Ciena 5162 Installation Manual

page of 110

/ 110
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

5162 Router

Installation

323-1955-201 - Standard Revision C

November 2023

2023 Ciena

Table of Contents

Need help?

Do you have a question about the 5162 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ciena 5162

Page 2 Corporation. All Rights Reserved Use or disclosure of data contained in this document is subject to the Legal Notices and restrictions in this section and, unless governed by a valid license agreement signed between you and Ciena, the Licensing Agreement that follows.
Page 3 (together with Software, “Product”) or (2) as a standalone application, and Software includes upgrades acquired by you from Ciena or a Ciena authorized reseller. The terms of this License apply to your use of the Software and associated documentation whether such has been provided by Ciena, an affiliate of Ciena, or by means of an authorized reseller or distributor.
Page 4 SUCH DATA OR PROGRAMS, EVEN IF INFORMED OF THE POSSIBILITY OF SUCH DAMAGES IN ADVANCE. 12. General. Ciena may assign this License to an affiliate or to a purchaser of the intellectual property rights in the Software. You shall not assign or transfer this License or any rights hereunder, and any attempt to do so will be void.
Page 5: Table Of Contents
HAPTER Chassis installation List of procedures 23 Mounting in a 4-post 19-inch rack 24 Mounting in a 2-post, front-mount rack 29 Mounting in a 2-post, mid-mount rack 33 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 6 HAPTER LEDs System status LEDs 83 10/1 GbE SFP+ port LEDs 84 100 GbE QSFP port LEDs 85 BITS RJ45 port LEDs 86 MGMT RJ45 port LEDs 87 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 7 FCC statement 97 Fiber break and damaged fiber precautions 97 General static electricity precautions 98 Optical fiber handling precautions 99 Precautions for handling and storing the chassis 99 Voltage precaution 100 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 9: Publication History
— Added a procedure on mounting the chassis into a two post rack in a mid-mount June 2023 Revision B Second standard release of this document. May 2022 Revision A Standard release of this document. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 11: About This Document
About this document This document directs network technicians and system administrators in the ® installation and start up of 5162 Router from Ciena Corporation. Hyperlinks are indicated by blue text in this document. Trademark acknowledgments Ciena is a trademark of Ciena Corporation.
Page 13: Hapter
Power units can be AC or DC, however, the combination of AC and DC units in the same chassis is not supported. 170-0092-900 5162 DC PLUGGABLE POWER SUPPLY, -48 VDC DC power distribution unit 170-0093-900 5162 AC PLUGGABLE POWER SUPPLY, WIDE...
Page 14 FOR USE W/ 5170/5162 rack 170-0193-900 19 INCHES 2 POST RACK FLUSHMOUNT Flushmount brackets for BRACKETS, FOR USE W/ 5170/5162 two-post 19 inch rack 170-0194-900 23 INCHES 2 POST RACK MIDMOUNT BRACKETS, Brackets for two-post 23 inch FOR USE W/ 5170/5162...
Page 15: Hapter
• 45 VDC input load = 144 W Maximum power consumption • 120VAC input load = 309 W (with standard optics) • 240VAC input load = 325 W • 48VDC input load = 284 W 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 16 5% to 90%, non-condensing Ambient operating temperature Includes indoor locations and partially controlled environments. 0°C to +40°C (32°F to 104°F) Storage temperature -40°C to +70°C (-40°F to 158°F) 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 17: Hapter
Installation Specification (IS) and Bill of Materials (BOM) • Regional, customer, and site-specific regulatory, installation, and safety requirements • Ciena® Standard Cleaning and Equipment Safety Practices (009-2003- 121) • Ciena® Installation Workmanship Standards (009-7B03-000) • Telcordia Electromagnetic Compatibility and Electrical Safety GR-1089- CORE •...
Page 18 Débranchez toutes les sources d'alimentation avant l'entretien afin d'éviter tout risque de choc. 危险觸電⾵險請在維修之前斷開所有電源，以免觸電。 WARNING This equipment is not suitable for use in locations where children are likely to be present. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 19: Chassis Size And Installation Options
The system can tolerate the failure of one fan and maintain operation until a maintenance action can be scheduled. The maintenance action to replace the unit must be scheduled as soon as possible. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 20: Proper Handling
Risque de dommages aux modules et aux fonds de panier Cet équipement contient des dispositifs sensibles aux décharges électrostatiques (DES). Portez des sangles de mise à la terre si vous devez manipuler l’équipement et suivez les procédures relatives aux DES. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 21: Required Tools And Equipment
• ESD-guard heel grounders • A Phillips screwdriver of suitable size to accommodate the rack screws • Flat head screwdriver • Anti-static bag or anti-static box 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 22: List Of Procedures
List of procedures The following is the procedure to create an ESD connection to protect the chassis from ESD damage. • Procedure 1, “Creating an ESD connection to the rack” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 23: Creating An Esd Connection To The Rack
