1. Introduction
1.1. General
Read this manual carefully before using for the first
time !
Keep for future reference.
This manual contains important information for the
correct use of the tool holder.
The manual is downloadable from :
https://www.pcm.ch/en/download
1.2. Tool Holder identification
All PCM Precision Tooling SA tools have a product
name and serial number engraved on one side.
Additional information may be added.
2. Security
All persons using the tool holder must be familiar with
the information and recommendations contained in
this manual. The person responsible for the product
must ensure that all users understand and comply
with these instructions.
2.1. General
When using and handling the toolholder, always
comply with the laws and safety regulations of your
country and/or the European Union, as well as the
safety and operating instructions of your machine tool
manufacturer.
Zone industrielle C
Rte du Grammont 101
CH-1844 Villeneuve
Mode d'emploi
Operating instructions
Betriebsanleitung
Istruzioni per l'uso
General information
2.2. Instructions
PCM Precision Tooling SA accepts no liability for
incorrect use of the tool holder and/or machine tool.
Incorrect
Product name
Serial number
Ratio
Incorrect use of the product can result in serious
injury and considerable material damage. It is the
responsibility of the person responsible for the
product to inform the user of potential hazards
and how to avoid them.
2.3. Non-PCM Accessoiries
PCM Precision Tooling SA is not responsible for the
safety and function of accessories supplied by third
parties.
PCM Precision Tooling SA
SWISS MADE
Copyright © PCM Precision Tooling SA.
Garant:
BT
Validation :
25.01.2024
use are:
-
Use of the product by unqualified and/or
untrained persons.
-
Use of the product without instruction.
-
Non-compliance with tightening torques.
-
Use outside limits.
-
Open the product using tools such as a
hexagonal wrench, unless specifically
indicated for certain functions.
-
Sealed screws (white dot) must not be
screwed in or out.
-
Modification of the product.
-
Use of a product with visible damage or
defects.
-
Collision due to programming error.
-
Use with accessories from other
manufacturers without prior agreement from
PCM Precision Tooling SA.
-
Exposure of the product to corrosive
environments.
-
Use of compressed air in the direction of the
product..
Warning
Tél ++41 21 967 33 66
Fax ++41 21 960 38 95
email:
Document :
1.General
information.docx
Page : 1 de 4
http://www.pcm.ch
sales@pcm.ch
