Bg SyncEV Mode 2 User Manual

User Guide
Mode 2 EV Charger
This BG SyncEV Mode 2 charger is intended for use with electric and hybrid vehicles. Please read and
use in accordance with these safety instructions. Please retain instructions for reference, or scan the QR
code.
SAFETY INSTRUCTIONS
Always inspect before use, do not use if the Electric Vehicle Supply Equipment (EVSE) plug, or cable is damaged.
Do not use with an extension lead or adaptor.
Connect the charging cable to a correctly functioning and fixed socket outlet marked with 'BS1363/EV'.
The user is responsible for any personal injury or vehicle or property damage arising from inappropriate use.
Do not use subject the product to corrosive liquid, flammable dust, or in strong corrosive environments.
Use and store within the service conditions stated in the Technical data.
The storage or use shall not exceed the service condition stated as above. Misuse such as dropping, immersion may cause the
risk or damage.
Do not immerse the product in the water, protect the plug and cable from moisture.
Do not use in a corrosive liquid, flammable dust, or strong corrosive environment.
OPERATING INSTRUCTIONS & INDICATOR STATUS
1. Insert 3-pin plug into wall socket (and switch on) – Charger starts self test mode, LED will flash green & red alternatively x3 times.
Approximately 5 seconds. After test Green indicator should appear 'Ready', if Red check fault guide.
2. Connect to EV – the charger will then start communication with the car, indicator will flash Green fast.
3. Charging – Green indicator slow pulse. Once charged indicator will flash Green fast.
4. To end charging remove disconnect (turn off) from wall socket, and remove charger from EV.
Action
Connect to wall socket
Ready
Connect to EV
Charging
Fault
TECHNICAL
Voltage: 230V~
Output : 2.3kW Max
Frequency: 50Hz
Power supply system: TN-S system
Residual Operating Current:
Operating Temperature: -25~+45 deg C
Relative humidity: MAX 75%/40℃
IP Rating (Function box): IP65
Altitude: up to 2000m
Standards: BS EN 62752, BS EN 61851-1
Mode 2 EV Charger | EVCM.202308.AY
Indicator Status
Green & Red alternate flash x3
Green On
Green fast flash
Green pulse
Red
I n: 30mA, 6mA DC
Remark
Self-test procedure (approx. 5s)
Communication test
See Fault Guide
www.syncev.co.uk
