Thor Broadcast Maximus4KFly User Manual

4K HDMI and USB E
PTZ Compact Camera
1
Camera Interface
No. Explain
1 Lens
2 Array Microphone
3 Brackets with Damper
2
Packing Box
ePTZ Camera × 1
USB 3.0 Cable × 1
Maximus4KFly
No. Explain
4 Product Label
5 USB 3.0 Interface
6 HDMI 2.0 Interface
IR Remote Controller × 1
User Manuel × 1
3
Remote Controller Specification
1
2
1
1
4
5
2
6
3 Camera Select Key
4
7
5
9
6
8
7
10
11
8 Preset Setting Key
9 Preset Reset Key
12
10
11
12
4
Specification
Camera
Video
Sony 1/2.5" CMOS
System
Effective
4K@3820*2160
Pixel
Zoom 4X Digital Zoom @1080P
Lens F=2.8mm FOV 130°
White
Auto / Indoor /Outdoor/ ONE PUSH, Manual
Balance
USB Function
4K@30,25fps; 1080p@30,25fps;
Video
1080i@60, 50, 30, 25fps; 720p@60, 50fps
Output
Encoding
UVC
Protocol
Video
Audio Function
Built-in
Audio
Voice
Pickup
Range
HDMI Interface
Video 4K@30,25fps; 1080p@30,25fps;
Output 1080i@60,50,30,25fps; 720p@60,50fps
Encoding
Audio
Output
ePTZ Support, 4X Digital Zoom @1080P
USB 3.0
Type B Female
Interface
HDMI 2.0
Key Function
After pressing, the camera enters standby
Power Key
mode
P/T RST Key After pressing, the camera enters self-check
Flip Key Set the camera image to flip
Select the camera to be controlled
BLC Key Turn on/off BLC
Menu Key Enter/Exist Menu
Camera PTZ Press HOME button, the camera return to the
Control Key middle position
Press "Preset" + Number(1-9) to save the
corresponding Preset
Press "Reset" + Number(1-9) to reset the
corresponding Preset
[AUTO]:Automatic focus [MANUAL]: Manual
focus
[FAR]: Manual focus, make the far object
Focus Key
clearer [NEAR]: Manual focus, make the near
object clearer
Zoom Key + increase, - decrease
Number Key Cooperate with setting / calling Preset
Min 0.02Lux @ F1.8,
Illumination AGC ON
Digital
Noise 2D,3D
Reduce
Shutter 1/30s ~ 1/10000s
Auto Focus Support
H.265 / H.264 / MJPEG
Support
UVC1.0 - UVC1.5
YES
USB 3.0
8Meters
H.265 / H.264 / MJPEG
N/A
Compatible with all interfaces below
USB3.0, support video, control, power
supply, audio input and output
Compatible with HDMI 2.0, 1.4, 1.3A, 1.3
and other interfaces, only supports video
transmission
