Hardware Installation and Reference Guide
WAP680ax Series Access Points
Hardware installation and reference guide
Copyright © Windbit Dm3101-I Version 1.1 2024
WAP680ax Access Points

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAP680ax Series and is the answer not in the manual?

Questions and answers

Related Manuals for Windbit WAP680ax Series

Summary of Contents for Windbit WAP680ax Series

  • Page 1 Windbit Hardware Installation and Reference Guide WAP680ax Series Access Points Hardware installation and reference guide Copyright © Windbit Dm3101-I Version 1.1 2024 WAP680ax Access Points...
  • Page 2 Windbit Hardware Installation and Reference Guide Legal Notice Warranty This publication is subject to updates and modifications. Teldat S.A. disclaims all warranties regarding the information in this manual. Teldat S.A. shall not be held liable for any direct, indirect, collateral, consequential, or other damages related to the delivery, supply, or use of this manual.

  • Page 3: Preface

    This document is intended for: ⚫ Network engineers ⚫ Technical support and servicing engineers Network administrators ⚫ Technical Support ⚫ Windbit website: https://www.windbit.com/ ⚫ Technical Support Website: https://support.windbit.com Conventions Signs The signs used in this document are described as follows: Warning An alert highlighting crucial rules and information.

  • Page 4: Table Of Contents

    Windbit Hardware Installation and Reference Guide Contents Preface ............................... 0 Product Overview ..........................1 Introduction to the WAP680ax Access Point ............... 1 Overview of Hardware Features................... 1 Package Contents ........................ 5 Technical Specifications ....................... 5 1.4.1 Dimensions and Weight ....................5 1.4.2...
  • Page 5 Windbit Hardware Installation and Reference Guide 3.6.2 Ethernet Cable Setup ....................27 3.6.3 Fiber-Optic Cable Setup ....................28 3.6.4 Power Cord Installation ....................29 Cable Bundling Techniques ....................30 3.7.1 Precautions for Cable Bundling .................. 30 3.7.2 Effective Cable Bundling Strategies................30 Post- Installation Checklist ....................

  • Page 6: Product Overview

    Windbit Hardware Installation and Reference Guide 1 Product Overview 1.1 Introduction to the WAP680ax Access Point The WAP680ax is an outdoor dual-radio, dual-stream access point. It adheres to the IEEE 802.11ax standard, offering a combined data rate of 2.975 Gbps. This includes speeds of up to 575 Mbps in the 2.4 GHz band and 2.4 Gbps in the 5 GHz band.
  • Page 7 Windbit Hardware Installation and Reference Guide Front View of Access Point Figure 1-1 WAP680ax Access Points...
  • Page 8 Windbit Hardware Installation and Reference Guide Top View of Access Point Figure 1-2 WAP680ax Access Points...
  • Page 9 Windbit Hardware Installation and Reference Guide Side View of Access Point Figure 1-3 Button and Ports Table 1-1 Item Description The console port is used for device management. Console/Reset The reset button is used for restarting the access point or restoring it to factory settings.

  • Page 10: Package Contents

    Windbit Hardware Installation and Reference Guide Note The nameplate is at the bottom of the access point. 1.3 Package Contents Package Contents Table 1-2 Item Quantity WAP680ax Access Point Mounting Plate Assembly (Including a mounting plate and a mounting arm)

  • Page 11: Radio Specifications

    Windbit Hardware Installation and Reference Guide Dimensions and WAP680ax Weight Access point: 1.0 kg (2.20 lbs.) Weight Mounting plate assembly: 0.6 kg (1.32 lbs.) Mounting bracket: 0.3 kg (0.66 lbs.) Installation Ceil mounting and pole mounting Lock Option Not supported Mounting plate assembly: 100 mm ×...

  • Page 12: Port Specifications

    Windbit Hardware Installation and Reference Guide Radio Specifications WAP680ax Power Adjustment Configurable in increments of 1 dBm 802.11b: BPSK, QPSK, CCK 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM Modulation 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11b: –91 dBm (1 Mbps), –88 dBm (5 Mbps), –85 dBm (11 Mbps)

  • Page 13: Power Supply And Consumption

    Windbit Hardware Installation and Reference Guide 1.4.4 Power Supply and Consumption Power Supply and Consumption Table 1-6 Power Supply and WAP680ax Consumption 1. DC power supply (48 V/0.35 Input Power Supply 2. PoE/PoE+ power supply (IEEE 802.3af/at-compliant) Max. Power 12.95 W...

  • Page 14: Functionality Of Led And Reset Button

    Windbit Hardware Installation and Reference Guide 1.5 Functionality of LED and Reset Button Note The LED description applies universally to both fit and fat modes, unless specifically noted otherwise. LED Status Table 1-8 Status Frequency Description The access point is not powered on.

  • Page 15: Understanding The Optical Module

    Windbit Hardware Installation and Reference Guide RSSI LEDs Table 1-10 No. of Steady-on LED Color Description LEDs The bridge function is currently disabled on the access point. The bridge function is currently disabled on the access point, resulting in failed bridging attempts.

