Page 1
65SX QUICK SETUP GUIDE Before using the TV, please read this guide thoroughly and retain it for future reference. For more detailed instructions, please see the User Manual. English ES-A201401-1...
Page 3
Important Safety Precautions This symbol alerts user about the ATTENTION presence of a dangerous voltage not isolated inside the product which can RISK OF SHOCK ELECTRIC be sufficiently powerful to constitute a risk of electrocution. Do not open the back cover. This symbol alerts user about the In no case the user is allowed to operate presence of important operating...
Page 4
Important Safety Precautions Warning Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: Using stands recommended by the manufacturer of the television set. Only using furniture that can safely support the television set.
Page 5
Important Safety Precautions Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference.
Page 6
Important Safety Precautions 9. Power-Cord Protection Power- supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plug, wall outlets, and the point where they exit from the TV. MAIN plug is used as the disconnect device, the disconnect device shall remain readily operable.
Page 7
Important Safety Precautions (d) If the TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.
Contents Figures and illustrations in this manual are provided for reference only and may differ from actual product appearance. Parts of the software function changes with the system upgrade. Contents Accessories List......................1 Installing the Stand ......................3 Installing the Wall Mount Bracket .................. 5 TV Front.........................
Accessories List Subwoofer ×1 Front Stand × 1 Subwoofer Connector × 1 (with power cord) Screw(M4×8) × 8 / Screw(M4×20) × 4 / Screw(M5×12) × 4 Cover for the wall mount bracket The arrow on the cover marked " " points up during the installation process. Left Cover ×...
Installing the Stand or Wall Mount Bracket CAUTION Be sure to disconnect the A/C power cord before installing a stand or wall mount brackets. The display on your TV is fragile. Make sure the TV screen is not scratched or damaged by hard objects or from pressure.
Page 11
Installing the Stand or Wall Mount Bracket 3. Carefully place your TV facedown on a soft, flat surface to prevent damage to the TV or scratching to the screen. Take out the front stand, secure it to the bottom of the TV with 8 screws in the accessory bag tightly, and then install the left and right covers of the front stand marked "...
Installing the Stand or Wall Mount Bracket 5. Connect the power cord plug of the subwoofer to the power socket of the TV, and then install the cover of the rear stand marked " ". (see Figure 5) Figure 5 Rear Cover 2 Power socket of the TV Power cord plug of the...
Page 13
Installing the Stand or Wall Mount Bracket CAUTION When mounting the TV on a wall, follow instructions provided with the wall mount bracket. If it is not correctly mounted, the TV may fall and cause property damage or personal injury. Place spacers between the TV and bracket.
TV Front TV Front TV Bottom Panel TV Back View Remote sensor Power indicator Item Description Receive remote signals from the remote control. Remote sensor Do not put anything near the sensor, as its function may be affected. Power indicator The light is off when turned on.
TV Rear TV Rear Nameplate Power Input HDMI 4 (4K@60Hz) VIDEO AV IN Note: When terminal connection is finished, take out the Cover from accessory bag and install it to cover terminals. Cover NOTE Check the jacks for position and type before making any connections. Loose connections can result in image or color problems.
Making Connections Connect an outdoor VHF/UHF antenna or cable. Outdoor Antenna TV JACK Cable ANT OUT (not included) Antenna Cable (75Ω) VHF/UHF Antenna HDMI / AV Connect a HDMI / AV cable from an external AV equipment. No sound connection is needed for HDMI to HDMI connection.
Page 17
Making Connections HEADPHONE Connect Headphone for audio out of the TV. TV JACK ATTENTION Excessive sound pressure from earphones and headphones can HEADPHONE cause hearing loss. Headphone (not included) NOTE Please make sure that the headphone you plug in is without microphone function, or it may not be supported.
Page 18
Making Connections Connect the USB1.1 and USB2.0 devices such as hard drives, USB sticks and digital cameras for browsing photos, listening music and watching movies. TV JACK USB 1 USB 2 DC 5V 0.5A(MAX) DC 5V 0.5A(MAX) NOTE When connecting a hard disk or a USB hub, always connect the mains adapter of the connected device to the power supply.
Page 19
Making Connections Wireless setup Connect your TV to your wireless network, you need a wireless router or modem. See the illustration below. · The TV’s built-in Wireless LAN Adapter supports the IEEE 802.11 b/g/n communication protocols. Wireless router with DHCP Wireless LAN Adapter LAN Cable built-in TV set...
Remote Control Power Standby button: Select input sources Power on/ Standby Select a channel or input numbers Display the Electronic Program Guide (DTV Display the current mode) program information Special function buttons Playpad keys Quick setup Confirm button / Display Navigation buttons the on-screen keyboard (Up/Down/Left/Right)
Page 21
Remote Control Microphone Display the present / Power indicator program information Power Standby button: Select input sources Power on / Standby Fast access to all Custom button to launch applications input or apps quickly Select a channel or input numbers Display the Electronic Display the channel Program Guide (DTV mode)
Page 22
Remote Control Source selecting button Power Standby button: INPUT Power on/ Standby Select a channel or input numbers Display subtitles in the Start Timeshift T.shift Subtitle Live TV Special function buttons EPG: Display the Quick Setup Electronic Program Guide (DTV mode) Confirm button / Display the on-screen keyboard Navigation buttons...
Page 23
Remote Control Installing Batteries in the Remote Control NOTE: Check information according to the actual remote control in the accessory bag. 1. Slide the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in the battery compartment.
Page 24
Remote Control Pairing the Remote Control (only for bluetooth remote control) 1. Press the [ ] button, and then select Settings > System > Bluetooth > Remote Pairing. 2. Press and hold the [ ] button until your TV and remote control are paired successfully.
Turning the TV on for the First Time Turning the TV on for the First Time 1. Connect the mains cable to the mains socket after you have completed all the connections. 2. The first time you turn the TV on, it will go straight to the Installation Guide. 3.
Specifications Features, appearance and specifications are subject to change without notice. If you encountered difficulty when setting up your TV, we suggest you refer to the troubleshooting tips in the User Manual. Item 65" Without Stand 1450 × 869 × 53 (W ×...
Other Information What is Freeview Plus? Freeview Plus is a new television service delivered via broadband providing a state of the art Electronic Program Guide (EPG) and seamless access to catch-up TV across the free-to-air networks with the simple press of a button. How does it work? First ensure the TV is connected to internet and an antenna system.
Accessories List User Manual User Manual × 1 Subwoofer × 1 Power Cord × 1 Adapter × 1 Product Illustration Button / Power Indicator Power Socket Connecting Instruction Power Connection (When the TV is on the wall) Put the subwoofer on the ground, and make sure the distance between the subwoofer and the TV is in the range of wireless connection.
Page 29
Pairing Instruction When the TV is on the wall, make sure the subwoofer is connected to the power supply before pairing. 1. Enter the TV Settings menu. 2. Select Sound > Sound Mode Setting > Subwoofer Pairing. 3. Press the button on the top of the subwoofer for more than 3 seconds. When the white light of the subwoofer flashes from slow to fast, it indicats that the subwoofer is in the pairing state.
