login successful I1628 Display: login successful I1629 CDI: login successful I1631 Web server access changed I1632 Display: login failed...
Page 156: 12.11 Resetting The Measuring Device
Diagnosis and troubleshooting Proline Teqwave MW 500 HART 12.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→  111). 12.11.1 Function range of "Device reset" parameter...
Page 157: 12.12 Device Information
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  157 Serial number →...
Page 158 Diagnosis and troubleshooting Proline Teqwave MW 500 HART Parameter Description User interface Factory setting Device name Shows the name of the transmitter. Character string comprising – numbers, letters and special  The name can be found on the characters nameplate of the transmitter.
Page 159: 12.13 Firmware History
Proline Teqwave MW 500 HART Diagnosis and troubleshooting 12.13 Firmware history Release Firmware Order code Firmware Documentation type Documentation date version Changes "Firmware version" 03.2024 01.00.zz Option 76 Original firmware Operating BA02322D/06/EN/03.24 instructions It is possible to flash the firmware to the current version or the previous version using the service interface.
Page 160: Maintenance
Maintenance Proline Teqwave MW 500 HART Maintenance 13.1 Maintenance work No special maintenance work is required. 13.1.1 Exterior cleaning When cleaning the exterior of measuring devices, always use cleaning agents that do not attack the surface of the housing or the gaskets.
Page 161: Repair
Proline Teqwave MW 500 HART Repair Repair 14.1 General notes 14.1.1 Repair and conversion concept The Endress+Hauser repair and conversion concept provides for the following: • The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions.
Page 162: Disposal
Repair Proline Teqwave MW 500 HART 14.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 163: Accessories
Proline Teqwave MW 500 HART Accessories Accessories Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 164: For The Sensor
Accessories Proline Teqwave MW 500 HART 15.1.2 For the sensor Accessories Description Mounting kit Consists of: • Screws/mounting bolts • Gaskets • Washers • Nuts  Order number: DK4M 15.2 Communication-specific accessories Accessories Description Commubox FXA195 For intrinsically safe HART communication with FieldCare via the USB port.
Page 165: Service-Specific Accessories
Proline Teqwave MW 500 HART Accessories 15.3 Service-specific accessories Accessories Description Applicator Software for selecting and sizing Endress+Hauser measuring devices: • Choice of measuring devices for industrial requirements • Graphic display of the calculation results • Determination of the partial order code, administration, documentation and access to all project-related data and parameters over the entire life cycle of a project.
Page 166: Technical Data
Technical data Proline Teqwave MW 500 HART Technical data 16.1 Application The measuring device is suitable only for the measurement of solids in water-based liquids. Depending on the version ordered, the measuring device can also measure potentially explosive media. To ensure that the device remains in proper operating condition for its service life, use the measuring device only for media against which the process-wetted materials are sufficiently resistant.
Page 167 Proline Teqwave MW 500 HART Technical data Measuring range Total solids 0 to 500 g/l (0 to 31 lb/ft ), 0 to 50 %TS Medium temperature 0 to 80 °C (32 to 176 °F) Electrical conductivity To ensure correct measurement, the electrical conductivity of the medium must not exceed the measuring range of the temperature-compensated electrical conductivity.
Page 168 Technical data Proline Teqwave MW 500 HART Open-circuit voltage ≤ 28.8 V (active) Possible input variables Volume flow of the medium for calculating the load rate Status input Order code "Output; input 2" (021), "Output; input 3" (022) or "Output; input 4" (023): option...
Page 169: Output
Proline Teqwave MW 500 HART Technical data 16.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (020): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: • Active •...
