- Page 1 SP-1101W V2 / SP-2101W V2 Quick Installation Guide 09-2017 / v1.0...
-
Page 2: Table Of Contents
CONTENTS Introduction ..................1 II Smart Plug Setup ................... 2 II-1 Package Contents ..................2 II-2 Hardware Installation ..................3 III EdiSmart App Setup ................5 III-1 Apple iOS ....................... 6 III-1-1 EdiSmart Account Sign-Up ..............6 III-1-2 Connecting the Smart Plug ..............7 III-2 Android OS .................... - Page 3 IMPORTANT SAFETY INFORMATION In order to ensure the safe operation of the device and its users, please read and act in accordance with the following safety instructions: WARNING: There is risk of fire or electric shock if the device is used inappropriately. If you experience problems with the device, please contact your dealer of purchase for help.
-
Page 4: I Introduction
Introduction SP-2101 and SP-1101 are Wi-Fi smart plugs that are mostly managed by a powerful application tool from Edimax Technology. Once the smart plug is connected to the internet, the accompanying app can control and manage its functions such as turning it on / off, scheduling and budget control. -
Page 5: Smart Plug Setup
Smart Plug Setup II-1 Package Contents SP-1101W V2 Quick Installation Guide CD with User Manual Or SP-2101W V2 Front Panel The smart plug graphical example used throughout the guide is model SP-2101W. The difference is demonstrated in the picture below (power meter-looking icon above Switch Status Button) 1. -
Page 6: Hardware Installation
II-2 Hardware Installation Follow the instructions below to ensure your smart plug is properly connected and ready for setup. Please only set up one smart plug at a time. Plug the smart plug into a power socket. Press and hold the reset button (for ~10 seconds) on the plug until the network LED starts flashing quickly in and let go. - Page 7 Wait a few moments for the smart plug to start up. The smart plug is ready for setup when the network LED is flashing slowly in indicate installation mode. When smart plug is in installation mode, please continue to III EdiSmart App Setup to set up your smart plug using the free EdiSmart app.
-
Page 8: Edismart App Setup
EdiSmart App Setup To allow remote access to your smart plug, please use the EdiSmart app. After setup, you can use the EdiSmart app to switch your smart plug on/off remotely from any compatible mobile device with an Internet connection, as well as set up automated schedules and email notifications. -
Page 9: Iii-1 Apple Ios
III-1 Apple iOS III-1-1 EdiSmart Account Sign-Up Search and download “EdiSmart” in Apple App Store. Open the EdiSmart app. Select “Sign up” (outlined in red) to sign up for an EdiSmart account Enter an email, password, and confirm the password in the blank fields shown. Tap “Login”... -
Page 10: Iii-1-2 Connecting The Smart Plug
III-1-2 Connecting the Smart Plug For EdiSmart app to control the Smart Plug, it must be connected to a Wi-Fi network with internet connectivity. To do so, follow the steps below: If you have not reset your smart plug, please do that now! Press and hold the Reset Button (for ~10 seconds) until the network LED starts flashing quickly in and let go. - Page 11 Firmware Upgrade After selecting the icon, EdiSmart app will identify the current firmware version of your smart plug and prompt you to upgrade it to the newest firmware version if available. Tap “OK” to upgrade your firmware. After firmware upgrade, please press and hold the Reset Button (for ~10 seconds) on the Smart Plug until the network LED starts flashing quickly in and go back to Step 1 to continue setup.
- Page 12 Select a Wi-Fi network (e.g. your home’s Wi-Fi router) from the Wi-Fi list. Enter the network’s password and press “OK” to continue. The app will connect the smart plug to the Wi-Fi router, please wait patiently. After the smart plug is connected to your Wi-Fi, the app will ask you to enter a name for the device.
- Page 13 Congratulations! The smart plug is ready to be used. The smart plug’s network LED should be on in green color to indicate a successful network and cloud connection. You can now control your smart plug from the EdiSmart home screen. Tap the switch to switch your smart plug (and any electrical device you plug into it) on or off.
-
Page 14: Iii-2 Android Os
III-2 Android OS III-2-1 EdiSmart Account Sign-Up Search and download “EdiSmart” in Google Play. Open the EdiSmart app. Select “Sign up” (outlined in red) to sign up for an EdiSmart account Enter an email, password, and confirm the password in the blank fields shown. Tap “Login”... -
Page 15: Iii-2-2 Connecting The Smart Plug
III-2-2 Connecting the Smart Plug For EdiSmart app to control the Smart Plug, it must be connected to a Wi-Fi network with internet connectivity. To do so, follow the steps below: If you have not reset your smart plug, please do that now! Press and hold the Reset Button (for ~10 seconds) until the network LED starts flashing quickly in and let go. - Page 16 A message will be shown indicating that it is connecting to the smart plug. Firmware Upgrade When the EdiSmart app is connecting to the smart plug, the app will identify the current firmware version of your smart plug and prompt you to upgrade it to the newest firmware version if available.
- Page 17 A Wi-Fi list will be displayed after the app connects to the smart plug. Select a Wi-Fi network (e.g. your home’s Wi-Fi router) from the Wi-Fi list. Enter the network’s password and press the icon to continue. The app will connect the smart plug to the Wi-Fi router, please wait patiently.
- Page 18 Congratulations! The smart plug is ready to be used. The smart plug’s network LED should be on in green color to indicate a successful network and cloud connection. You can now control your smart plug from the EdiSmart home screen. Tap the switch to switch your smart plug (and any electrical device you plug into it) on or off.
-
Page 19: Resetting The Smart Plug
If you experience problems with your smart plug, or you want to connect the smart plug to a different Edimax app account, you can reset the plug back to its factory default settings. This resets all settings back to the default settings. - Page 20 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 21 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU, 2014/35/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/53/EU, 2014/35/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/53/EU, 2014/35/EU.
- Page 22 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: Wi-Fi Smart Plug Model No.: SP-1101W V2/SP-2101W V2 The following European standards for essential requirements have been followed:...
- Page 23 Notice According to GNU General Public License Version 2 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code.
- Page 24 TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The ‘“Program’“, below, refers to any such program or work, and a ‘“work based on the Program’“...
- Page 25 the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or, Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in object code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifications to it.
- Page 26 or among countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this License. 9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time.
