Summary of Contents for Eizo Extron DMS 2000
- Page 1 Installation Guide Operation with the Large Monitor Manager Important Please read the safety information and all information delivered with the product carefully to familiarize yourself with safe and effective usage.
-
Page 2: Legal Information
Use of EIZO products WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech- nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
General safety instructions .................. 5 Product-specific safety instructions ................ 5 3 Description........................ 6 Scope of delivery ...................... 6 4 Setup and installation ...................... 7 5 Connecting........................ 8 6 Configuration and operation .................. 10 7 Appendix ......................... 11 Contact ........................ 11 Trademarks...................... 11 Extron DMS 2000 Installation Guide, 06/2020... -
Page 4: Introduction
1 Introduction 1.1 Contents of this document This document explains how to install the Extron DMS 2000 20x20 DVI matrix for operation with an Large Monitor Manager. The configuration and operation of the installed system with the Large Monitor Manager and Extron DMS 2000 are described in the Large Monitor Manager instructions for use. -
Page 5: Safety Information
2.1 General safety instructions 2 Safety information 2.1 General safety instructions Correct and safe operation of Extron DMS 2000 DVI matrix assume professional transport, storage, installation, and connection, as well as careful operation and service. CAUTION Observe the general safety instructions in the instructions for use of the Large Monitor Managers and the matrix. -
Page 6: Description
After unpacking, check the scope of delivery for correctness and completeness. Note Keep the packaging material for subsequent use. Product Order No. Description Extron DMS 2000 20x20 6GF60310AA01 Matrix for connecting 20 DVI video DVI matrix inputs and outputs. Components... -
Page 7: Setup And Installation
3.1 Scope of delivery 4 Setup and installation Set-up location The Extron DMS 2000 has to be set up near the Large Monitor Manager so that the matrix can be connected to the Large Monitor Manager using the two-meter RS232/USB adapter cable. -
Page 8: Connecting
Observe the safety information and the connection procedure descriptions in the instruc- tions for use for the Large Monitor Manager and the matrix. Connect Extron DMS 2000 to Large Monitor Manager (LMM) Fig.: Front view matrix Fig.: Rear view matrix... - Page 9 5. Connect the matrix to the power supply. 6. Switch on the matrix using the power switch. ð The matrix is operational and can now be enabled in the LMM system settings. System overview with LMM0802 (schematic) Extron DMS 2000 Installation Guide, 06/2020...
-
Page 10: Configuration And Operation
3.1 Scope of delivery 6 Configuration and operation Configuring To ensure that the Large Monitor Manager detects the connected Extron DMS 2000, mark the setting for activating the matrix in the "Base settings (extended)" sidebar of the Large Monitor Manager user interface:... -
Page 11: Appendix
7.2 Trademarks The EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries. - Page 12 Carl-Benz-Straße 3 76761 Rülzheim Germany Installation Guide, 06/2020 Extron DMS 2000 1085683-001 Copyright © 2020 EIZO GmbH. All rights reserved.
