Summary of Contents for Pyle PKBRD6139BT
-
Page 2: Please Read Carefully Before Proceeding
PLEASE READ CAREFULLY BEFORE PROCEEDING Please keep this manual in a safe and handy place for future reference NOTICE • Dedicated power adapter shall be used, and in case of adaptor damage, replace it immediately • The keyboard can only be disassembled by professionals, and no change can be made to the internal structure. -
Page 3: Top Control Panel
I. Control Panel and External Ports TOP CONTROL PANEL REAR PANEL PORT www.PyleUSA.com... - Page 4 II. Preparations before Playing POWER ADAPTOR A dedicated power adapter shall be used. Connect the output end of the adaptor to the power port on the rear panel of the keyboard, and then the other end to the power socket. (Note: the input voltage of the adaptor shall be compatible with the power supply voltage) AUDIO OUTPUT/EXTERNAL HEADPHONE Audio Output: Firstly, turn o the keyboard and the external audio devices, secondly,...
- Page 5 III. Basic Playing Method When [Power ON/OFF] is pressed, LCD screen will turn ON and shows the current tone, tempo and other status. Then you may operate the Keyboard as required. MASTER VOLUME ADJUSTMENT Press [Master Vol +/-] to turn up or turn down the master volume. “VOLUME”...
-
Page 6: Tempo Adjustment
IV. Auto Style STYLES SELECTION This Keyboard provides 255 Styles, from "000" to "254", for your selection, and the Style default is "000". Press [Styles] to enable the Style selection function. "STYLE" and current Style number will show on the display. Then you can press the number buttons or the "+"... - Page 7 V. Auto Bass Chord SINGLE CHORD Under the state that the Style is enabled, press [Single Chord], and “SIN” will show on the display, and then you can play a single chord on the keys in the chord zone of the keyboard. FINGERED CHORD Under the state that the Style is enabled, press the [Fingered Chord] button.
- Page 8 Single Chord Fingering VI. Status Memory Function With the status memory function, you can save the Sound, Style, Tempo and other parameters to be changed during playing for fast shifting. This keyboard is equipped with 4 status memories, which can be exibly called at any time during playing. www.PyleUSA.com...
- Page 9 STORAGE OF STATUS MEMORY Set the Sound, Style, Tempo and Chord as required, and then press the [Status Memory] botton and one of [Memory 1] to [Memory 4] to save the current status. CALLING OF STATUS MEMORY Press any one of [Memory 1] to [Memory 4] to call the setting parameters saved under this memory to replace the current status.
- Page 10 VIII. Recording and Style Programming RECORDING Press [REC] to enable the recording function, “REC” will show on the display. Under this mode all playing notes will be recorded. When the storage is full, “REC” will show on the display, and recording will stop automatically.
- Page 11 IX. Three-step Intelligent Training TRAINING I: ONE KEY Press [One Key] to enable the One Key training function, "LEARN", "SONG" and the song number will show on the display, and then press "+” / “-" button to select the song to be learned. Single Key training aims at duration learning, and there is no requirement for pitch or correctness.
-
Page 12: Sounds Table
Appendix I. SOUNDS TABLE www.PyleUSA.com... - Page 13 II. STYLE TABLE www.PyleUSA.com...
- Page 14 Keyboard Stand Assembly www.PyleUSA.com...
- Page 15 Features: • 2-in-1 Karaoke Keyboard: Play & Sing-Along! • Compact & Portable Musical Piano • Simple Electronic Plug-in Operation • Portable Piano • Built-in Full Range Stereo Speakers • Connect & Stream Audio from External Devices • Can Connect to Speaker and Play Sound •...
- Page 16 Headset Specs: • Construction Material: ABS + Laser decorative sheet • Wire Material: PVC at wire • Wire Length: 1.1M • Plug Diameter: 3.5mm 1/8 • Weight: 0.14 kg Keyboard Stand Features: • Baked Varnish • Detachable Function • Height Adjusting Function •...
- Page 17 Technical Specs: • (61) Keyboard Keys • 255 Styles/ 255 Sounds • 50 Demonstration Songs: One/All • Audio Interface: Aux (3.5mm) Output Jack / Mic Input • Max Sound Level: Up to 110 dB • USB/Power Cable Length: 3.9’ ft. •...
- Page 18 Questions? Comments? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