Page 170 Technical data Proline Teqwave MW 500 HART Pulse/frequency/switch output Order code "Output; input 2" (021), "Output; input 3" (022) or "Output; input 4" (023): option E: Pulse/frequency/switch output Function Can be configured as pulse, frequency or switch output Version Open collector Can be set to: •...
Page 171 Proline Teqwave MW 500 HART Technical data Relay output Order code "Output; input 2" (021), "Output; input 3" (022) or "Output; input 4" (023): option H: relay output Function Switch output Version Relay output, galvanically isolated Switching behavior Can be set to: •...
Page 172 Technical data Proline Teqwave MW 500 HART Pulse/frequency/switch output Pulse output Fault mode Choose from: • Actual value • No pulses Frequency output Fault mode Choose from: • Actual value • 0 Hz • Definable value between: 2 to 12 500 Hz...
Page 173: Power Supply
Proline Teqwave MW 500 HART Technical data Load Output signal →  169 Ex connection data Safety-related values Order code for "Output; input 1" Option Output/input type Safety-related values for output/input 1 26 (+) 27 (–) Current output 4 to 20 mA HART...
Page 174 Technical data Proline Teqwave MW 500 HART Device plug for connecting to the service interface: Order code for "Accessory mounted" Option NB, RJ45 M12 adapter (service interface) →  175 Order code for "Accessory mounted", option NB "Adapter RJ45 M12 (service interface)"...
Page 175: Performance Characteristics
Proline Teqwave MW 500 HART Technical data Cable entries • Cable gland: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) • Thread for cable entry: • NPT ½" • G ½" • M20 Optional: M12 device plug for connection to the service interface Order code for "Accessories mounted", option NB: "Adapter RJ45 M12 (service...
Page 176: Mounting
Technical data Proline Teqwave MW 500 HART Repeatability Total solids Nominal diameter Standard deviation of total solids [mm] [in] [%TS] 50 to 80 2 to 3 0.02 100 to 300 4 to 12 0.01 Medium temperature ± 0.5 °C (± 0.9 °F) Electrical conductivity μS/cm...
Page 177 Proline Teqwave MW 500 HART Technical data If operating the device outdoors: • Install the measuring device in a shady location. • Avoid direct sunlight, particularly in warm climatic regions. • Avoid direct exposure to weather conditions. • Protect the display against impact.
Page 178: Process
Technical data Proline Teqwave MW 500 HART Electromagnetic As per IEC/EN 61326 compatibility (EMC) 16.9 Process Medium temperature range 0 to +80 °C (+32 to +176 °F) Electrical conductivity To ensure correct measurement, the electrical conductivity of the medium must not exceed the measuring range of the temperature-compensated electrical conductivity.
Page 179 Proline Teqwave MW 500 HART Technical data Connection housing and sensor Nominal diameter Weight [mm] [in] 8.1 kg (17.8 lb) 8.4 kg (18.4 lb) 10.0 kg (22.0 lb) 14.5 kg (32.1 lb) 21.3 kg (47.0 lb) 30.2 kg (66.6 lb) 35.2 kg (77.6 lb)
Page 180 Technical data Proline Teqwave MW 500 HART Cable entries and adapters Material Cable gland M20 × 1.5 Plastic • Adapter for cable entry with female thread G ½" Nickel-plated brass • Adapter for cable entry with female thread NPT ½"...
Page 181 Proline Teqwave MW 500 HART Technical data Mounting kit For installing the sensor • Screws/mounting bolts, nuts and washers: stainless steel, 1.4301/304, 1.4306/1.4307 • Gaskets: aramid fibers, with NBR binder Pipe mounting For mounting the transmitter on a pipe • Screws, threaded bolts, washers, nuts: stainless steel, 1.4301/304, 1.4306/1.4307 •...
Page 182: 16.11 Display And User Interface
Technical data Proline Teqwave MW 500 HART 16.11 Display and user interface Operation concept Operator-oriented menu structure for user-specific tasks • Commissioning • Operation • Diagnosis • Expert level Quick and safe commissioning • Guided menus ("Make-it-run" wizards) for applications •...
Page 183 Proline Teqwave MW 500 HART Technical data A0037255  37 Operation with touch control Display elements • 4-line, illuminated, graphic display • White background lighting; switches to red in event of device errors • Format for displaying measured variables and status variables can be individually...
