BUILT-IN RANGE BURNER
OWNER'S MANUAL
FOR USE WITH BUTANE OR PROPANE GAS
CATEGORIA I3+(28-30/37), CATEGORIA I3B/P(30)
CATEGORIA I3B/P(37), CATEGORIA I3P(50)
FOR USE WITH NATURAL GAS
CATEGORIA I2E(20), CATEGORIA I2H(20)
CONTENTS
SAFETY ................................................................................ 2
INSTALLATION .................................................................... 3
LP GAS CYLINDER.............................................................. 10
HOSE & REGULATOR......................................................... 11
NATURAL GAS .................................................................... 12
LEAK TESTING ................................................................... 13
VENTURI TUBES ................................................................. 14
LIGHTING ............................................................................. 15
OPERATION ........................................................................ 16
MAINTENANCE ................................................................... 16
TROUBLESHOOTING ......................................................... 17
WARRANTY ......................................................................... 18
READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING YOUR GAS GRILL.
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
70094-S200EU REV A 07/23
Advertisement
Table of Contents
Related Manuals for Broil King 802762
Summary of Contents for Broil King 802762
-
Page 1: Table Of Contents
BUILT-IN RANGE BURNER OWNER’S MANUAL FOR USE WITH BUTANE OR PROPANE GAS CATEGORIA I3+(28-30/37), CATEGORIA I3B/P(30) CATEGORIA I3B/P(37), CATEGORIA I3P(50) FOR USE WITH NATURAL GAS CATEGORIA I2E(20), CATEGORIA I2H(20) CONTENTS SAFETY ................2 INSTALLATION ..............3 LP GAS CYLINDER.............. 10 HOSE &... -
Page 2: Safety
MODEL SPECIFICATIONS TOTAL HEAT TOTAL HEAT 50 mbar 3P(50) JET SIZE SIDE MODEL INPUT INPUT BURNER 50 mbar 3P(50) (kW) (g/h) 802762 0.95 20 mbar 2E(20) 802763 1.02 I 2E(20) 20 mbar 802763PL 0.96 802766 1.55 20 mbar 2H(20) 20 mbar... -
Page 3: Installation
INSTALLATION POSITIONING YOUR RANGE BURNER Ensure there is adequate ventilation for heat and smoke to dissipate. WHEN DETERMINING THE POSITION OF THE RANGE BURNER, GIVE THOUGHT TO: Exposure to wind. • Proximity to traffic. • Keeping gas lines and electrical connections as short as •... - Page 4 INSTALLATION – CLEARANCES ABOVE COUNTERTOP A) Minimum clearance between the range burner and non- combustible wall above the countertop surface is 6” [150mm] to the left, right and rear. B) Minimum clearance between the range burner and a protected combustible wall above the countertop surface is 12”...
- Page 5 INSTALLATION – CLEARANCES BELOW COUNTERTOP D) Minimum clearance between the range burner and any E) Minimum clearance between the range burner and any non-combustible wall below the countertop surface is protected combustible wall below the countertop surface is 1/4” (6mm) to the left, right and rear. 4”...
- Page 6 INSTALLATION – CLEARANCES OVERHEAD WARNING: Do not install or use the grill under unprotected combustible construction without a fire safe ventilation system. OVERHEAD CONSTRUCTION AND EXHAUST HOOD REQUIREMENTS A minimum 60” [1500mm] clearance is required between the grilling surface and the overhead construction. When installed under combustible overhead construction, the area above the cooking surface of the grill must be covered with an exhaust hood.
- Page 7 INSTALLATION - ENCLOSURES GAS CYLINDER ENCLOSURE VENTS FOR LP GAS CYLINDER ENCLOSURE Liquefied Petroleum (LP) Propane / Butane gas cylinder enclosures WARNING: Vents are required in the LP gas cylinder enclosure must meet the requirements for venting and separation of the gas to provide ventilation in the event of a gas leak.
- Page 8 INSTALLATION - ENCLOSURES ENCLOSURE WITH A DANGER Failure to build a remote LP gas cylinder enclosure for a single LP GAS CYLINDER 15 kg. LP gas cylinder only, following the requirements for • A remote gas cylinder enclosure is required for installations that ventilation and separation of the LP gas cylinder from a heat use a gas cylinder as outlined on the previous page.
- Page 9 INSTALLATION – CYLINDER & GRILL SPECIFICATION FOR CONNECTING TO A 11 kg. LP GAS CYLINDER • A 14” (350 mm) corrugated hose with a 3/8” SAE 45 degree fitting is connected to the manifold of the grill. • Do not use pipe sealant on the 3/8” SAE 45 degree fitting The 3/8”...
-
Page 10: Lp Gas Cylinder
GAS CYLINDER HOSE REGULATOR LP gas cylinders up to and including the 15 kg size may be used. Do not use LP gas cylinders larger than 15 kg. This appliance must be fitted with a regulator complying with the local/national standards and/or norms with a nominal outlet pressure Always treat a LP gas cylinder with care. -
Page 11: Hose & Regulator
CHANGING A GAS CYLINDER NEVER use an unregulated gas supply or a regulator with an operating pressure different then specified on the rating label. WARNING: Changing a cylinder must be carried out in a flame free environment. SCREW-ON CONNECTION SWITCH-ON CONNECTION Some screw on connections have a No tools are required for this type. -
Page 12: Natural Gas
FIXED PIPE PROPANE, BUTANE OR NATURAL GAS LINE GAS LINE LOCATION GAS SUPPLY TESTING Propane, Butane and Natural Gas supply lines should be installed The outdoor gas grill and its individual shutoff valve must be • by a qualified professional. disconnected from the gas supply piping system during any Note: Provide access in the enclosure for gas supply and regulator pressure testing of that system at test pressures in excess of... -
Page 13: Leak Testing
LEAK TESTING S100 Range Burner gas assembly All factory-made connections have been thoroughly tested for gas leaks and the burner has been flame tested. However, shipping and handling may have loosened a gas fitting. AS A SAFETY PRECAUTION: Test all fittings for leaks before using your range burner. •... -
Page 14: Venturi Tubes
VENTURI TUBES INSPECTING & CLEANING VENTURI TUBES Always keep venturi tubes clean. • Blockages in the venturi tubes caused by spiders, insects and nests Turn off gas by closing the main supply valve. Turn control knob can cause a flashback fire. “OFF”. -
Page 15: Lighting
LIGHTING LIGHTING INSTRUCTIONS • The range burner must be assembled and installed as per the assembly and installation instructions. Ensure the range burner is properly connected to the LP or • Natural Gas supply. Ensure there are no gas leaks in the gas supply system. See: •... -
Page 16: Operation
If a problem is found with the regulator, hose, burner, or control valves, do not attempt repair. See your dealer, approved service center, or contact the factory for repairs or replacement parts. To ensure optimum performance, use only original BROIL KING® replacement parts. LEAK TEST When reconnecting a gas cylinder on propane models, be sure to check for leaks. -
Page 17: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION SHUT OFF LP CYLINDER VALVE AT ONCE. SMELL OF GAS DO NOT USE THE APPLIANCE UNTIL LEAK IS SEALED. Leak detected at cylinder, 1. Regulator fitting loose. 1. Tighten fitting and “Leak Test.” (pg 3) regulator or other connection. -
Page 18: Warranty
On receipt of letter or fax (not by phone) BROIL KING may at its ®...
