Model no. FA-43G, FA-62G
Art. 413880, 424751, 424752
3-way absorption refrigerator
Gas - AC 230~240V - DC 12V
Instructions for use
2531
P.I.N Code: 2531DL-0091
Important: Please read these instructions before using this refrigerator. Keep
these instructions for future reference.
Note:
This refrigerator has been designed and manufactured for outdoor use.
Therefore, use it with good ventilation and in an easily accessible, level area.
Keep it away from hazardous areas and fire.
1
Advertisement
Table of Contents
Summary of Contents for Compass FA-43G
- Page 1 Model no. FA-43G, FA-62G Art. 413880, 424751, 424752 3-way absorption refrigerator Gas - AC 230~240V - DC 12V Instructions for use 2531 P.I.N Code: 2531DL-0091 Important: Please read these instructions before using this refrigerator. Keep these instructions for future reference.
- Page 3 12V connection connection 230V~ connection cable Cooling System Burner cover Contents...
-
Page 4: Table Of Contents
1. Explanation of the symbols 2. Safety instructions 2.1. General safety 2.2. Safe operation of the device 3. Scope of delivery 4. Intended use 5. Functional description 5.1. Range of functions 5.2. Operating and display elements. 6. Operation 6.1. Before initial commissioning. 6.2. -
Page 5: Explanation Of The Symbols
1. Explanation of the symbols DANGER! Safety instruction: Failure to observe this instruction will result in death or serious injury. WARNING! Safety instruction: Failure to observe this instruction will result in death or serious injury. CAUTION! Safety instruction: Failure to observe this instruction may result in injury. NOTE! Safety note: Failure to observe this note can lead to material damage and impair the function of the product. - Page 6 • Children must be supervised to ensure that they do not play with the product. • Keep the appliance out of the reach of children under the age of 8. • Do not store explosive materials, such as aerosols with flammable propellants, inside the product.
-
Page 7: Safe Operation Of The Device
Please note! • Check that the voltage specified on the type plate matches that of the power supply. • Connect the unit only as follows - With a DC cable to a DC socket in the vehicle (e.g. cigarette lighter). - Or with an AC power cable to an AC power socket. -
Page 8: Scope Of Delivery
• Ensure that the unit is placed far enough away from walls and other objects to allow air circulation. • Ensure that the ventilation openings are not covered. • Do not fill the inner compartment with ice or liquids. • Do not immerse the unit in water. -
Page 9: Intended Use
4. intended use Main switch on the control panel The refrigerator is suitable for domestic use (mains supply), for use on a 12 V vehicle socket (e.g. cigarette lighter), on a boat or in a caravan, or for use with a gas cylinder. Before deciding which option to use and putting the refrigerator into operation, please read the instructions for preparing the power supply and switching off the appliance. -
Page 10: Operating And Display Elements
5.2 Operating and display elements Article description Main switch Thermostat for alternating current operation Gas ignition (main switch on GAS) Gas indicator (function when the pin is green) Removable partition x 2 Door shelf x 2 Evaporator cooling element... -
Page 11: Operation
6. operation 6.1 Before initial commissioning NOTE For hygienic reasons, you should clean the inside and outside of your new refrigerator with a damp cloth before using it for the first time (see also "Cleaning and maintenance" on page 19). NOTICE! Danger of overheating! Always ensure adequate ventilation to dissipate the heat generated during operation. -
Page 12: Use Of The Refrigerator
6.3 Use of the refrigerator The Main switch (rotary knob) on the left-hand side of the control panel is in the OFF position when the unit is unpacked. Connection to 230V~ mains ⚠Danger! Never touch the plugs and switchs with wet hands or when standing on a wet surface. - Page 13 After about 2 hours of operation, you will notice a significant drop in temperature. If the temperature in the refrigerator is too low, you can set the temperature from MAX to half of MIN to prevent your stored food, fresh vegetables or drinks from freezing.
- Page 14 The fridge does not have a DC thermostat. Therefore, you should not use the refrigerator in extremely low ambient temperatures to avoid freezing or damaging food, fresh vegetables, fruit or drinks. NOTE! To switch off the DC, simply switch off the unit and then switch off the power supply.
- Page 15 Prevent rain or water from entering the refrigerator as it works with the burner system at the back of the refrigerator. Do not use the gas-powered refrigerator in an underground or enclosed space. Do not operate the gas refrigerator in direct sunlight. ...
- Page 16 Ensure that the hose is not blocked, kinked or in contact with any part of the refrigerator other than the connector. The pressure regulator must be suitable for butane (28 mbar) or propane (37 mbar). Use a suitable regulator certified according to EN 16129: 2013. To connect the pressure regulator to the gas cylinder, the cylinder valve must be closed.
- Page 17 SWITCH ON Switch on your gas regulator or open the valve on the gas cylinder and follow the 3 steps below. The first time you switch on the gas supply, you must press for a long time to release the air from the regulator hose. You will then be able to light the gas in a short time.
-
Page 18: Switch Off The Refrigerator
6.4 Switching off the refrigerator • Empty the fridge • Switch off the refrigerator's power supply • Disconnect the connection cable or power supply, including gas. If you do not want to use the refrigerator for a longer period of time: •... -
Page 19: Complete Shutdown Of Gas Operation
7. complete shutdown of gas operation Turn the switch to the OFF 0 position (as shown below) to turn off the gas supply. Remember to close the gas cylinder or gas supply when it is completely shut off. 8. Manual defrosting If you find that too much ice on the evaporator is preventing the fridge from cooling down, remove all food and drink from the fridge. -
Page 20: Guarantee
NOTE! If the appliance is not to be used for a long period, switch it off, defrost, clean and dry it, and leave the door open to prevent the formation of mould in or on the appliance.. 10. guarantee The statutory warranty period applies. If the product is defective, please contact your nearest customer service centre. -
Page 21: Troubleshooting
11. troubleshooting. Error Possible cause Proposed remedy Device has no No voltage (12V or Please check whether function 230V~) is present. the power supply is switched on. Try a different socket if necessary. No voltage at the Check the fuse in the 12V input cigarette lighter plug and replace it if necessary. - Page 22 If possible, dispose of the packaging material in the designated waste containers. If you wish to dispose of this product, please contact your local recycling centre or dealer for details. NOTE If the ambient temperature is above +32°C, the minimum temperature cannot be reached.
-
Page 23: Technical Data
13 Technical data Type FA-43G FA-62G Capacity 43 litres 61 litres Climate class N, SN Ambient temperature +10°C to 32°C Refrigerant ammonia Insulation Cyclopentane AC supply 230V~/50Hz, 80W, 0.4A 230V~/50Hz, 90W, 0.45A DC supply 12V-, 85W, 7.5A 12V-, 95W, 8.5A... - Page 24 This appliance must be installed in accordance with the applicable regulations. This appliance must be installed in accordance with the manufacturer's instructions. Use only in a well-ventilated area, above ground level and protected from rain. Compass Yachtzubehör Handels GmbH & Co KG Lüdinghauser Street 34 D-59387 Ascheberg...