Place the ESD wrist strap over your wrist. Connect the ESD strap to an ESD jack on the equipment rack. Ensure that the retractable cable is connected to the wrist strap and the rack. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 25: Hapter
The serial number and model number are located on a pull-out tab below the console port. Figure 2 Serial number location List of procedures The following are the major steps for unpacking and inspecting a 5162 router. • Procedure 2, “Unpacking the chassis” •...
Page 26: Unpacking The Chassis
Compare the labels on the shipping containers with the information on the packing list. If there are Then discrepancies or stop and notify Ciena® Global Product Support. Have missing the following information available: components • shipping invoice number • model and serial number of the damaged item •...
Page 27 Remove the foam block from the chassis. Remove the chassis out of the ESD bag. Ensure that the shipping container is empty. Dispose of shipping container and packing materials in accordance with site requirements. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 28: Inspecting For Damage
Visually inspect every surface of the chassis. Look for: • chipped paint • cracks • breaks • broken connectors • electronics damage such as bent pins Determine whether there is any damage. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 29 • photograph and record the damage • report the damage to the shipping courier ® • notify Ciena Global Product Support about damaged components no damage is the chassis is ready to be positioned and installed.
Page 30: Returning Materials
22 Unpacking and inspection Procedure 4 Returning materials All returned equipment must have a Ciena return merchandise authorization (RMA) number. Ciena is not responsible for any item returned without this identifier. Overview The following information is required to obtain an RMA number: •...
Page 31: Hapter
Procedure 5, “Mounting in a 4-post 19-inch rack” • Procedure 6, “Mounting in a 2-post, front-mount rack” • Procedure 7, “Mounting in a 2-post, mid-mount rack” • Procedure 8, “Installing the chassis on a desktop” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 32 Securing the mounting brackets to the chassis Align the holes on the first mounting bracket with the mounting holes on the side of the chassis. Figure 3 Mounting bracket chassis hole positions 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 33 The center of the bracket should lay flat against the chassis. Figure 5 Attach the mounting bracket 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 34 Secure the front rack post in the desired position in the rack using a customer- provided rack screw inserted in the center hole of the rack ear. Figure 7 Securing the rack posts 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 35 Installing the chassis in the rack Align the rails of the track bracket installed on the chassis with the channels of the front rack brackets already installed in the rack, then slide the 5162 into the rack. Figure 8 Aligning the rails Secure the chassis to the rack using 2 customer-provided rack screws.
Page 36 The following image shows the insertion location of the screw on the cable guide and on the bracket. Figure 10 Mounting bracket with cable guide 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 37 Align the holes on the front mounting bracket with the front three mounting holes on the side of the chassis. Secure the mounting bracket to the chassis with three of the provided flathead screws. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 38 Installing the chassis in the rack Secure the chassis in the desired position in the rack using two customer- provided rack screws inserted into the top and bottom holes of the rack ear. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 39 Slide a second rear mounting bracket onto the track bracket on the other side of the chassis. Secure the rear rack bracket to the rear of the rack with two customer- provided rack screws into the holes on the rear rack ears. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 40 23-in bracket. Figure 16 Mounting bracket with cable guide (23-inch bracket, right) 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 41 Using one of the four brackets provided in the mid-mount kit, align the three bracket holes with the front 3 mounting holes on the side of the chassis. Secure the bracket to the chassis with the three of the provided flat-head screws. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 42 Figure 18 Mid-mount bracket secured at 212.35 mm (8.36 in) setback Figure 19 Attaching the mounting brackets Use a Phillips screw driver to secure the third bracket to the chassis with three additional flat-head screws. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 43 The following image shows the insertion location of the screw on the cable guide and on the bracket as well as on the 23-in bracket. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 44 36 Chassis installation Figure 21 Mounting bracket with cable guide (23-inch bracket, right) 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 45: Installing The Chassis On A Desktop
