Summary of Contents for Origin Acoustics KlipLok BR10
- Page 1 KlipLok New Construction Bracket Installation Manual BR10, BR68, BR5, BR3 BRP8, BRP6...
-
Page 2: Table Of Contents
Table of Contents Introduction What’s Included Tools & Items About the New Construction Bracket Why a New Construction Bracket Positioning the Wings Assembling the Bracket Placing the Bracket Cutting the Hole Technical Assistance Warranty Return Process... -
Page 3: Introduction
Introduction Thank you for purchasing the BR & BRP New Construction Brackets. At Origin Acoustics, we take pride in providing you with a high quality product. All of Origin Acoustics’ products are designed to have excellent sound quality, longevity, and a simple installation process. -
Page 4: What's Included
What’s Included Bracket Wings (2) Tools & Items • Drywall Saw • Drill • Hammer • Measuring Tape • Screws • Nail About the New Construction Brackets The KlipLok new-construction bracket makes prewire installations easier by reserving the proper space for Origin loudspeakers before and after drywall has been installed. -
Page 5: Positioning The Wings
1. Positioning the Wings Origin rectangular KlipLok brackets Joist are shipped with wings that can attach Wing to any of four positions on the center frame. Most installations will require the wings to be directly opposite each other on the center frame. However, Bracket Wing there will be some installations that... -
Page 6: Assembling The Bracket
2. Assembling the Bracket The wings clip into place by lining up the tabs and grooves and simply pressing them into place. If additional Wing pressure is needed, we recommend placing the center frame on a solid flat surface and using both hands to apply even pressure to engage the Bracket wings. -
Page 7: Cutting The Hole
4. Cutting the Hole Make sure the “lip” of the reusable bracket is facing down into the room. The “lip” allows the bracket to act as a template for cutting the speaker cutout in the sheet rock. Cut along the inside of the bracket hole where the hole should be. Use a keyhole or drywall saw to cut the hole. -
Page 8: Technical Assistance
If you are considering returning the product, it’s required that you contact Origin Acoustics prior to any return attempts. This way we can determine if the issue can be resolved without returning the product, or if needed we can provide instructions and support for the return process. -
Page 9: Warranty
If the product is determined to be defective, it will be repaired or replaced at Origin Acoustics’ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 10: Return Process
Before making any return attempts, it is required that you first contact Origin Acoustics. Return product to Origin Acoustics or your dealer, either in person or by mail. It’s preferable if the product is returned in the original packaging. If this isn’t possible, the customer is responsible for insuring the shipment for the full value of the product. - Page 12 • 844-674-4461 ©2017 Origin Acoustics...
