2D SENSE Mounting and Installation Guideline
Document TBS-032 for TCOM400 board revision 02
NOTE:
The latest version of this document is always available at:
https://cloud1.tbs-biometrics.com/index.php/s/nihEFQvY0vuDdns
Revision
October 22, 2021
April 13, 2022
June 8, 2022
December 23, 2022
Author
Comment
AG/TO
First Release
AG/TO
Name change from 2D TERMINAL to 2D SENSE
AG/TO
Updated installation environment
AG
Added Wiegand 3.3V limitation
Advertisement
Table of Contents
Related Manuals for tbs electronics 2D SENSE
Summary of Contents for tbs electronics 2D SENSE
- Page 1 The latest version of this document is always available at: https://cloud1.tbs-biometrics.com/index.php/s/nihEFQvY0vuDdns Revision Author Comment October 22, 2021 AG/TO First Release April 13, 2022 AG/TO Name change from 2D TERMINAL to 2D SENSE June 8, 2022 AG/TO Updated installation environment December 23, 2022 Added Wiegand 3.3V limitation...
-
Page 2: Table Of Contents
TBS Installation Manual – 2D SENSE Content Chapter Page Introduction ............................3 Legal and Safety Instructions ......................4 Declarations of Conformity ....................... 5 European Union (CE) regulatory notices ..................... 5 USA (FCC) regulatory notices ......................5 Canada (IC) regulatory notices ......................5 Mounting and Installation ......................... -
Page 3: Introduction
TBS Installation Manual – 2D SENSE Introduction The TBS 2D SENSE brings Access Control and Time & Attendance applications featuring biometrics to a new level. It combines highest security with user convenience and the most flexible configuration options on the market. -
Page 4: Legal And Safety Instructions
TBS company representative or TBS hotline. TBS reserves the right to make changes to information published in this document at any time and without notice. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 4 of 22... -
Page 5: Declarations Of Conformity
Le 2D SENSE est conforme à la norme ICES 003 : 2017 et 2016. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et 2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en... -
Page 6: Mounting And Installation
NOTE: Installation in extreme environments without proper protection may cause permanent device damage and voids warranty. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 6 of 22... -
Page 7: Accessing The Device
Lift up bottom part to have it angled ~12° from vertical axis, then carefully slide upwards. Please do not press hard! Remove Remove device carefully from back cover. Remove cables if required. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 7 of 22... -
Page 8: Closing The Device
To avoid destruction and electrical shorts please ensure no cable or metal parts press against the electronic boards inside the device! Please keep cables inside the device as short as possible. Do not feed other cables through device! • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 8 of 22... -
Page 9: Mounting Instructions
The recommended mounting height of the terminal is 1.11 m, measured from the floor to the lower screw holes of the back cover. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 9 of 22... -
Page 10: Flush Mount Terminal
IMPORTANT: It is strongly recommended to use upper cable duct. Please do not use cable ducts marked (see above). • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 10 of 22... -
Page 11: Power And Signal Wiring
Electrical Connection and Cabling Since Q3/2021 all TBS 2D SENSE are equipped with 'TCOM400' boards. An adhesive tag marks the installed board type. The on-board wire terminals are located on the main board of the terminal and are accessible after separating the front and back panels. -
Page 12: Power Supply
Power and ground shall be supplied to the PWR wire terminals located on the top. Wire Terminal Number 2D SENSE Label Type VCC 12-24 VDCC Voltage Ground • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 12 of 22... -
Page 13: Wiring Recommendations
1.31 5.2.2 Power on Ethernet Power supply to the 2D SENSE can also be provided by Ethernet (Power over Ethernet mode - IEEE802.3at type 2 compliant). TBS recommends using an ethernet cable of Cat5e standard or higher. The terminal may be powered via a UL 294 compliant PoE power injector or switch. According to the PoE standard two modes are available: power on data pins and power on dedicated pins. -
Page 14: General Purpose Input Output
GP In 3 3.3 V TTL Compatible GP Out 3.3 V TTL Compatible 3.3V Line Ground NOTE: It is recommended to connect ground for reference. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 14 of 22... -
Page 15: Integrated Relay
TBS CONTROLLER SMART (4 relays, 4x GPIN, 4x GPOut, connected via RS-485 or LAN) TBS CONTROLLER LITE (RelayBoard with 2 relays, connected via RS-485) • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 15 of 22... -
Page 16: Connecting Third Party Controllers
Ground Ground for Wiegand The 2D SENSE’s Wiegand interface works with LV-TTL (3.3 VDC) voltage level. In most cases, this level is sufficient to drive TTL (5V) inputs on the receiver’s side. Should the controller in use not be able to work properly with LV-TTL voltage, an external 3.3V-to-5V level shifter must be added to both D0 and D1 lines. - Page 17 If your door controller does not offer a dedicated RS485 GND line, it is up to the installer to select a fitting GND source for the serial interface. In case the 2D SENSE is powered from the controller, RS485 GND can be connected to PWR GND.
-
Page 18: Tamper Switch
TBS Installation Manual – 2D SENSE Tamper Switch TBS 2D SENSE can be equipped by a tamper switch that detects when the device front is lifted off from the mounting box. Function Activation creates a trigger in the TBS reader that can be used for actions, like deleting the internal database or sending an alarm output via relay or GPOUT. -
Page 19: Appendix
Use warm water with a few drops of soap or a combined cleaning & disinfection liquid normally used to wash hands. Don’t use aggressive detergents. The capacitive sensor of 2D SENSE is susceptible to scratches. Use soft towels for cleaning only, don’t use abrasive cleaning equipment. - Page 20 Verify camera endpoint configuration in DeviceConfig and ensure camera service is running on server. 1000 General network error. 1001 No Wifi signal. 1002 Low Wifi signal. • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 20 of 22...
-
Page 21: Tbs Port Assignments
(2) Port is not mandatory in FW 2.xx since DCC channel is used for enrollment (3) PC where the sensor management tool is running should have this port open for inbound • • TBS 2D SENSE Mounting and Installation Guideline REV02 TBS-032 Rev 12-2022 page 21 of 22... -
Page 22: References To Other Tbs Documents
References to other TBS documents TBS 2D SENSE Mounting and Installation Guideline Permanent link: https://cloud1.tbs-biometrics.com/index.php/s/Pn7MZFC1EwLzwED The QR code printed on the product opens this link, leading to the 2D SENSE product folder from where this manual is available. TBS Terminal Firmware https://biometrics.talentlms.com TBS Partner Portal with full product documentation and access to latest firmware for terminals.
