- Page 1 Solar station OPTION Produce your own energy Installation manual Ref. 127120 Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 2 Introduction Thank you for purchasing an Avidsen solar station. Before starting the installation, you must inform your distribution grid operator, Enedis, using the CACSI form (Agreement for self-consumption without injection for an electricity production facility). This form is available on the service-public.fr website and should be submitted to your distribution grid operator ( https://www.service-...
-
Page 3: Kit Contents
Kit contents Installation manual - Solar station - Avidsen - Ref. 127120... -
Page 4: Equipment Required For Installation
Not included in this kit - For floor installation 4 sand bags (5 kg min. per bag) To ballast the brackets of the 4 solar panels and ensure the stability of the installation Installation manual - Solar station - Avidsen - Ref. 127120... - Page 5 Assembling solar panels Parts to be assembled Handle solar panels with care. Place a piece of cardboard or a blanket Tools needed under the panel before assembling the parts. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 6 Assembling solar panels Carefully turn the assembled solar panel over. Assembly of the solar panel is now complete. Repeat this assembly for 3 solar panels. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 7 The inverter is attached to this solar panel. Parts to be assembled Handle solar panels with care. Place a piece of cardboard or a blanket Tools needed under the panel before assembling the parts. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 8 Assembling solar panels Carefully turn the assembled solar panel over. Assembly of the solar panel with the inverter plate is now complete. Installation manual - Solar station - Avidsen - Ref. 127120...
-
Page 9: Installing The Inverter
Installing the inverter Parts to be assembled Screw on the in- verter antenna. Tools needed Installation manual - Solar station - Avidsen - Ref. 127120... -
Page 10: Installation
If you are mounting your panels on a wall, go straight to Chapter 7. If you are installing your panels on a balcony, go to Chapter 8 (optional balcony kit). Installation manual - Solar station - Avidsen - Ref. 127120... -
Page 11: Floor Installation
(lawn, terrace, etc.) at the desired final location. The Soria Avidsen solar station should ideally face south, or in any event south-east or south-west. Choose a sunny spot from morning to evening, with no shade, to optimise the performance of the station. - Page 12 The Soria solar station must be weighted down using sand bags placed at the read of each structure to ensure its stability. Note: Remove the transparent protective film from the solar panel frames. 5 kg min. 5 kg min. Installation manual - Solar station - Avidsen - Ref. 127120...
-
Page 13: Wall Mounting
If you opt for wall mounting, they should be positioned side by side on a wall, in keeping with the installation instructions below. The Soria Avidsen solar station should ideally face south, or in any event south-east or south-west. Choose a sunny wall from morning to evening, with no shade, to optimise the performance of the station. - Page 14 Wall mounting Warning: Before you start installing the Soria Avidsen solar station on a wall, make sure you have a minimum width of 3.07 m. If you are installing the panels at a height of more than 1.80 m, you may need to apply to your local council.
- Page 15 The upper part of the bracket must be positioned in the middle of the solar panel. Tools needed Use plugs and screws that are suitable for the bracket. 22 cm 22 cm 32 cm Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 16 Wall mounting Level Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 17 22 cm 3.07 m Installing the lower part of the wall bracket (locking tab) Parts to be installed Tools needed Use plugs and screws that are suitable for the bracket. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 18 Installation of the lower part of the solar panel bracket is now complete. Repeat this installation for the other 3 solar panels. Installation of your solar station on the wall is now complete. Go to Chapter 9 to make the connections. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 19 If you opt for a balcony installation, they should be positioned side by side on a railing, in keeping with the installation instructions below. The Soria Avidsen solar station should ideally face south, or in any event south-east or south-west, with no shade, to optimise the performance of the station.
- Page 20 Balcony installation (optional kit, ref. 127126) Warning: Before you start installing the Soria Avidsen solar station on a balcony, make sure you have a minimum width of 3.07 m. Make sure your balcony railing can bear the weight of the solar panels (approximately 32 kg). You may need to apply to your local council if you exceed 1.80 m, or to your homeowner association.
- Page 21 Repeat this op- the right way round, one for the right side and one for the left side of the eration for the other 7 brackets. solar panel bracket. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 22 Installing the hooks on the solar panel bracket Wall mounting kit Repeat this operation for the second hook. optional Install the other 3 pairs of hooks on the other solar panels in the same way. Ref. 127126 Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 23 (optional kit, ref. 127126) Mounting the solar station on the balcony railing Wall mounting kit optional Ref. 127126 Railing Repeat this operation for the other 3 solar panels. Solar panel Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 24 (optional kit, ref. 127126) Securing the solar station Secure your solar station by attaching the brackets with the plastic clamps supplied. Railing Installation of your Soria Avidsen solar station on the balcony is now complete. Solar panel Balcony Wall mounting kit optional Ref.
- Page 25 (standard 230 V 2P+T = 2-pole + earth). If necessary, add a waterproof outdoor extension cord. Inverter Push in and screw. 230 V socket Place the solar panel fitted with the inverter here. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 26 WiFi or 230 V mains. The inverter is locked on Solid blue + the best operating point flashes red every and there is no WiFi 3 seconds connection. Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 27 Once the solar station is connected, follow the the application guide you. instructions below to pair it. 1 - Installing the mobile app Download the Avidsen Home app from the If you do not connect Android Play Store or Apple App Store. your solar station to the Internet, you won’t...
-
Page 28: Installing The Mobile App
Not compatible with 5 GHz WiFi or with WEP encryption. Please check the WiFi settings of your router or contact your Internet service provider if you experience connection difficulties. Installation manual - Solar station - Avidsen - Ref. 127120... - Page 29 Stay within 5 m of your solar station during the Bluetooth pairing phase. To make pairing easier, this is done via Bluetooth. The product will appear directly on screen, press Ajouter (Add). Installation manual - Solar station - Avidsen - Ref. 127120...
- Page 30 Please wait while the connection procedure takes place. This step can take several minutes. Your Soria Avidsen solar station has been successfully paired, you can rename your Soria solar station by pressing the pencil and pressing Terminé (Finish).
- Page 31 By clicking on each function in the chart, you can access additional information such as grid frequency, grid voltage, injected current, voltage and current supplied by the solar panels, etc. Installation manual - Solar station - Avidsen - Ref. 127120...
-
Page 32: Technical Features
MPPT efficiency 99.8% General inverter characteristics Operating temperature -20°C to +50°C Storage temperature -20°C to +50°C Dimensions 165 x 176 x 38 mm Weight 0.82 kg Watertightness IP65 WIFI 2.4 GHz Installation manual - Solar station - Avidsen - Ref. 127120... -
Page 33: Warranty
Monday to Friday, 9am to 12pm, and 2pm to 6pm. 2 - Cleaning and maintenance Avidsen undertakes to keep a stock of spare parts for this The solar panels of the Soria Avidsen station should be product throughout the contractual warranty period. - Page 34 UE Declaration of Conformity Avidsen declares, under its sole responsibility, that the equipment with reference number 127120 complies with the applicable Union harmonisation legislation and its conformity has been assessed pursuant to the applicable standards in force: Inverter: - Specific inverter regulations...
- Page 35 19 avenue Marcel Dassault - ZAC des Deux Lions 37200 Tours - France Installation manual - Solar station - Avidsen - Ref. 127120...
