Gossen MetraWatt AKKUPACK Z502H Supplement

SUPPLEMENT
3-447-108-27
3/1.24
Z502H / Z502O / Z505U – AKKUPACK
1 SAFETY INSTRUCTIONS
Read and follow these instructions carefully and com-
pletely in order to ensure safe and proper use.
The instructions must be made available to all persons
who use the product.
Keep for future reference.
 Observe and comply with all safety regulations which are appli-
cable for your work environment.
 Use the battery set in undamaged condition only.
Inspect the battery set before use. Pay particular attention to
damage.
 Do not use the battery set after long periods of storage under
unfavorable conditions (e.g. humidity, dust or extreme tempera-
ture).
The battery set must not be exposed to direct sunlight.

Only use the battery set in compliance with the specified tech-

nical data.
 Batteries may only be charged in undamaged condition.
 Inspect the batteries before use. Pay particular attention to
leaky and damaged batteries.
 Unauthorized modification or opening of the accessory is pro-
hibited.
2 APPLICATION
Please read this important information!
2.1 INTENDED USE /
USE FOR INTENDED PURPOSE
Z502H / Z502O / Z505U, hereinafter referred to as "product", are
battery packs for supplying the following test instruments with elec-
trical power:
 Z502H:
 all test instruments of the PROFITEST MASTER series
 all test instruments the PROFITEST MF series
 PROFITEST INTRO
METRISO XTRA

Z502O: all test instruments the PROFITEST MF series

Z505U:

all test instruments of the PROFITEST MASTER series

 all test instruments the PROFITEST MF series
 PROFITEST INTRO
 METRISO XTRA
Safety of the user, as well as that of the product, is only assured
when it's used for its intended purpose.
2.2 USE FOR OTHER THAN INTENDED PURPOSE
Use of the product for any purposes other than those described in
this supplement, or in the product documentation for the associat-
ed test/measuring instrument, is contrary to use for intended pur-
pose. Use for Other than Intended Purpose may lead to
unpredictable damage!
2.3 LIABILITY AND GUARANTEE
Liability and guarantee granted by Gossen Metrawatt GmbH com-
plies with the applicable contractual and mandatory legal regula-
tions.
3 PRODUCT
3.1 SCOPE OF DELIVERY
1 Akkupack (Z502H / Z502O / Z505U)
1 Supplement (this document)
3.2 SYMBOLS ON THE PRODUCT
Symbol Meaning
European conformity marking
The product may not be disposed of with household
trash. You are required to comply with all applicable
local regulations 2.
The battery set must be fed into the recycling loop for
rechargeable nickel metal hydrid batteries.
NiMH
3.3 TECHNICAL DATA
Z502H: 2000 mAh
Charging
Z502O: 2500 mAh
capacity
Z505U: 2620 mAh
Nominal
9.6 V
voltage
Overall
0.6 Ω (1000 Hz)
Resistor
Operating temperatures: see test instrument
Ambient Storage temperatures: –20 °C ... +30 °C
Conditions Storage duration: max. 1 year
Relative atmospheric humidity: 65 % ± 20 %
Terminals: for 9-V block battery clips
Mechanical
W × H × D: approx. 63 mm × 30 mm × 61 mm
Design
Weight: approx. 250 g
4 STORAGE AND TRANSPORT
ATTENTION
Improper Storage
Damage to the product.
 Store the product in a protected location and only within the limits
of the permissible ambient conditions ( "Technical Data" 1).
ATTENTION
Improper Transport
Damage to the product.
Transport the product only within the limits of the permissible

ambient conditions ( "Technical Data" 1).
 Ensure adequate protection when transporting the product.
1 | 2
