- Page 1 SF-HANHELD-260T05 Body Tmperature Scanner System User Manual...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Instructions Safety Instructions ..................2 To ensure proper use of this producto, please read the instructions carefully before using. Structure ......................3 The optimal measuring distance for this producto is 1 meter. Display ......................3 To ensure measurement accuracy, please use the producto in an operating Power On/Off .................... -
Page 3: Structure
2. Structure 3. Display Display size: 2.8” Display resolution: 320 (vertical) x 240 (horizontal) pixels Item Description Item Description USB (Type-C) interface Flashlight button SD card slot Left button Interface cover Down button LED light Up button Infrared camera lens Replay button Visual light camera Right button... -
Page 4: Power On/Off
4. Power On/Off 5.2. Palette Press and hold the power button for 3 seconds to turn on/off the product. Note: After the product starts the shutdown procedure, it takes 5 to 6 seconds. Please try to avoid turning on and off the producto continuosly to avoid damage. 5. -
Page 5: Point Temperature
5.3. Point Temperature 5.4. Image Mode 1. Press the SET button to open the main menú 2. Press the left/right button to select the option 1. Press the SET button to open the main menú 3. Press the SET button to enter the Image Mode menú 2. -
Page 6: Settings
5.5.2. Date and Time 5.5. Settings To set date and time: 1. Press the up/down button to selec the Date and Time option in the settings menú To enter to Settings menú: 2. Press the SET button to enter the Date and Time submenú 3. -
Page 7: Hi / Lo Alert
5.5.4. HI / LO Alert 5.5.6. Display Brightness To set HI/LO temperature alert: Press the up/down button to select the HI/LO Alert option in the Settings menú To set Display Brightness: Press the SET button to enter the HI/LO Alert submenú Press the up/down button to select the Display Brightness option in the Settings Press the up/down button to select the desired option menú... -
Page 8: Usb Mode
5.5.8. USB Mode 5.5.10. System Settings To set USB mode: To set System Settings submenu: Press the up/down button to select the USB mode option in the Settings menú Press the up/down button to select the System Settings option in the Press the SET button to enter the USB mode submenú... -
Page 9: Operating Instructions
To format SD card: Factory Reset Press the up/down button to select the Format SD card option in the System Settings submenu Press the SET button to enter Press the up/down button to select YES Press the SET button to confirm Press the back button to exit NOTE: During the factory reset process, please do not force other operation avoid progam errors... - Page 10 6.2. Image Viewing 6.5. USB Communication and Image Projection 1. Download and install the PC software (refer to: https://athena-visiotech.s3-eu-west- 1.amazonaws.com/nx9xDHEBlrFzs_pSrxzY/) 2. Connect the USB cable to the PC 3. Set the USB mode to USB disk to browse pictures and analyze data through the PC software, set the USB mode to USB camera to realice real-time image projection through the PC software...
-
Page 11: Specifications
7. Specifications Image blending ratio 0% (pure visual light image), 25%, 50%, 75% and 100% Sensor UFPA (pure infrared image) Temperature Range 30°C ~ 45°C PC Software Measurement resolution 0.1°C Real-time image transmisión Yes (real-time image projection Accuracy ±0.5°C (at 25°C ambient through PC software) temperature) Data transmisión... -
Page 12: Maintenance
8. Maintenance Use a wet cloth or weak soap solution to clean the outer Shell of the device. Do not use abrasives, isopropyl alcohol or solvents to clean the outer Shell, lens or window. 9. Common Emissivity...
