Summary of Contents for MK BATTERY Deka duration DD5300
- Page 1 DD5300 QUICK INSTALLATION GUIDE 15 MODULES OR LESS This Quick Guide is not meant to replace the full I&O Manual...
-
Page 2: Product Overview
Product Overview The Deka Duration DD5300 is a dual voltage, Stackable Battery Module that can be used in Low Voltage configuration or High Voltage configuration. Section 1 is for Low Voltage Application Section 2 is for High Voltage Application This Battery Module is designed to be used indoors. - Page 3 Battery Module Included Accessories The battery is dual voltage – it can be installed in either a High Voltage configuration or a Low Voltage configuration, but never both at the same time. D D 5 3 0 0...
- Page 4 Terminals and Connections Low Voltage Only High Voltage Only Screw Terminal Fast Connectors Low Voltage High Voltage Parallel Connection Serial Connection D D 5 3 0 0...
-
Page 5: General Preparation
General Preparation Before Installation: Ensure that all the modules are turned OFF. Battery installation location should be at least 20m away from sources of heat, sparks or other sources of extreme temperature. Battery connecting cables shall be as short as possible to prevent excessive voltage drops. - Page 6 Stackable Installation The DD5300 Battery Module has two terminals for connecting the power supply. The installer must pay the utmost attention to the respective functions. D D 5 3 0 0...
- Page 7 Seismic Racking Installation Place the Battery Module on the base and secure it using the corner brackets. Use the hardware supplied with the corner brackets on the module. Use the two M6 hex cap screws with the M6 flat and lock washers to fasten the front of the module to the base as shown below.
- Page 8 Seismic Racking Installation Before stacking the next module, secure the L-bracket to the bottom of the battery using two M6 flat head screws. Use the two outside cutouts on the bottom of the module for the connection. Remove the two screws that are circled below for the L-bracket connections. Place the module on top and secure the L-bracket using the two M4 head screws in the position illustrated below.
- Page 9 Seismic Racking Installation Repeat the 2 previous steps for every module in the stack (MAX=8). Secure the front cover plate using the two (2) 10-24 screws. D D 5 3 0 0...
- Page 10 Low Voltage Parallel Set Up DD5300 can be connected in parallel up to 15 modules (in a single cluster), this process requires a full knowledge of the product. 9.5 Nm(7 ft lb) Battery Terminal Block Power Cable Tightness CHECK TORQUE EVERY THREE MONTHS Dip switch configuration up to 15 modules in parallel.
- Page 11 Low Voltage Set Up Steps After setting the DIP Switch, the Battery Module must be restarted for the DIP switch changes to take effect. Set up the DIP switches for all the modules in the cluster. Connect of the earth terminal between the modules and the general earth rod. Connect the RS485 B Port of the Master battery with the RS485A Port of the SUB-1 battery using the RJ45 cable supplied.
- Page 12 Low Voltage Set Up Steps Screws, cables and bus bar power connections on the battery terminal block must be installed with due diligence, and the tightening of the connection terminal must be to 9.5 nm (7 ft lb). Each terminal should be inspected, and its torque checked every three months.
- Page 13 Low Voltage Wake-Up Steps Turn the power switch on for all the batteries in the cluster. Press the RUN button on the master battery for 2-3 seconds. Wait for all the sub modules to wake up and all the run buttons are solid green The process may take up to 30-45 seconds.
- Page 14 Low Voltage Cluster Shutdown Press and hold the Master Run Button for 5-seconds. The GREEN RUN light should go off immediately. The GREEN RUN lights on the sub batteries will not be extinguished immediately. The RED FAULT lights on the sub batteries’ FRONT LED bars will start flashing after ten seconds and the GREEN RUN lights will remain on.
- Page 15 High Voltage Configuration It is mandatory to use the DD21002 HV box for this configuration. High Voltage Accessories Included With The Battery H I G H V o l t a g e...
- Page 16 HV Box Included Accessories H I G H V o l t a g e...
- Page 17 High Voltage Set Up Preparations It is extremely important that every module within the system has the same voltage. The installation of an HV system requires particular attention to preparation of the individual modules that make up a cluster. A single module with a lower voltage than few MVOLTS compared to the others could result in a performance reduction of the entire system.
- Page 18 High Voltage Set Up Steps Turn the Solar Inverter OFF. Verify the HV Box main breaker is in the OFF position (located on the side). Arrange the cluster physically. Set the DIP Switches per illustration below for the modules and the HV BOX in a cluster. Connect the communication cable from HV BOX CAN1-B PORT to the first Battery Module CAN-A PORT.
- Page 19 High Voltage Set Up Steps Communication, Dip Switches and Ground Cables Connections H I G H V o l t a g e...
- Page 20 High Voltage Set Up Steps Power Cable Connections H I G H V o l t a g e...
- Page 21 High Voltage Wake-up Steps Inspect all the power connections of each cluster. Turn on the power switch (only) on all Battery Modules in the cluster. Switch on the breaker of the first HV Box (ID00) and wait for the total start-up of the first cluster.
- Page 22 DD5300 Firmware Update Visit www.dd5300-bms.com and download the UL PC software and the appropriate firmware. Plug RJ45 end of DD21004 into the operator port on the battery or the HV BOX and the USB into the computer. Select Low Voltage for individual battery and Low Voltage cluster upgrade or select High Voltage for HV BOX and High Voltage cluster upgrade.
- Page 23 DD5300 Firmware Update Once the system is connected click on the upgrade tab. Low Voltage: Click on Search New Firmware to either upgrade all or individual upgrade. High Voltage: Click on Search New Firmware to either upgrade the HV BOX or the full cluster.
- Page 24 DD5300 Firmware Update Click on the appropriate folder that contains the “.bin” firmware. HV BOX, LV Hub and Battery Firmware can be found at www.dd5300-bms.com Once the file populates in the PC software, click on Upgrade or Load Firmware. Dont exit the software or turn off the computer until upgrade is complete. D D 5 3 0 0...
- Page 25 DD5300 Firmware Update D D 5 3 0 0...
- Page 26 Warnings The battery could explode and/or be severely damaged if dropped or crushed. This Battery Module is designed to be used indoors. The STANDARD IP20 degree of protection does not allow installation in outdoor environments even if sheltered from the weather. The Battery Modules must be stored indoors in a clean, dry, cool location in a limited access area.
