Symetrix T-7 Glass Quick Start Manual

QUICK START GUIDE:
What Ships in the Box
• T-7 Glass touchscreen
• Universal flush mount bracket
• Two zinc-plated steel M3.5 x 25mm
Phillips pan head screws
• Four zinc-plated steel 6-32 x 1.25"
Phillips pan head screws
• Two painted black steel 2-56 x 5/16" Torx
T8 screws
• Torx T8 screwdriver
• This Quick Start Guide
What You Need to Provide
• Windows PC with the following
minimum specifications:
• 1 GHz or higher processor
• Windows 10 or higher
• 1 GB free storage space
• 1280x1024 graphics capability
• 16-bit or higher colors
• Internet connection
• 8 GB of RAM
• Network (Ethernet) interface
• CAT5e/CAT6 cable
Getting Help
®
Composer , the Windows software that
configures the T-7 Glass touchscreen
hardware, includes a help file which acts as a
complete User's Guide for both hardware and
software. If you have questions beyond the
scope of this Quick Start Guide, contact our
Technical Support Group in the
following ways:
Tel: +1.425.778.7728 ext. 5
Web: https://www.symetrix.co
Email: support@symetrix.co
Forum: https://www.symetrix.co/Forum
We, Symetrix Incorporated,
6408 216th St. SW, Mountlake Terrace, Washington, USA,
declare under our sole responsibility that the product:
to which this declaration relates, is in conformity
with the following standards:
FCC Part 15 (EMC-USA),
RoHS (health/environmental)
www.Symetrix.co | +1.425.778.7728
T-7 Glass
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
This apparatus shall not be exposed
to dripping or splashing and no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install only in accordance with the
manufacturer's instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Ensure proper ESD control and grounding
when handling exposed I/O terminals.
10. Protect the cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
cord is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally, or
has been dropped.
Declaration of Conformity
T-7 Glass
WARNING:
SEE OWNERS MANUAL. VOIR CAHIER D'INSTRUCTIONS.
No user serviceable parts inside. Refer servicing to qualified service personnel.
Il ne se trouve a l'interieur aucune piece pourvant entre reparée l'usager.
• The lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user of the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute
a risk of electric shock to persons. The
exclamation point within an equilateral
triangle is intended to alert the user of
the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product
(i.e. this Quick Start Guide).
• User Serviceable Parts: There are
no user serviceable parts inside this
Symetrix product. In case of failure,
customers inside the U.S. should refer
all servicing to the Symetrix factory.
Customers outside the U.S. should refer
all servicing to an authorized Symetrix
distributor. Distributor contact information
is available online at:
https://www.symetrix.co.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void
the user's authority to operate the equipment under FCC rules.
Cet appariel numerique de la classe B respecte toutes les Exigences
du Reglement sur le materiel brouilleur du Canada.
Technical construction files maintained at:
Symetrix, Inc. 6408 216th St. SW,
Mountlake Terrace, WA, 98043 USA
Date of issue: September 21, 2023.
Place of issue: Mountlake Terrace, Washington, USA
Authorized signature:
Mark Graham, CEO
Symetrix Incorporated.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE
AVIS:
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
S'adresser a un reparateur compétent.
Page 1 of 4
