Accedian Skylight element GT Hardware Installation Manual

Specifications
Power
Input Power Ratings AC: 100-240V , 50-60Hz, 0.5-0.3A
AC
DC: 20-57V , 1.25A
DC (Max)
Output Power Ratings SFP : 1.5W per port, up to 5W
(Max)
ports
ANT (Sync. Option): 3.3V
DC
Power Consumption 22W (75 BTU/hr )
(Max) (Max)
Physical
Dimensions (H x W x D) 38 x 200 x 172mm (1.5 x 7.9 x 6.8")
Weight 1.35 kg (3 lb)
Environmental
Operating Temperature Commercial: 0°C to +50°C (32°F to 122°F)
Hardened: -40°C to 65°C (-40°F to 149°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 85% RH, Non Condensing
Storage Humidity 5% to 95%, Non Condensing
Maximum Altitude 2000 m (6600 ft), Above Sea Level
Regulation & Compliance (Model: NID4)
Safety IEC 60950-1, IEC 62368-1, EN 62368-1, CSA/UL 62368-1,
AS/NZS 62368.1, J62368-1
EMC - Emission (Class A) CISPR 32, IEC 61000-3-2, IEC 61000-3-3, EN 55032, EN
61000-3-2, EN 61000-3-3, FCC Part 15 (CFR 47), ICES-
003, AS/NZS CISPR 32, VCCI-CISPR 32, KS C 9832
EMC - Immunity CISPR 35, EN 55035, KS C 9835
EMC - Radio ETSI EN 301 489-19
Telco NEBS Level-3: GR-63, GR-1089
RoHS IEC 63000, EN IEC 63000
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
(Max)
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
total for all the
(Max)
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
, 50mA
(Max)
VCCI-A
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用すると電波妨害
を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要求さ
れることがあります。
KCC-A
사용자 안내문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경
에서 사용하는 경우 전파간섭의 우려가 있습니다.
Attention: This product, like all electronic products, uses semiconductors that
can be damaged by electrostatic discharge (ESD). Always observe appropriate
precautions when handling.
Warning: Potential for damage to equipment or personal injury.
Attention: This symbol indicates that the surface is hot and to use caution to
avoid touching it.
Functional grounding point
Protective grounding point
Special considerations
Basic Contents
• Skylight element: GT (1)
• Rubber feet (4)
• This Hardware Installation Guide (1)
Note: Package can contain other ordering options. See the Ordering Guide for more details.
Do not place hands, fingers or foreign objects in any holes, insertion slots or
gaps.
To avoid damage to the equipment, keep objects clear of system ventilation
inlets, outlets and system fans, if any, ensuring the air flow through the units
is not obstructed, and that the fans rotate freely.
Do not disassemble or alter the unit.
Compliance Satements
Conventions
Package Contents
Skylight element: GT™
HARDWARE INSTALLATION GUIDE
423-005-00, Revision 7
Published: 2022-08-30