警告⽕災危險確保交流供電的機箱直接放置在不可燃的服務上 . Steps Place the device in the desired location on a shelf or tabletop ensuring that adequate space is provided for cable and fiber management. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 47: Hapter
être installée de manière à protéger le personnel et l'équipement de façon adéquate. The following figure shows the location of the ground attachment point at the rear of the chassis. Figure 22 Location of the ground attachment point 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 48: List Of Procedures
“Chassis installation” on page 23 “Connect and verify ground cable” on page 43 List of procedures The following procedure installs the chassis ground connection. • Procedure 9, “Installing the chassis ground connection” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 49: Installing The Chassis Ground Connection
• All equipment cables and ground cables must conform to local regulatory standards and regional practices. Equipment cables and ground cables are not supplied by Ciena. CAUTION Possibility of power short If the wire gauge used is too large, the system is in danger of shorting out.
Page 50 Note: Ensure that there are no sharp bends in the copper grounding cable and do not expose the ground cable to sharp edges during installation. Cut a 2 in. (51 mm) length of heat-shrink tubing. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 51 Read the display and note the value. The reading must be less than one ohm. A resistance greater than one ohm indicates an improperly grounded device that must be corrected. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 53: Fan Module Installation
The following figure shows the location of the fan modules. Figure 25 Location of the fan modules The following image shows the connector end of a fan module. Figure 26 Fan module 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 54: List Of Procedures
à nouveau. List of procedures The following task flow summarizes the major steps of installing a cooling fan unit into the 5162 • “Installing fan modules” on page 47 5162 Router...
Page 55: Installing Fan Modules
à nouveau. Steps At the rear of the chassis, loosen the captive screw by turning it by hand 1/4 turn counter-clockwise. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 56 Slide the new fan module into the slot, then gently press to make sure the connector is seated into the board. Figure 28 Seating the fan Finish installing the fan module by tightening the captive screw by hand until secure. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 58: Dying Gasp
When two PSUs are used, each PSU should be connected to separate power feeds. This allows for the removal and replacement of one PSU while the router is still operating. The following figure shows the location of the AC power supply units. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 59 DANGER Electrical hazard This chassis has dual power connections, which supply hazardous energy levels. Remove power from both A and B power feeds to de-energize this equipment. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 60: List Of Procedures
Procedure 11, “Installing an AC power supply unit” • Procedure 12, “Installing the AC power feed” • Procedure 13, “Verifying power” • Procedure 14, “Removing an AC power supply” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 61: Installing An Ac Power Supply Unit
Note: The PSUs are universal and fit into either slot. If you are installing a second PSU, then remove the blank cover from slot PS B and repeat step 1 step 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 62: Installing The Ac Power Feed
Dress the power cord Dress the power cord towards the left side of the rack or cabinet. Ensure that the power cord is not dressed across the ports. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 63: Verifying Power
Connect the power cable to the AC socket outlet. Observe that the AC LEDs blink green and then change to solid green. Remove the power cable from the power source. The final connection is made “Cable installation” on page 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 65: Removing An Ac Power Supply
Disconnect all power sources before servicing to avoid shock hazard. DANGER Risque de choc électrique Débranchez toutes les sources d'alimentation avant l'entretien afin d'éviter tout risque de choc. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 66 Next, do one of the following: a. Install a replacement PSU immediately. b. If the slot is to remain empty for any length of time, install a power supply cover plate. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 67: Dc Power Installation
Procedure 16, “Installing the PDU power feed from a Battery Distribution Fuse Bay (BDFB)” • Procedure 17, “Verifying the power and return cables” • Procedure 18, “Removing a DC power distribution unit” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 68: Installing A Dc Power Distribution Unit
Remove the protective cover from the input connector. If you are installing a second PDU, then remove the blank cover from slot PS B and repeat step 1 through step 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 69: Installing The Pdu Power Feed From A Battery Distribution Fuse Bay (Bdfb)
