PedalPCB Prismatic Distortion Manual page 2

LOCATION VALUE
R1 1M
R2 220K
R3 10K
R4 10K
R5 10K
R6 22K
R7 33K
R8 33K
R9 220K
R10 5K6
R11 10K
R12 10K
R13 10K
R14 100K
R15 10K
R16 10K
R17 5K6
R18 22K
R19 220K
R20 470R
R21 1K
CLR 4K7
C1 100n
C2 10u
C3 10n
C4 10n
C5 100n
C6 100n
C7 100n
C8 100n
C9 6n8
C10 6n8
C11 10u
C100 10u
D1 1N4148
D2 1N4148
D3 1N4148
D4 1N4148
D100 1N5817
Q1 BC182
IC1 MC1458P
IC2 LM741CN
LEVEL A10K
ATTACK A100K
First batch of PCBs are incorrectly marked BC182L. BC182 with L suffix have
a different pinout and should not be used.
Prismatic Distortion
Prismatic Distortion
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Film capacitor, 7.2 x 5.0mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
Schottky diode, DO-41
BJT transistor, NPN TO-92
Dual op-amp, DIP8
Single op-amp, DIP8
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Copyright © 2024 - PedalPCB.com
NOTES
* LED current limiting resistor
See note below
Page 2 of 5
