RETRA FLASH PRO MAX
USER MANUAL
Last Update: 19-JAN-2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLASH PRO MAX and is the answer not in the manual?

Questions and answers

Summary of Contents for Retra FLASH PRO MAX

  • Page 1 RETRA FLASH PRO MAX USER MANUAL Last Update: 19-JAN-2024...

  • Page 2: Table Of Contents

    CONTENTS TECHNICAL SPECIFICATIONS........3 POWER SOURCE............4 BOOSTER..............5 Mode: OFF..............6 Mode: BATT/TEST............7 Mode: SOS/TURN............8 CHARGING – “CHG” SYMBOL........9 PILOT / TEST............... 10 SOUND................. 11 Mode: M – Manual............12 Mode: TTL (automatic illumination)......13 OPTICAL SIGNAL QUALITY CHECK......14 Mode: U (Custom User Mode)........15 Mode: HSS - High Speed Sync mode......

  • Page 3: Technical Specifications

    Number of flashes at full (100%) power with Booster 520+ Standby time with Booster +24 hours Optical Connector Inon threaded connector / Sea&Sea plug connector Leakage detection Bluetooth Connectivity Bayonet Mount Classic A1 For the complete list of technical specifications please visit: https://www.retra- uwt.com/...

  • Page 4: Power Source

    POWER SOURCE The Retra Flash Pro Max uses 4x AA batteries (8x AA batteries with Booster) as the standard power source. The Retra Flash can work with single-use Alkaline batteries, however the performance will be greatly reduced. Take care of our planet and get the maximum performance from the Retra Flash by using high quality rechargeable NiMh batteries.

  • Page 5: Booster

    IMPORTANT: Use only NiMh or Alkaline batteries and NEVER use any other battery chemistry (NiZn, LiFe, Li-ion etc.) because the high current required for powering the Retra Flash can cause damage to the battery or result in fire or injury in case of catastrophic failure.

  • Page 6: Mode: Off

    In OFF mode the Retra Flash Pro Max has practically no battery consumption. Despite this, we strongly advise taking out the batteries, if the Retra Flash will not be used for several weeks or during travel, to avoid accidentally turning on the Retra Flash and consuming the battery.

  • Page 7: Mode: Batt/Test

    TEST MODE: By pressing the PILOT-TEST button in BATT-TEST mode the Retra Flash will emit a flash at the selected power level. This feature is used to test if your Retra Flash is firing correctly or for creative lighting techniques with long exposures.

  • Page 8: Mode: Sos/Turn

    The pilot light emits a morse code signal for help (SOS). This mode overrides all errors. When in the SOS/TURN mode, you can flip the screen on the Retra Flash Pro Max 180°. To turn the screen, simply turn the mode dial on the Retra Flash Pro Max to °.

  • Page 9: Charging - "Chg" Symbol

    CHARGING – “CHG” SYMBOL The Retra Flash will indicate that the capacitors are charging with a “CHG” symbol. Once the Retra Flash is ready to fire it will signal by producing a short sound and indicate the selected mode and power level.

  • Page 10: Pilot / Test

    OFF, 50%, 100%. You can modify and customize the pilot light power levels in the ADVANCED FEATURES section in the Retra UWT Application (*). *Pilot adjust is currently unavailable and will become available after the new Retra UWT application will launch.

  • Page 11: Sound

    You can toggle the sound of your Retra Flash ON or OFF inside the Retra UWT Smartphone App (currently unavailable in Retra UWT app). You can also mute the sound on the Retra Flash by turning the mode dial on the Retra Flash to M. Then press and hold the PILOT-TEST button for approximately 3 seconds or until the Retra Flash emits a sound.

  • Page 12: Mode: M - Manual

    Mode: M (Manual) In M mode, the Retra Flash is triggered via a built-in optical sensor. The power output of the flash can be adjusted manually, with the power dial. The power dial features 13 power levels with steps of approximately 0,5 F-Stop per step.

  • Page 13: Mode: Ttl (Automatic Illumination)

    Try setting the power dial to plus (+) positions OR decrease the distance from Retra Flash to subject. When using rear curtain sync in TTL mode, the Retra Flash will not fire in a range of shutter speeds from approximately 1⁄6 to 1⁄2, but will work at faster and slower shutter speeds.

  • Page 14: Optical Signal Quality Check

    LED or flash trigger on the camera. The high sensitivity of the optical sensor on the Retra Flash may produce false triggers on land with the presence of static electricity.

  • Page 15: Mode: U (Custom User Mode)

    Mode: U (Custom User Mode) The Retra Flash Pro Max enables you to customize the (U) user mode via the Retra UWT Smartphone App and tailor your Retra Flash experience to suit your specific needs. To set advanced features, the Retra Flash Pro Max must be connected to the Retra UWT App via smartphone or tablet.
  • Page 16 The Manual low power (Mlp) mode operates the same as Manual (M) mode. LED Adjust - Pilot light output adjust The Retra Flash Pro Max allows you to adjust the intensity of the pilot light at each power level. Short pressing the PILOT-TEST button once turns on the pilot light at first power level.

  • Page 17: Mode: Hss - High Speed Sync Mode

    Mode: HSS - High Speed Sync mode The Retra Flash Pro Max is capable of emitting a long flash pulse required for HSS photography. The successful operation of HSS synchronization depends on the capability of underwater camera housing electronics OR the onboard camera flash to emit a HSS synchronized light pulse.

  • Page 18: Errors (Leakage, Overheat, Etc.)

    When the message appears, the Retra Flash will operate normally and will not indicate any errors. When the Retra Flash is turned off it will reset this mode and all errors will start indicating again. Use this function at your own risk. Using the error override function repeatedly may damage the product and void your warranty.
  • Page 19 30-60 seconds to allow cooling. If the Retra Flash overheats, an overheat symbol will appear on the screen. Once the temperature is reduced the lights will stop blinking and the flash may be used...

  • Page 20: Maintenance

    Push the buttons and turn the power and mode dials on the back panel to make sure all salt water is removed from the Retra Flash. DO NOT use the Retra Flash if water or moisture is present within the front dome. Remove the batteries and contact us for assistance at: help@retra-uwt.com Always keep your Retra Flash turned on when submerged in water.
  • Page 21 Flash accessory or the bayonet mount may be damaged. Please contact us for assistance help@retra-uwt.com Front Dome - The front dome of the Retra Flash is made out of plexiglass and can be polished with any kind of plexiglass certified polish solution.

  • Page 22: Warranty And Disclaimer

    Keeping your Retra Flash up to date with the latest firmware via the Retra UWT App automatically extends your warranty by 1 additional year to a total of 2 years of warranty.