The following image shows the faceplate of the DC power supply with the plastic terminal block cover. Make sure the cover is replaced after installing the input wiring. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 70 Touch the leads of the meter together to ensure that the meter is working properly. The meter should read less than 100 milliohms. Measure the resistance between the - terminal to the chassis GRD. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 71 Route power cables At the power source, ensure that the circuit breakers that supply power to the 5162 are OFF and tagged Out of Service. Route the power cables (load, return, and common) to the left side of the 5162 as appropriate for your site.
Page 72 Dress the power cables to the right and use cable ties to secure the cables to the rack to help relieve the cord weight from the connectors and avoid the inadvertent disconnection of the power supply cords. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 73: Verifying The Power And Return Cables
Confirm that the PSU A and B DC LEDs blink green and change to solid green. Open the BDFB circuit breakers removing DC power from the PDUs. Do not close the BDFB circuit breakers. The final connection is made in “Cable installation” on page 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 74: Removing A Dc Power Distribution Unit
Disconnect all power sources before servicing to avoid shock hazard. DANGER Risque de choc électrique Débranchez toutes les sources d'alimentation avant l'entretien afin d'éviter tout risque de choc. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 75 PDU was installed over the empty power slot. Replace the terminal block cover. Orient the cover so the cable openings are pointed down. Reapply power to the PDU. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 77: Hapter
Received power which is above that range may cause permanent damage to the optical module. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 78: List Of Procedures
List of procedures Procedures for transceiver installation are: • Procedure 19, “Handling pluggable transceivers” • Procedure 20, “Installing pluggable transceivers” • Procedure 21, “Removing a pluggable transeiver” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 79: Handling Pluggable Transceivers
Join the connector of an ESD wrist strap to the ESD jack on the equipment rack. Ensure that the retractable cable is connected to the wrist strap. Place the wrist strap over your wrist. Remove the transceiver from its packaging. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 80: Installing Pluggable Transceivers
Note: If the transceiver does not install easily, reorient the transceiver and try again. The following figure shows examples of various types of Ciena pluggable transceiver modules. Different chassis models support different types of transceiver modules. Refer to the ports on the chassis for the supported transceiver formats.
Page 81 ATTENTION Risque de blessures Vérifiez les DEL pour vous assurer que le matériel optique est en bon état de fonctionnement. Ne regardez pas dans le faisceau laser. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 82 74 Optics installation 危险受傷⾵險請檢查 LED 以確認光學裝置運作正常。請勿直視雷射光。 Install another transceiver or proceed to installing cabling. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 83: Removing A Pluggable Transeiver
未連接光纖時，端⼝孔徑可能會散發不可⾒輻射。請避免暴露在輻射中，並避免凝視開⼝。 CAUTION Risk of damage to modules and backplanes This equipment contains Electrostatic Discharge (ESD) sensitive devices. Wear grounding straps when handling equipment and follow ESD procedures. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 85: Hapter
HAPTER Cable installation When connecting cables to the 5162, always make only one connection at a time. Ciena recommends that cables be connected in the following order: Fiber cables Ethernet cables Note: All copper Ethernet cables, both intra-system and those connecting to the system should be shielded Cat 5e type minimum and terminated at both ends.
Page 86 être isolées du câblage exposé de l’installation extérieure (OSP). L’ajout de protecteurs primaires ne constitue pas une protection suffisante pour une connexion métallique de ces interfaces au câblage de l’installation extérieure. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 87: List Of Procedures
The following task flow summarizes the major steps for installing cables on the 5162. • Procedure 22, “Routing fiber” • Procedure 23, “Routing Ethernet cables” • Procedure 24, “Connecting power cables” 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 88: Routing Fiber
Requirements • The individuals involved in installation must be trained in and have experience with Ciena installations. • As much as possible, it is recommended that copper Ethernet cables, fiber, and power cables remain separated using the cable manager.
Page 89: Routing Ethernet Cables
Connect the Ethernet cable(s) to the appropriate port(s). Dress the cable(s) through either the left or the right cable support bracket. It is recommended to route the Ethernet cable(s) out of the right cable support bracket. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 90: Connecting Power Cables
If using a redundant power supply, connect the PSU B power cable and repeat step 2 through step 4, dressing the power cable to the right (while facing rear of the chassis). The hardware installation is complete. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 91: Chapter Leds