  • Page 16: Preparing For Installation

    Windbit Hardware Installation and Reference Guide 2 Preparing for Installation 2.1 Safety Guidelines Note ● To prevent personal injury and device damage, carefully review the safety precautions before installing the device. ● These safety precautions may not encompass all potential hazards.

  • Page 17: Secure Storage Protocols

    Windbit Hardware Installation and Reference Guide ⚫ Inspect the work area for potential risks, such as wet ground. ⚫ Identify the indoor emergency power switch location before installation and cut off the power switch in case of accidents. ⚫ Thoroughly check the access point before shutting down the power supply.

  • Page 18: Cleanliness Guidelines

    Windbit Hardware Installation and Reference Guide ⚫ Conversely, in environments with low relative humidity, insulating strips may dry out and shrink, leading to loosened screws. In excessively dry environments, static electricity poses a risk of damaging the internal circuits of the access ⚫...

  • Page 19: System Grounding Requirements

    Windbit Hardware Installation and Reference Guide Average (mg/m Maximum (mg/m Chlorine gas (CI 0.01 Note The Average value represents the mean concentration of harmful gas over the course of one week. The Maximum value indicates the upper threshold of harmful gas concentration within a single week, with this maximum level permissible for up to 30 minutes each day.

  • Page 20: Lightning Protection Guidelines

    Windbit Hardware Installation and Reference Guide 2.2.8 Lightning Protection Guidelines The WAP680ax offers protection against lightning strikes, however, exceptionally strong strikes can still pose a risk of damaging the device. To mitigate this risk, consider the following lightning protection measures: ⚫...
  • Page 21 Windbit Hardware Installation and Reference Guide Note The WAP680ax does not come with a tool kit; customers are responsible for providing their own. WAP680ax Access Points...

  • Page 22: Access Point Installation Process

    Windbit Hardware Installation and Reference Guide 3 Access Point Installation Process The WAP680ax access point should be installed at a fixed position. Caution Prior to installing the device, thoroughly review the requirements outlined in Chapter 2. 3.1 Step-by-Step Installation Flowchart...
  • Page 23 Windbit Hardware Installation and Reference Guide ⚫ Confirm that the installation location adheres to the specified temperature and humidity guidelines for the device. Ensure that the necessary power supply and required current are accessible at the installation site. ⚫ ⚫...

  • Page 24: Essential Precautions To Observe

    Windbit Hardware Installation and Reference Guide Mounting Bracket Dimensions Figure 1-7 3.3 Essential Precautions to Observe To ensure optimal performance and extend the service life of the access point, adhere to the following safety precautions: ⚫ Avoid powering on the device during installation.

  • Page 25: Pole Mounting Procedure

    Windbit Hardware Installation and Reference Guide Access Point Wi-Fi Coverage Area Figure 1-8 3.4.1 Pole Mounting Procedure (2) Secure the mounting plate assembly to the underside of the WAP680ax access point using four M5 screws. Attaching the Mounting Plate Assembly to an Access Point Figure 1-9 (3) Secure the mounting bracket to a pole.
  • Page 26 Windbit Hardware Installation and Reference Guide For vertical pole mounting: Thread two hose clamps through the square holes of the mounting bracket ○ and secure it to the vertical pole. Ensure the part of the bracket labeled TOP is positioned on top.
  • Page 27 Windbit Hardware Installation and Reference Guide (4) Align the two holes on the mounting arm with the corresponding screw holes on the mounting bracket. Placing the Mounting Arm onto the Mounting Bracket Figure 1-12 (5) Secure the mounting arm to the mounting bracket using two M8 screws.

  • Page 28: Ceiling Mounting Instructions

    Windbit Hardware Installation and Reference Guide Securing the Mounting Arm to the Mounting Bracket Figure 1-13 3.4.2 Ceiling Mounting Instructions (6) Use four M6 expansion anchors to securely attach the mounting bracket to the ceiling. Securing the Mounting Bracket to the Ceiling Figure 1-14 (7) To detach the mounting arm, loosen the two M6 screws on the mounting plate assembly.
  • Page 29 Windbit Hardware Installation and Reference Guide Rotating the Mounting Arm Clockwise by 90 Degrees Figure 1-15 (8) Attach the mounting plate assembly to the underside of the WAP680ax access point using four M5 screws. (9) Align the mounting arm with the mounting bracket, ensuring that its two holes match up with the screw holes on the bracket.
  • Page 30 Windbit Hardware Installation and Reference Guide Secure the mounting arm to the mounting bracket by fastening it with two M8 screws. (10) Securing the Mounting Arm to the Mounting Bracket Figure 1-17 WAP680ax Access Points...

  • Page 31: Access Point Removal Guidelines

    Windbit Hardware Installation and Reference Guide Caution ● Use screws that match the screw holes, and securely fasten the structural components at various stages of installation. ● Securely tighten all fastening screws. Failure to do so could result in excessive vibration, shifting, or even the device falling.

