Summary of Contents for Philips DTR220
- Page 1 DTR 220/05 www.philips.com/welcome For support call 0870 900 9070 Receiver...
-
Page 2: Table Of Contents
Contents Quick Start Guide ..... 3 Introduction......4 Environmental Markings . -
Page 3: Quick Start Guide
Quick Start Guide Connecting to a Television UHF Aerial RF in connector Connecting to a Television and Recorder UHF Aerial Example TV set, rear panel Set Top Box, rear panel Example VCR set, rear panel Example TV set, rear panel SCART input on TV SCART cable (supplied) -
Page 4: Introduction
Introduction Thank you for purchasing this product which has been designed and manufactured to give you many years of trouble-free service. About This User Manual This user guide contains all the information you need to know about how to setup and watch available 'Freeview' channels using your set top box. -
Page 5: Environmental Markings
The "Green Dot" affixed on cardboard means PHILIPS pays a financial duty to the "Avoidance and Recovery of Packaging Waste" organization. NTRODUCTION... -
Page 6: Getting Started
If any of these items are damaged or missing, please contact us at: Philips CE, The Philips Centre,Surrey 0870 900 9070 Please make sure that you have the model number of your set top box, before contacting us. The label showing the type and serial number is underneath your receiver. -
Page 7: The Remote Control
Digital Set Top Box Front view IR Receiver / Blue LED, Normal Operation - off, Stand-by - on Rear view RF out RF in from Aerial Mains Adaptor Plug this into a 230V AC outlet socket The Remote Control Using the Remote Control To use the remote control, point it towards the front of the set top box. -
Page 8: Connecting Your Digital Set Top Box To Other Equipment
Connecting Your Digital Set Top Box to other equipment The following diagrams are of typical configurations only, and may differ slightly to your existing external equipment. If you are unsure on how to connect to your set top box, always consult your manufacturer's user guide supplied with your equipment. Connecting to a Television and DVD player UHF Aerial Set Top Box rear panel... -
Page 9: Switching On For The First Time
Switching on for the first time 1 Connect your equipment according to the appropriate system diagram given on the previous pages and power up/turn on the equipment. During initialisation the indicator on the front panel will flash for a few seconds and then remain off. If the indicator is blue (stand by) press the Power key on the remote control. -
Page 10: Using The Set Top Box
Using the Set Top Box Volume control - Use the volume keys + and - for increasing or decreasing the volume. Mute function By pressing the MUTE key, the sound reproduction is stopped. The sound is audible again if you... - ... -
Page 11: Select A Channel From A Favourites List
Sorting channels in the favourite list You can individually set the sequence of the channels within a favourites list. 1 Press the I-II key to switch to the favourites list. 2 Highlight the channel you want to shift by using the arrow keys 3 Press the OK key to confirm the channel to be shifted. -
Page 12: Using Teletext
How to use the options: 1 Call up the desired channel. 2 Press e.g. the I-II key for sound selection. If a teletext is offered, you can call it up by using the TEXT key. Using teletext 1 Press the TEXT key to call up the teletext. Note: You possibly also have to press the OK key in order to display the teletext and to specify whether you want to use the teletext of your TV, or that of the receiver. -
Page 13: Editing The Timer List
2 Press the TIMER key. 3 Press the OK key. The window is closed and the selected program is stored in the timer list. Editing the timer list During the normal program replay, press the TIMER key to open the timer list. Deleting (a) program(s) 1 Select the desired program. -
Page 14: Settings Menu
Settings Menu 1 Press the MENU key to open the main menu. The menu item Box Settings is highlighted by default. Note: You can close any menu by pressing the EXIT key. 2 Press OK. The Box Settings menu displays: 3 By using the arrow keys option and press the OK key in order to call it up. -
Page 15: Miscellaneous Settings
Transparency Here you set the transparency of the OSD. If you have dif- ficulties to read the OSD with transparent setting, select not any. Miscellaneous settings Options here include: - Time Zone settings - Audio Format (Mono - Stereo) This is useful if programs are being broadcasted in multi- ple languages (right-left channel). -
Page 16: Channel Search
Channel search In the main menu you can choose between Automatic Search and Manual Search. After the initial installation, it may be required to search for channels again, or to add specific channels that are additionally broadcasted. Note: In order to carry out a new initial installation, you have to reset the device to its default settings, see page 15. -
Page 17: Security
Security 1 Press the MENU key. 2 Highlight the item Security by using the arrow keys and press the OK key. 3 Enter the PIN code and acknowledge by OK. Note: The PIN code is set to 0000 at delivery. Also observe the displayed information. -
Page 18: Troubleshooting
Troubleshooting If you experience an operating problem with your Digital Set Top Box, please refer to the trouble-shooting table below and then the notes that follow. Symptom No picture and no sound No picture or picture is blocky in appearance Sound but no picture Cannot receive station that you could receive before... -
Page 19: Technical Data
Technical Data General - DVB terrestrial Free-To-Air receiver compliant to EN 300 744 - MHEG5 and LCN support - UHF frequency range support - Video and Audio out via 2x SCART - Digital audio out - Fast channel search - Reed-Solomon decoding support (EN 300 744) - Automatic FEC selection (1/2, 2/3, 3/4, 5/6, 7/8) - MPEG2 Transport Stream support: ISO/IEC 13818-1 - DVB-Video/-Audio support: ISO/IEC 13818-2, -3... -
Page 20: Guarantee
Guarantee This set top box is guaranteed for 12 months from the date of original purchase. If any defect arises due to faulty materials or workmanship, the set top box will either be replaced, a refund given or repaired free of charge (where possible) during this period by the dealer from whom you purchased.