STAT Indicates an alarm condition. green Indicates that the status is normal and the system is ready. blinking green System is initializing and performing self tests. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 92: 10/1 Gbe Sfp+ Port Leds
The left arrows indicate link/activity while the right arrows indicate speed. The following figure shows the location of the 10 GbE SFP+ port LEDs. Figure 35 10 GbE SFP+ port LEDs location 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 93: 100 Gbe Qsfp Port Leds
The following figure shows the location of the 100/40 GbE QSFP port LEDs. Figure 36 100 GbE QSFP port LEDs location The following table describes the operating states for the 100 GbE QSFP port LEDs. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 94: Bits Rj45 Port Leds
Port is in a maintenance state (loopback). BITS In LOS is detected on the receive signal or no signal is present. yellow Input signal is being received. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 95: Mgmt Rj45 Port Leds
The port is not operational. green Indicates a valid network connection. blinking green Indicates transmit and receive activity. Port speed is 10 or 100 MbE. yellow Port speed is 1000 MbE. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation...
Page 97: Hapter
Health and safety The health, safety and welfare of engineers and support staff is of paramount importance to Ciena. Implementing a safe system of work with safe people is an integral component of our procedures and an absolute requirement under the provisions of the Health &...
Page 98 WEEE 2012/19/EU2 ETSI 300 019 Class 1.2, 2.2, 3.2 Laser Safety ANSI Z136 EN 60825-1 FDA 21 CFR subpart (J) (Safety of Laser Products) IEC 60825-1 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena Corporation November 2023...
Page 99: Compliance Information
(Type 2 or Type 4 ports as described in GR-1089-CORE) and require isolation from the exposed OSP cabling. The addition of Primary Protectors is not sufficient protection in order to connect these interfaces metallically to OSP wiring. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 100: Class 1M Laser Product Notice
The chassis, when operating normally with all doors and access covers installed, all energized fiber cabling connected, and protective caps/covers installed on all unused optical connectors, is a Class 1 laser product. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 101: En55022 Class A Notice
Environmental impact statement Ciena equipment contains no hazardous materials as defined by the United States Environmental Protection Agency (USEPA). Ciena recommends that all failed products be returned to Ciena for failure analysis and proper disposal. Federal Communications Commission: Interference This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the of the of the Federal Communications Commission (FCC) rules.
Page 102: Industry Canada Notice
Food and Drug Administration (FDA) laser safety warning This product contains a laser diode. Ciena Corporation strongly recommends that users and maintenance and service personnel comply with the standards and regulations in the design, modification, operation, maintenance, and service of lasers and fiber-optic devices.
Page 103: Vcci Class A Statement
Do not touch un-insulated wiring or terminals carrying direct current or leave this wiring exposed. Protect and tape wiring and terminals to avoid risk of fire, electric shock, and injury to service personnel. 5162 Router Installation 323-1955-201 Standard Revision C ©...
Page 104 Opening the chassis voids the warranty. ATTENTION Non remplaçable sur le site Le bâti ne doit jamais et en aucun cas être ouvert. L’ouverture du bâti entraîne l’annulation de la garantie. 5162 Router Installation 323-1955-201 Standard Revision C © ®...
Page 105: Ce Compliance
If necessary, the user should consult the dealer or an experienced radio/ television technician for additional suggestions. Modifications to this product not authorized by Ciena could void the FCC approval and negate your authority to operate the product. Fiber break and damaged fiber precautions...
Page 106: General Static Electricity Precautions
Materials similar to cotton do not typically have the potential to generate and hold a charge. The buildup of static electricity can be of a sufficient potential to damage electronic circuitry. When working on Ciena equipment or any interconnecting electrical/optical cabling, always wear an approved personnel ground device.
Page 107: Optical Fiber Handling Precautions
When handling, installing, or removing a chassis, observe the following precautions: • Wear wrist straps or other suitable ESD-grounding devices before touching and/or removing a chassis from the equipment shelf or ESD- protective packaging. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright...
Page 108: Voltage Precaution
• Before activating circuits, ensure that other personnel are not in contact with voltage sources. • Deactivate power whenever possible before performing maintenance on system components. 5162 Router Installation 323-1955-201 Standard Revision C © ® Copyright 2023 Ciena...
Page 110 Installation © ® Copyright 2023 Ciena Corporation. All rights reserved. Publication: 323-1955-201 Document status: Standard Revision C Document release date: November 2023 CONTACT CIENA For additional information, office locations, and phone numbers, please visit the Ciena web site at www.ciena.com...