  • Page 32: Ethernet Cable Setup

    Windbit Hardware Installation and Reference Guide Installing the Grounding Cable Figure 1-19 3.6.2 Ethernet Cable Setup Caution ● Ensure proper insertion of the RJ45 connector into the access point to prevent damage when tightening the cable gland. ● When disconnecting the Ethernet cable, remove the cable gland before detaching the RJ45 connector from the access point.

  • Page 33: Fiber-Optic Cable Setup

    Windbit Hardware Installation and Reference Guide Use an Ethernet cable installation tool to affix an RJ45 connector onto the unterminated end of the (13) Ethernet cable. Then, apply waterproof materials to the Ethernet cable between part B (split gasket) and C (grommet).

  • Page 34: Power Cord Installation

    Windbit Hardware Installation and Reference Guide Exploded View of Cable Gland Assembly Figure 1-22 Install an RJ-45 connector onto the unterminated end of the fiber-optic cable, then carefully insert the RJ- (17) 45 connector into the SFP port of the access point. Thread part A (adapter base) into the SFP port.

  • Page 35: Cable Bundling Techniques

    Windbit Hardware Installation and Reference Guide 3.7 Cable Bundling Techniques 3.7.1 Precautions for Cable Bundling ⚫ Arrange cables neatly to maintain aesthetic appeal. ⚫ When bending twisted pairs, do so naturally or with a wide radius near the connector. Avoid over-tightening twisted pair bundles to prevent reduced cable lifespan and performance.
  • Page 36 Windbit Hardware Installation and Reference Guide ⚫ Verify the access point’s functionality after powering it on. WAP680ax Access Points...

  • Page 37: Operational Status Verification

    Windbit Hardware Installation and Reference Guide 4 Operational Status Verification 4.1 Configuration Environment Setup The access point can be powered either through PoE or local power sources. ⚫ When powering the access point via DC or PoE, ensure the power supply operates correctly and adheres to safety standards.

  • Page 38: Monitoring And Maintenance

    ⚫ When the access point operates in fit mode, it facilitates centralized management and maintenance through a wireless controller. 5.3 Hardware Maintenance If you encounter any hardware issues, please reach out to Windbit technical support for assistance. WAP680ax Access Points...

  • Page 39: Troubleshooting Common Issues

    Check whether the LEDs are normal. Confirm that all cables are properly connected to their respective ports. If issues persist, contact Windbit technical support to investigate potential hardware faults. 6.2 Identifying Common Faults 6.2.1 Ethernet Port Malfunction After Cable Connection Ensure that the peer device is functioning correctly and confirm that the Ethernet cable can support the required data rate and is securely connected.

  • Page 40: Led Blinks Blue At 0.2S Intervals (In Fit Mode)

    Windbit Hardware Installation and Reference Guide 6.2.5 LED Blinks Blue at 0.2s Intervals (in Fit Mode) At times, the access point undergoes a software upgrade immediately after powering on. Throughout this process, the LED blinks blue at intervals of 0.2 seconds and remains in this state until the upgrade is finalized, indicated by a steady blue light.

  • Page 41: Appendix

    Windbit Hardware Installation and Reference Guide 7 Appendix 7.1 Connectors and Media Specifications ⚫ 1000BASE-T/100BASE-TX/10BASE-T port The 1000BASE-T/100BASE-TX/10BASE-T operates at speeds of 10/100/1000 Mbps and supports both auto- negotiation and auto MDI/MDIX Crossover. In accordance with IEEE 802.3ab standards, the 1000BASE-T port necessitates the use of 100-ohm Category 5/5e UTP or STP cables, with a maximum distance limit of 100 meters (328.08 feet).
  • Page 42 Windbit Hardware Installation and Reference Guide Socket Plug Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used The diagram below illustrates the possible configurations of straight-through and crossover twisted pairs for a 100BASE-TX/10BASE-T port. 100BASE-TX/10BASE-T Twisted Pairs Connection...

  • Page 43: Comprehensive Guide To Cabling

    Windbit Hardware Installation and Reference Guide 7.2 Comprehensive Guide to Cabling During installation, route cable bundles either upward or downward along the sides of the rack, depending on the specific layout of the equipment room. All cable connectors should be positioned at the bottom of the cabinet to avoid exposure outside.
  • Page 44 Windbit Hardware Installation and Reference Guide Any metal hole through which cables pass should possess a smooth and fully rounded surface or be ○ lined with insulation to prevent damage to the cables. It’s essential to select appropriate cable ties for bundling cables. Connecting two or more cable ties to ○...
  • Page 45 Windbit Hardware Installation and Reference Guide assembly to prevent tension or stress. Upon reaching the installation position, the remaining cable segment should steer clear of heat sources, sharp corners, or sharp edges. If exposure to heat sources is unavoidable, utilize high-temperature cables.

  • Page 46: Detailed Dc Connector Specifications

    Windbit Hardware Installation and Reference Guide 7.3 Detailed DC Connector Specifications ⚫ Input voltage: 48 V DC; rated current: 0.35 A DC Connector Specifications Table 1-16 Inner Diameter Outer Diameter Depth Polarity 2.0 mm (0.08 in.) 6.3 mm (0.25 in.) 9.8 mm (0.39 in.)