Page 184 Technical data Proline Teqwave MW 500 HART A0028746  39 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 185 Proline Teqwave MW 500 HART Technical data Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" A0052608 Transmitter with integrated WLAN antenna...
Page 186 Technical data Proline Teqwave MW 500 HART NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 187 Proline Teqwave MW 500 HART Technical data Supported operating Operating unit Interface Additional information tools Web browser Notebook, PC or tablet • CDI-RJ45 service Special Documentation for the with web browser interface device →  193 • WLAN interface DeviceCare SFE100 Notebook, PC or tablet •...
Page 188 Technical data Proline Teqwave MW 500 HART • Flash firmware version for device firmware upgrade, for example • Download driver for system integration • Visualize up to 1000 saved measured values (only available with the Extended HistoROM application package) HistoROM The measuring device features HistoROM data management.
Page 189: 16.12 Certificates And Approvals
Proline Teqwave MW 500 HART Technical data Data transmission Manual Transfer of a device configuration to another device using the export function of the specific operating tool, e.g. with FieldCare, DeviceCare or Web server: to duplicate the configuration or to store in an archive (e.g. for backup purposes)
Page 190 Technical data Proline Teqwave MW 500 HART Ex-approval The devices are certified for use in hazardous areas and the relevant safety instructions are provided in the separate "Safety Instructions" (XA) document. Reference is made to this document on the nameplate.
Page 191 Proline Teqwave MW 500 HART Technical data • NAMUR NE 105 Specifications for integrating fieldbus devices in engineering tools for field devices • NAMUR NE 107 Self-monitoring and diagnosis of field devices • NAMUR NE 131 Requirements for field devices for standard applications...
Page 192: 16.13 Application Packages
Technical data Proline Teqwave MW 500 HART 16.13 Application packages Many different application packages are available to enhance the functionality of the device. Such packages might be needed to address safety aspects or specific application requirements. The application packages can be ordered with the device or subsequently from Endress+Hauser.
Page 193: 16.14 Supplemental Documentation
Proline Teqwave MW 500 HART Technical data 16.14 Supplemental documentation For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate.
Page 194 Technical data Proline Teqwave MW 500 HART Installation instructions Contents Note Installation instructions for spare part sets and • Call up an overview of all available spare part sets accessories available using Device Viewer: www.endress.com/deviceviewer • Accessories available for order with Installation Instructions →...
Page 195: Index
Proline Teqwave MW 500 HART Index Index Connecting the measuring device Proline 500 ......35...
Page 196 Index Proline Teqwave MW 500 HART Display Field of application see Local display Residual risks ......10...
Page 197 Proline Teqwave MW 500 HART Index Languages, operation options ....182 Nameplate Line recorder ......126 Sensor .
Page 198 Index Proline Teqwave MW 500 HART Pulse/frequency/switch output (Wizard) . . 89, 90, 93 Return ........161 Pulse/frequency/switch output 1 to n (Submenu) 122 Relay output .
Page 199 Proline Teqwave MW 500 HART Index Events list ......153 Totalizer Heartbeat setup ......107 Configuring .
Page 200 *71637045* 71637045 www.addresses.endress.com...

Endres Proline Teqwave MW 500 Operating Instructions Manual

1 About this Document

2 Safety Instructions

3 Product Description

4 Incoming Acceptance and Product

Identification

5 Storage and Transport

6 Mounting Procedure

Electrical Connection

8 Operation Options

9 System Integration

10 Commissioning

11 Operation

12 Diagnosis and Troubleshooting

13 Maintenance

14 Repair

15 Accessories

16 Technical Data

Index

Quick Links

Need help?

Questions and answers

Summary of Contents for Endres Proline Teqwave MW 500

Table of Contents
